PITCH CONTROL (deck A)
It is possible to vary the tape speed in deck A in the range of
about ±10% in the playback mode. The center click position is
for the standard tape speed.

MULTI MUSIC SCAN

The multi music scan mechanism of this unit allows you to
quickly locate the beginning of a specific tune (up to 99 tunes
before or after the current tune).
The multi music scan mechanism functions by detecting non-
recorded sections between tunes (of more than 4–5 sec.).
The illustration shows the forward direction.
Example of fast forward scan.
PLAY
MUSIC SCAN
PLAY
Procedure
1. Press the
button during playback.
2. When more than 2 tunes are to be skipped, after procedure
1 press the
(or
want to skip tunes. The number of tunes to be skipped is
displayed in the counter.
Relation between Multi Music Scan and REVERSE MODE.
: The multi music scan mechanism operates on one
side of the tape only. If the number set is too high
(more than there are tunes remaining on that side),
the tape stops when the end of the tape is reached.
: It operates continuously through one cycle of the A
and B sides of the tape. If the number set has not
been reached, the tape stops at the end of the B
side. When the head rotates to play side A from B or
B from A, this rotation is counted as one non-
recorded section. When a recorded tune continues
from side A to B, this tune is recorded as two tunes.
In such a case, press the
extra time.
Notes:
In the following cases, the mechanism may not operate cor-
rectly. This is not a malfunction; use the mechanism according
to the type of program.
Tapes with tunes having long pianissimo passages (very quiet
parts) or non-recorded portions during tunes.
Tapes with short non-recorded sections.
) button the number of times you
(or
) button one

RECORDING

Deck B only
Operate in the order of the numbers in the illustration.
Make sure the safety tab of the cassette has not been broken
off.
It should be noted that it may be unlawful to re-record pre-
recorded tapes, records, or discs without the consent of the
owner of copyright in the sound or video recording, broadcast
or cable programme and in any literary, dramatic, musical, or
artistic work embodied therein.
1
POWER
ON
OFF
(B version)
2
3
DOLBY NR
B
C
6
COMPU CAL
8
INPUT LEVEL
INPUT LEVEL
5
5
4
4
6
6
3
3
7
2
2
8
1
1
9
MIN
MIN
MAX
MAX
1 Turn the power on.
2 Load a cassette for recording.
3 Press the DOLBY NR button to set to the required setting.
4 Press the REVERSE MODE button to set to the desired set-
ting.
5 Select the side to be recorded.
6 Press the COMPU CAL button, if required. (See page 9.)
7 Press the
PAUSE button and
(record-pause mode).
REC and
indicators light.
8 Adjust the recording level. (See page 10.)
9 Press to ''00 00''.
0 Press the PLAY button to start recording.
Notes:
When the safety tabs are removed from a cassette tape, the
tape cannot be recorded even if you try. Make sure that both
tabs are still in place when performing full recording.
– 8 –
STANDBY / ON
A
4
5
REVERSE
MODE
7
REC/REC MUTE PAUSE
9
0
COUNTER RESET
REC/REC MUTE button
POWER
(J version)
PLAY
