- Page 1 AC Power For Business-Critical Continuity™ Liebert ® ™ User Manual – 5-20kVA Modular UPS...
-
Page 3: Table Of Contents
TABLE OF CONTENTS ..........1 MPORTANT AFETY NSTRUCTIONS... - Page 4 Long Run Time (LRT) Battery Temperature Probe Terminals ..... . . 41 USB Port ..............41 ®...
- Page 5 User interface module............12 Figure 8 Liebert APS system control module and the system monitor module ..... . 12 Figure 9 Liebert APS power module .
- Page 6 Figure 40 Secure cables on cable bridges ........... . . 33 Figure 41 Wiring connections .
- Page 7 Specifications of Liebert APS external battery cabinet ....... . .
-
Page 9: Important Safety Instructions
Emerson Network Power representative or the Emerson Network Power Liebert Service Group. The Liebert APS UPS system is designed for use on a properly earthed (grounded) "TN" electrical supply, for installation by qualified personnel. A qualified electrician must review and approve... - Page 10 Operating this device in a residential area is likely to cause harmful interference that users must correct at their own expense. The Liebert APS complies with the requirements of EMC Directive 2004/108/EC and the published technical standards. Continued compliance requires installation in accordance with these instructions and use of accessories approved by Emerson.
-
Page 11: Glossary Of Symbols
Glossary of Symbols LOSSARY OF YMBOLS Risk of electrical shock Indicates caution followed by important instructions AC input AC output Requests the user to consult the manual Indicates the unit contains a valve-regulated lead acid battery PbH2SO4 Recycle DC voltage Equipment grounding conductor Bonded to ground AC voltage... -
Page 12: Product Introduction
Liebert APS UPS. System Description The Liebert APS power system is a modular UPS designed to provide high reliability. It is intended for use with workstations, servers, networks, telecoms and other sensitive electronic equipment. It provides continuous, high-quality AC power to your equipment, protecting it from any power disturbance due to blackouts, brownouts, surges or noise interference. -
Page 13: Figure 1 16-Bay Transformer-Free Ups
Product Introduction Figure 1 16-bay transformer-free UPS ® Liebert IntelliSlot Ports Power Input and System Control Manual Bypass Output Module (under Breaker (under Terminals cover) cover) System Dry Contacts User Enable and REPO Interface Switch Connections Module USB Port Bays for Output Power, Breaker... -
Page 14: Figure 3 12-Bay Transformer-Based Ups
Product Introduction Figure 3 12-bay transformer-based UPS Liebert IntelliSlot System Control Ports Module User Interface (under cover) Module System Enable Dry Contacts Switch and REPO Bays for Power, Connections Charger, or Battery Modules USB Port Bays for Battery Modules Ports for PODs External Battery Manual Bypass... -
Page 15: Figure 4 16-Bay Transformer-Based Ups
Product Introduction Figure 4 16-bay transformer-based UPS System Control Liebert Module ® IntelliSlot (under cover) Ports User Interface Module Dry Contacts System and REPO Enable Connections Switch Bays for Power, USB Port Charger or Battery Modules Battery Ports Module Bays Input Breaker Output... -
Page 16: Features
• Charger module: option for charging batteries and long run time applications • External battery cabinet: prolongs system run time Communications • Dry contacts • Liebert IntelliSlot communication ports • USB port Operating Principle The operating principle of the Liebert APS UPS is shown in Figure 5. ® ™ Liebert... -
Page 17: Figure 5 Operating Principle Diagram
Control Module Communication The Liebert APS UPS is composed of AC input, EMI filter, power module(s), battery module(s), user interface, control interface, system control module, output and bypass contactor, manual bypass, output transformer (certain frames only) and AC output. ®... -
Page 18: Operating Modes
Product Introduction Operating Modes The Liebert APS UPS is a true online double-conversion system, having the following operating modes: • Normal Mode • Backup Mode • Auto Restart Mode • Bypass Mode Normal Mode The power module rectifiers derive power from a utility AC source and supply regulated DC power to the inverter. -
Page 19: Major Components
Extending more than one module at a time could cause the unit to tip over. All UPS components are located in the Liebert APS frame. The front of the UPS consists of a series of plastic bezels. By grasping these bezels from the sides and pulling straight out, you can remove the bezel to reveal the battery/power module bays. -
