Metra Electronics CS-HDC5EXTS User Manual

HDMI Extender Over Cat/6
CS-HDC5EXTS
IMPORTANT SAFETY INSTRUCTIONS
• Do not mix up HDM I to RJ45 sender and
receiver before installation.
•
Do not hot plug when it is powered up.
• Use DC5V power supply only. Make sure specification
matched if using adapters not supplied by factory.

1. PACKAGE CONTENTS

HDMI senderTX*1 pcs
DC5V1 A "2pcs
11

2. INSTALLATION REQUIREMENTS

2.1. HDMI source device.
2.2. HDMI display device.
2.3. UTP/STP cat6/cat6A/cat7 cable
2.4. Follow standard IEEE-5688
2.5.Transmit length more than 40m by CATS cable or higher
level cable.
HDMI receiver RX*1 pcs
User's manual*1 pcs

3. Interfaces

3.1.HDMI to Rj45

G) DC5V power input
®
HDMI signal input
@RESET
@ RJ45 signal output
@HDMI signal indicator led. It lights on all the
time with HDMI signal input, flashes with no
signal input.

3.2.RJ45 to HDMI

(j) ® @@
G) Network cable length adjust button. There are total 12
levels and can be switched cy clically. Supports memory
function and needs no setting after power off.
®
Rj45 signal input
@The first level netwok cable length LED ,if you need
the third level network cable length.please press
the button"LENGTH" twice when this LED lights on,
and so on.
@ Connection status indicator led. It lights on all the time
with HDMI signal transmission, flashes with no signal
transmission.
@DCSV power input
®
HDMI signal output
( J
•
@
@ @
@
@
