SURFACE MOUNT INSTALLATION INSTRUCTIONS*
Use the camera's mounting
1
template or your camera to
mark the holes as required.
Mount the surface mount
4
base (junction box) to the
wall.
8
Drill holes into the drywall and
2
insert the drywall mounts into
the holes.
Route wiring behind
the inner posts
(dark gray area).
Pull wires through and make
3
connections.
If you need to keep the wiring within the
camera housing, refer to the diagram
below.
To use the side conduit, remove the
security screw with the supplied
3.0mm Allen key, and unscrew the
conduit plug.