Page 20: User Interface Module
Except for the silkscreen, the appearance of the system control module and the system monitor module is as shown in Figure 8. Figure 8 Liebert APS system control module and the system monitor module Handle Securing Hole... -
Page 21: Power Module
Product Introduction 1.5.4 Power Module The power module is shown in Figure 9. Figure 9 Liebert APS power module Green Status LED Yellow Fault LED Locking Lever FRONT VIEW Fastener Each power module is an independent 5kVA unit, consisting of a power factor corrected rectifier, battery charger and inverter, with associated monitoring and control circuitry. -
Page 22: Charger Module
The battery module strings work in parallel to provide longer backup time for the UPS. A Liebert APS can be configured with, at most, four external battery cabinets. An external battery cabinet is shown in Figure 12. -
Page 23: Installation
2.1.3 Installation Site Consider the weight and size of the Liebert APS when deciding where to install the unit. Verify that the floor can support the weight of a fully loaded unit, any accessories and external cabinets. Verify that the UPS will be in a well-ventilated area with at least 12 inches (305mm) clearance behind it. -
Page 24: Unloading The Ups
Installation Unloading the UPS The unit frame is bolted to the shipping pallet to ensure safety during shipping. Emerson recommends keeping the unit bolted to the pallet and using a pallet jack to transport the unit to its installation location. -
Page 25: Mechanical Installation
Installation Mechanical Installation Two installation modes are available for the Liebert APS UPS: tower installation and rack installation. 2.3.1 Tower Installation 1. Once the UPS is in the desired location, adjust the leveling feet to secure its position, as shown in Figure 16. -
Page 26: Rack Installation
2U space of all four rack posts. These cage nuts will secure the optional shelf that will support the weight of the Liebert APS. b. Install a cage nut in the middle square hole of 4U, 6U, 10U, 12U spaces, respectively, again in all four posts. -
Page 27: Figure 20 Install The Guide Rails
Detail D Bracket 6. Push the Liebert APS frame slowly into the enclosure from the front, as shown in Figure 22. The rear of the UPS goes into the rack first when installing through the front of the rack. ®... -
Page 28: Figure 22 Push The Ups Frame Into The Rack
Installation Figure 22 Push the UPS frame into the rack Front of Rack Front of UPS Push the UPS frame into the rack. Guide Rails 7. Use eight panel screws to secure the UPS frame to the rack posts, as shown in Figure 23. NOTE It might be necessary to use the leveling feet to get the holes to align Figure 23 Fix the UPS frame... -
Page 29: Figure 24 Install The Metal Plate
Installation Figure 24 Install the metal plate Square hole Metal Screw (2 places) Plate (4 places) Detail F 10. The installation is complete, as shown in Figure 25. Figure 25 Installation completed Bezel ® ™ Liebert... -
Page 30: Module Installation
Installation Module Installation The Liebert APS ships from the factory configured (modules prepopulated) and tested as a system to the customer’s requirements. If any modules were removed to facilitate ease of installation, follow the steps below to re-insert them properly. -
Page 31: Install System Control And System Monitor Modules
Installation Figure 27 Lever and fastener Locking Lever Pull Out Press Downward Before Pressing the Lever After Pressing the Lever Side View Side View NOTE If the lever of the module cannot be pressed down smoothly, remove the module and reinstall it. 4. -
Page 32: Figure 29 Insert The System Control And System Monitor Module
Installation Figure 29 Insert the System Control and System Monitor module 10mm Insert module here 3. Use a #2 Phillips screwdriver to install the screws into the holes on each end. 4. Slide the lever toward the right, as shown in Figure 30. Figure 30 Lever and fastener on System Control and System Monitor Module Mounting Hole... -
Page 33: Cable Connection
2.5.1 Transformer-Free UPS Cable Connection A junction box is factory-installed on each model of the Liebert APS to ease cable connection. Select the appropriate input cables according to Table 3 and Table 4 based on the UPS rating and mains frequency; however, it is recommended that you size the over current protection and wiring for the frame rating to easily allow upgrades to the UPS system. -
