Page 1: User Manual
User Manual CS-HDBTLPOER-70 70m HDBaseT Extender with Bi-directional PoE Version: V1.0.0... -
Page 3: Important Safety Instructions
Important Safety Instructions Warning: To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth. splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. -
Page 4: Table Of Contents
Table of Contents Introduction ....................3 Overview ....................3 Features ....................4 Package Contents ..................4 Specifications .................... 5 Transmitter..................5 Receiver .................... 8 Panel ...................... 11 Transmitter..................11 Receiver ..................13 Hardware Installation ................... 17 IR Control ..................... 19 Scenario 1 .................... - Page 5 Maintenance ..........Error! Bookmark not defined. Provided Service ........Error! Bookmark not defined. Mail-In Service .......... Error! Bookmark not defined. Warranty ........... Error! Bookmark not defined. Warranty Limits and Exclusions ....Error! Bookmark not defined. Glossary ....................... 23...
-
Page 6: Introduction
Introduction Overview CS-HDBTLPOER-70 is a 70m, 4K HDBaseT Extender with BI-directional PoE, which offers the distribution of uncompressed 4K@60Hz UHD video, HD audio, Power, RS232, Two-way IR up to 70m/230ft over a single Cat(x) cable. It allows the transmission of uncompressed 4K@60Hz UHD video, HDCP 2.2 compatibility, RS232 and Bi-directional IR pass through. -
Page 7: Features
Features Cat 6a/7 cables, 4K@60Hz output up to 40m, while 1080P up to 70m Cat 5e/6 cables, 4K@60Hz output up to 35m, while 1080P up to 60m HDMI 1.4 with 4k@60Hz (Chroma sub-sampling 4:2:0 8-bit only) and HDCP 2.2 compliance ... -
Page 8: Specifications
Specifications Transmitter Technical Video Input 1 x HDMI Input Signal Type HDMI: HDMI1.4 w/ HDCP 2.2 pass through 4096x2160@24/25/30/50/60Hz, 3840x2160@24/25/30/50/60Hz, 1080P, 1080I, 720P, 576p, 576i, 480p, 480i; Input Resolution Support NOTE: 4k@50/60Hz are supported under Chroma sub-sampling 4:2:0 8-bit only. Input Video Level 0.5~1.0 Vp-p Maximum Pixel Clock... - Page 9 1080P, 1080I, 720P, 576p, 576i, 480p, 480i; NOTE: 4k@50/60Hz are supported under Chroma sub-sampling 4:2:0 8-bit only. 100Ω Video Impedance Cat 5e/6: 4K: 35m; 1080P: 60m Maximum Transmission Distance Cat 6a/7: 4K: 40m; 1080P: 70m Audio Stereo, LPCM 5.1, LPCM 7.1; Dolby True Support Audio Format HD, DTS-HD Master Audio Control...
- Page 10 10% to 90%, non-condensing Product Weight 200g Power Supply DC 18V 1A Power Consumption 11W Max (Pair) Product Dimension 162mm × 74.2mm × 25mm (L x W x H) Human-body Model: ESD Protection ±8kV(Air-gap discharge)/ ±4kV(Contact discharge)
-
Page 11: Receiver
Receiver Technical Specifications Video Input 1 x HDBaseT Input Signal Type HDBaseT 4096 x 2160@24/25/30/50/60Hz, 3840 x 2160@24/25/30/50/60Hz, 1080P, 1080I, 720P, 576p, 576i, 480p, 480i; Input Resolution Support NOTE: 4k@50/60Hz are supported under Chroma sub-sampling 4:2:0 8-bit only. Input Video Level 0.5~1.0 Vp-p Maximum Pixel Clock 297MHz... - Page 12 1080P, 1080I, 720P, 576p, 576i, 480p, 480i; NOTE: 4k@50/60Hz are supported under Chroma sub-sampling 4:2:0 8-bit only. 100Ω Video Impedance Cat 5e/6: 4K: 35m; 1080P: 60m Maximum Transmission Distance Cat 6a/7: 4K: 40m; 1080P: 70m Audio Stereo, LPCM 5.1, LPCM 7.1; Dolby True Support Audio HD, DTS-HD Master Audio Control...
- Page 13 10% to 90%, non-condensing Product Weight 200g Power Supply DC 18V 1A Power Consumption 11W Max (Pair) Product Dimension 162mm × 74.2mm × 25mm (L x W x H) Human-body Model: ESD Protection ±8kV(Air-gap discharge)/ ±4kV(Contact discharge)
-
Page 14: Panel
Panel Transmitter Front Panel Name Description ON: Transmitter is powered on. Power LED OFF: Transmitter is powered off. ON: Transmitter and Receiver are linked. Blinking: Connection exception. Link LED OFF: No link. - Page 15 Rear Panel Name Description Connects to a power supply. If Transmitter is connected to a power supply, Receiver Power is adapter free. HDBT OUT Connects to the Receiver via a Cat(x) cable. IR RX Connects to the supplied IR receiver (30KHz-50KHz). IR TX Connects to the supplied IR emitter.
-
Page 16: Receiver
Name Description RS232 RS232 pass through HDMI IN Connects to HDMI source device. Receiver Front Panel Name Description ON: Receiver is powered on. Power LED OFF: Receiver is powered off. ON: Transmitter and Receiver are linked to each other. Blinking: Connection exception. Link LED OFF: No link. - Page 18 Rear Panel Name Description Connects to a power supply. If Receiver is connected to a power supply, Transmitter Power is adapter free. HDBT IN Connects to the Transmitter via a Cat(x) cable. Connects to the supplied IR receiver (30KHz-50KHz). IR RX...
- Page 19 Name Description Connects to the supplied IR emitter. IR TX RS232 pass through RS232 HDMI OUT Connects to HDMI display device.
-
Page 20: Hardware Installation
Hardware Installation Connect an HDMI source (such as a Blu-Ray, games console, media server etc.) to Transmitter using quality HDMI cables. Connect a good quality, well terminated Cat5e/6 cable of no more than 70m/230ft in length between the HDBaseT output of the Transmitter and HDBaseT input of Receiver. -
Page 22: Ir Control
IR Control IR pass-through function allows you to control the source from the display's location or control the display from source's location. Scenario 1 Controlling the Source from the display side. -
Page 23: Scenario 2
Scenario 2 Controlling the Display from the Source side. -
Page 25: Troubleshooting
Troubleshooting 1: Why the Power indicator is off? Check that all the devices are powered on. Check that all the cables are qualified and connected properly. 2: Why the Link indicator is off or blinking? Check that all the devices are powered on. ... - Page 26 Glossary Acronym Complete Term Direct Current Digital Video Disc Electro-static Discharge High Definition HDBT HDBaseT HDCP High-bandwidth Digital Content Protection HDMI High Definition Multimedia Interface Infra-red Liquid Crystal Display Light Emitting Diode Power over Ethernet...
- Page 28 Metra Electronics Corp. 460 Walker Street Holly Hill, Fl. 32117 Main Tel: (866) 839-9187 Tech Support: (866) 839-9187 www.metrahometheater.com...