Page 34: Figure 31 Knockouts
Installation To connect the cable: NOTE Input and output cables must be run in separate conduit before cable connection. For the user whose input power grid is L-L line voltage, the input N of the power input and output terminals will connect live wire, so the output N of the power input and output terminals is also live wire. -
Page 35: Figure 33 Connection In 3-Phase Input
Installation Figure 33 Connection in 3-phase input OUTPUT INPUT 200/208/220/230/240 380/400/415 ® ™ Liebert... -
Page 36: Transformer-Based Ups Cable Connection
The UPS grounding should be in accordance with local regulations. A junction box is factory-installed on all models of the Liebert APS to ease cable connection. Select the appropriate input cables according to Table 5 and Table 6 based upon the UPS rating and mains frequency. -
Page 37: Figure 34 Setting Bypass Voltage Jumper (Default: 208Vac)
Installation Configuring the Bypass Voltage The UPS bypass voltage is factory-set to 208V (the jumper copper bar has been installed). Should the user have a utility supply of 200V/220V/230V/240V, the bypass voltage jumper must be changed to ensure correct output voltages when in bypass mode. Configuring the bypass voltage jumper settings are shown in Figures 34 and 35. -
Page 38: Figure 36 Configuring The Neutral/Earth Jumper
Installation Configuring the Neutral/Earth Jumper The UPS contains an isolation transformer that generates a neutral conductor for the connected load. The UPS is a separately derived source and contains a neutral/earth jumper. A factory-installed neutral/earth jumper copper bar may require removal to comply with local codes and regulations. Figure 36 Configuring the neutral/earth jumper Neutral/Earth Jumper Connecting Cables... -
Page 39: Figure 38 Connection Method
Installation Figure 38 Connection method Refer to Table 6 for configuring the output cable. For standard voltages, make the connections shown in Table 7. Table 7 Configuration list for output cables Bypass Voltage Jumper Output Voltage (Between Terminals) Set Output Output Voltage 208V TAP... -
Page 40: Transformer-Free Ups-Dual Inverter Frames
2.5.3 Transformer-Free UPS—Dual Inverter Frames A junction box is factory-installed on all models of the Liebert APS to ease cable connection. Select the appropriate input cables according to Tables 9 and 10 based on the UPS rating and mains frequency. Emerson recommends sizing the overcurrent protection and wiring for the frame rating for easing upgrades to the UPS system. -
Page 41: Figure 40 Secure Cables On Cable Bridges
Installation 4. Respectively secure the input/output cables through the cable bridges on the rear panel of the UPS (see Figure 40). Figure 40 Secure cables on cable bridges The connections for the single-phase input mode and the 3-phase input mode are shown in Figure 32 and Figure 33, respectively. -
Page 42: Connecting External Battery Cabinet
Installation 2.5.4 Connecting External Battery Cabinet Up to four external battery cabinets may be connected to the Liebert APS to provide longer battery run times. An external battery cabinet contains a standard battery cable and a communication cable, each 1meter (39in) long. They are used to connect UPS and the external battery cabinet. Optional cables of 3 and 5 meters can be provided if the battery cabinets must be located some distance from the UPS cabinet. -
Page 43: Figure 43 Connecting External Battery Cabinet (Transformer-Based Ups)
Figure 43 Connecting external battery cabinet (transformer-based UPS) Communication Cable Battery Cable Liebert APS Battery Cabinet After connecting the external battery cabinet, use the user interface to determine the number of external battery cabinets, as shown in Figure 44. Figure 44 Battery screen... -
Page 44: Connecting Integrated Power Output Distribution (Pod)
UPS output voltage is set to 220/127V. 5. Secure the POD by using the two screws removed in Step 2. 6. Repeat Steps 1 through 5 to install a second POD on the Liebert APS (only the 16-bay frame has two POD ports). - Page 45 If using the integral distribution PODs on the UPS or MBC, verify that the individual POD breakers are closed. 6. Emerson recommends closing the UPS input breaker; it is on the front of transformer-free frame systems and on the rear of transformer-based frame systems. If AC mains becomes available, the UPS will revert to AC power mode and begin recharging the battery.
-
Page 46: Communication
Liebert IntelliSlot Ports (with protective covers) Liebert IntelliSlot Unity Cards—IS-UNITY-LIFE, IS-UNITY-S, IS-UNITY-DP • IS-UNITY-LIFE: This card is standard in every Liebert APS. It is used for communication between the Liebert APS UPS and Emerson’s Trellis ® NMS and LIFE Services. -
Page 47: Dry Contact Ports
Provides dry contact alarm information, including: On Battery, Low Battery signals for communication to four servers for use with Liebert MultiLink software. Liebert IntelliSlot EBC Card This card is used for the Liebert APS UPS to monitor and manage the intelligent battery modules in external matching battery cabinets. Dry Contact Ports The UPS provides dry contact ports. -
Page 48: Repo (Remote Emergency Power Off)
REPO (Remote Emergency Power Off) The Liebert APS is equipped with a REPO (Remote Emergency Power Off) connection. Only the SELV (Safety Extra Low Voltage) circuit can be connected to the REPO terminal block. Figure 48 shows the REPO connection pin layout. -
Page 49: Long Run Time (Lrt) Battery Temperature Probe Terminals
Locate battery temperature signal at UPS remote end USB Port The Liebert APS UPS contains a standard B type USB port on the rear of the unit to connect the UPS to a network server or other computer for monitoring using any operating system, built-in UPS support or in conjunction with Liebert MultiLink ®... -
Page 50: Liebert Multilink
The LCD module contains the LCD port, which is used for power and data communication between the UPS monitor module and display module. The LCD module can be removed from the Liebert APS and remotely located. A longer Ethernet cable must be used when installing the LCD module remotely. -
Page 51: Operation And Display Panel
Operation and Display Panel PERATION AND ISPLAY ANEL Overview This chapter describes the functions and operation of the UPS display panel. The LCD is composed of an LED mimic power flow diagram, fault LED indicator and LCD screen to show detailed operational information and UPS alarm list using the navigation buttons. -
Page 52: Figure 52 User Interface Module Layout
Operation and Display Panel Audible Alarms Three different audible alarms may occur during the UPS operation; see Table 16 for a description of the audible alarms. Table 16 Audible alarm descriptions Alarm sound Meaning One beep per second When the UPS has an alarm, for example, AC fault (mains failure) One beep every 0.5 second Upon UPS output overload or low battery voltage alarm during discharge Continuous beep... -
Page 53: Lcd Screen
See Table 19 for the detailed description. Table 19 Item description of system information window Item Description Liebert APS UPS name, representing Liebert APS 2012-01-01 Current time (format: year-month-date) 10: 45: 20 (format: 24 hours, h: m: s) ®... -
Page 54: Table 20 Item Description Of Menu Window And Data Window
Operation and Display Panel Menu Window and Data Window The menu window shows the menu name and allows navigation to different menu items. Each menu item has a set of data that is displayed in the data window. Using the menu window, you can browse the relevant parameters of the UPS and can adjust/set some operational parameters. - Page 55 Operation and Display Panel Table 20 Item description of menu window and data window (continued) Menu Name Data Item Data Description Disabled/ Enabled. If ‘Enabled,’ the system operational parameters will assume there is a redundant power module in the frame; if ‘Disabled’, the Redundancy system operational parameters will assume that all power modules in the frame are not redundant.
- Page 56 Operation and Display Panel Table 20 Item description of menu window and data window (continued) Menu Name Data Item Data Description Load factory Restore all settings in ‘Settings’ menu back to factory default values default Communication Sets the UPS device address. This setting is only for the network card Address communication of newly emerging market.
-
Page 57: Table 21 Function Descriptions Of Menu Buttons
Operation and Display Panel Table 20 Item description of menu window and data window (continued) Menu Name Data Item Data Description Battery maintenance test allows battery to discharge some voltage to Battery obtain the battery activity. The loads must be within 0% ~ 90%, the battery Maintenance Test capacity must be larger than 70%, and there is no battery fault and alarm in the system. -
Page 58: Default Screen/Screen Saver
Operation and Display Panel 4.2.3 Default Screen/Screen Saver During the UPS operating process, if there are no active alarms, the LCD will go into a screen saver mode after 2 minutes of no user navigation activity. The default screen saver is shown in Figure 55. After a brief delay, the LCD backlight will also turn Off. -
Page 59: Battery Screen
From the main screen, press the F3 button once and the battery screen will be displayed, as shown in Figure 57. Figure 57 Battery screens 2014 -01-01 2014 -01-01 Liebert APS Liebert APS 10:45:20 10:45:20 Batt voltage (V) 157 .0 Batt current (A) 0.03... -
Page 60: Load Screen
Operation and Display Panel 4.3.4 Load Screen From the main screen, press the F4 button once and the load screen will be displayed, as shown in Figure 59. Figure 59 Load screen The load screen displays output kVA (Sout/apparent power), output kW (Pout/active power), load level and crest factor. -
Page 61: Redundancy Screen
Operation and Display Panel 4.3.6 Redundancy Screen From the main screen, press the F4 button three times until the redundancy screen is displayed, as shown in Figure 61. Figure 61 Redundancy screen The redundant screen displays the number of installed power modules in the frame, and whether the system contains a redundant module or not. -
Page 62: Settings Screen
Operation and Display Panel 4.3.7 Settings Screen From the main screen, press the F4 button four times until the settings screen is displayed. The settings screen is displayed in a total of nine screens as you scroll down, as shown in Figure 62. Figure 62 Settings screens First Screen Second Screen... -
Page 63: Entering A Password
Operation and Display Panel Figure 63 Settings screens, (continued) Seventh Screen Eighth Screen Ninth Screen On the first settings screen, pressing the F5 button will prompt a password window to pop up. After you enter the correct password, the function of the F2, F3, and F4 buttons will switch from the primary functions to the secondary functions, as shown above in Table 21. -
Page 64: Battery Setting Screen
Operation and Display Panel 4.5.1 Battery Setting Screen From the main screen, press the F4 button five times until the battery settings screen is displayed, as shown in Figure 64. Figure 64 Battery settings screens First Screen Second Screen On the first settings screen, pressing the F5 button will prompt a password window to pop up. After you enter the correct password, the function of the F2, F3, and F4 buttons will switch from the primary functions to the secondary functions as shown above in Table 21. -
Page 65: Alarms Screen
Operation and Display Panel 4.5.3 Alarms Screen From the main screen, press the F4 button seven times until the alarms screen is displayed, as shown in Figure 66. Figure 66 Alarms screen The alarms screen displays any current alarms of the UPS, including the alarm name, alarm ID code and alarm date/time stamp. -
Page 66: Module Replacement Screen
Operation and Display Panel 4.5.5 Module Replacement Screen From the main screen, press the F4 button nine times until the module replacement screen is displayed, as shown in Figure 68. Figure 68 Module replacement screen Module Replacement Screen LCD Board Replacement Procedures The module replacement screen displays the procedures for replacing all user replaceable module assemblies in the UPS frame. -
Page 67: Table 22 Information And Actions Required For The Prompt Window
Operation and Display Panel Table 22 Information and actions required for the prompt window Prompt Window Description/Action Required Turn On the UPS or cancel Press the ON/OFF-button while UPS is off Turn On the Inverter or Turn Off Press the ON/OFF-button while UPS is operating in bypass mode the output Press the ON/OFF-button while UPS is operating in inverter mode and bypass Turn Off the Inverter or cancel... -
Page 68: Troubleshooting
Troubleshooting ROUBLESHOOTING This chapter provides the basic troubleshooting guide and required actions for maintaining the Liebert APS system. Active Alarms In the event of an alarm, the User Interface LCD will display the latest alarm message. A list of possible alarm messages are displayed in Table 23. If an alarm occurs and you are uncertain of the corrective action to take, contact your local Liebert Service representative. - Page 69 Troubleshooting Table 23 Alarm message list (continued) Possible Cause Corrective Action Alarm Message Have a qualified electrician check the wiring rotation at the external battery Battery Reversed The battery is reversely connected. cabinet. If this is not the problem, contact your local Liebert Service representative.
- Page 70 Troubleshooting Table 23 Alarm message list (continued) Possible Cause Corrective Action Alarm Message Check upstream feeder breaker or the UPS input breaker and reset if The battery capacity has reached the necessary.If this is not the problem, Low Battery Warning user programmable set point.
-
Page 71: Module Troubleshooting
Troubleshooting Table 23 Alarm message list (continued) Possible Cause Corrective Action Alarm Message Check the locking lever to ensure it is Charger Module LOCK Lever The locking lever is not in the locked fully inserted. If so, contact your local in Remove Position position. -
Page 72: Module Replacement
Troubleshooting Module Replacement Follow the instructions below when replacing or adding a system control, system monitor, power, battery, or charger module. Contact your local Liebert representative if you need to purchase additional modules to expand your system or contact authorized Liebert service representative for replacement modules. -
Page 73: Figure 72 Pull Out A Battery Module, A Power Module Or A Charge Module
Troubleshooting Figure 72 Pull out a battery module, a power module or a charge module Step 3 Step 3 Step 3 WARNING Risk of heavy unit falling over. Can cause equipment damage, injury or death. Read all of the instructions before attempting to move the unit, lift it, remove packaging or prepare the unit for installation. -
Page 74: Replacing The User Interface Module
Troubleshooting 5.3.2 Replacing the User Interface Module 1. Remove the display bezel on top of the frame. 2. Lift up the user interface module, and put it on top of the UPS frame. 3. Disconnect the network cable from the user interface module. 4. -
Page 75: Maintenance
Proper Care Proper maintenance of the UPS is imperative to optimal performance and life of the unit. Emerson recommends that a certified technician perform preventive and corrective maintenance. Emerson Network Power Liebert Services is dedicated to ensuring the highest level of performance and unmatched support for your UPS. -
Page 76: Bezel Filter
Maintenance 6.3.2 Bezel Filter 1. Remove the bezel from the frame. 2. Remove the filter assembly from the bezel, as shown in Figure 75, and clean the filters as described above. 3. Restore the filter and small plastic bezel of the frame. Figure 75 Replace/clean the bezel filter 6.3.3 Bottom Fan Filter—Transformer-Based Frames Only... -
Page 77: Specifications
Specifications PECIFICATIONS Table 25 Liebert APS specifications 10 Bay 16 Bay 12 Bay 16 Bay 10 Bay 16 Bay No Transformer Unit Size, Type No Transformer Transformer-based Dual Inverter Frame Rating, kVA/kW 15/13.5 20/18 15/13.5 20/18 15/13.5 20/18 General & Environmental... -
Page 78: Table 26 Rated Input Voltage Range (Unit: Vac)
Specifications Table 25 Liebert APS specifications (continued) 10 Bay 16 Bay 12 Bay 16 Bay 10 Bay 16 Bay No Transformer Unit Size, Type No Transformer Transformer-based Dual Inverter Frame Rating, kVA/kW 15/13.5 20/18 15/13.5 20/18 15/13.5 20/18 Battery Module... -
Page 79: Table 27 Specifications Of Liebert Aps External Battery Cabinet
Specifications Table 27 Specifications of Liebert APS external battery cabinet Parameters AS7EBCNCC1BX000 General and Environmental Conducted and Radiated EMC Levels IEC/EN/AS 62040-2—Class A, FCC Part 15 (Class A) Safety Standards IEC/EN/AS 62040-1:2008, UL 1778 4th Ed and CSA 22.2 No. 107.3... -
Page 80: Estimated Battery Run Times
Specifications Estimated Battery Run Times 7.1.1 Tables for UPS Where Model Number Digits 1-3 are AS1 or ASA ® ™ Liebert... -
Page 81: Table 29 10-Bay, Single-Phase, No Transformer Unit Type N (& Ups Model Number Digit 6 = N)
Specifications ® ™ Liebert... -
Page 82: Table 30 10-Bay, Single-Phase, No Transformer Unit Type R (& Ups Model Number Digit 6 = R)
Specifications ® ™ Liebert... -
Page 83: Table 31 10-Bay, Single-Phase, No Transformer Unit Type B (& Ups Model Number Digit 6 = B)
Specifications ® ™ Liebert... -
Page 84: Table 32 10-Bay, Single-Phase, No Transformer Unit Type F (& Ups Model Number Digit 6 = F)
Specifications ® ™ Liebert... -
Page 85: Estimated Battery Run Times
Specifications Estimated Battery Run Times 7.2.1 Tables for UPS Model Number Where Digits 1-3 are AS2 or ASB ® ™ Liebert... -
Page 86: Table 34 16-Bay, Single-Phase, No Transformer Unit Type R (& Ups Model Number Digit 6 = R)
Specifications ® ™ Liebert... -
Page 87: Table 35 16-Bay, Single-Phase, No Transformer Unit Type B (& Ups Model Number Digit 6 = B)
Specifications ® ™ Liebert... -
Page 88: Table 36 16-Bay, Single-Phase, No Transformer Unit Type F (& Ups Model Number Digit 6 = F)
Specifications ® ™ Liebert... -
Page 89: Estimated Battery Run Times
Specifications Estimated Battery Run Times 7.3.1 Tables for UPS model number digits 1-3 are AS3 or ASC ® ™ Liebert... -
Page 90: Table 38 12-Bay, Single-Phase, Transformer-Based Unit Type R (& Ups Model Number 6 = R)
Specifications ® ™ Liebert... -
Page 91: Table 39 12-Bay, Single-Phase, Transformer-Based Unit Type B (& Ups Model Number 6 = B)
Specifications ® ™ Liebert... -
Page 92: Table 40 12-Bay, Single-Phase, Transformer-Based Unit Type F (& Ups Model Number 6 = F)
Specifications ® ™ Liebert... -
Page 93: Estimated Battery Run Times
Specifications Estimated Battery Run Times 7.4.1 Tables for UPS Model Number Where Digits 1-3 are AS4 or ASD ® ™ Liebert... -
Page 94: Table 42 16-Bay, Single-Phase, Transformer-Based Unit Type R (& Ups Model Number 6 = R)
Specifications ® ™ Liebert... -
Page 95: Table 43 16-Bay, Single-Phase, Transformer-Based Unit Type B (& Ups Model Number 6 = B)
Specifications ® ™ Liebert... -
Page 96: Table 44 16-Bay, Single-Phase, Transformer-Based Unit Type F (& Ups Model Number 6 = F)
Specifications ® ™ Liebert... -
Page 97: Estimated Battery Run Times
Specifications Estimated Battery Run Times 7.5.1 Tables for UPS Model Number Where Digits 1-3 are AS5 or ASE ® ™ Liebert... -
Page 98: Table 46 10-Bay, Two-Phase, No Transformer Unit Type R (& Ups Model Number 6 = R)
Specifications ® ™ Liebert... -
Page 99: Table 47 10-Bay, Two-Phase, No Transformer Unit Type B (& Ups Model Number 6 = B)
Specifications ® ™ Liebert... -
Page 100: Table 48 10-Bay, Two-Phase, No Transformer Unit Type F (& Ups Model Number 6 = F)
Specifications ® ™ Liebert... - Page 101 Specifications NOTES ® ™ Liebert...
- Page 102 Specifications ® ™ Liebert...
