3Com SuperStack II User Manual page 47

Table 11 Flex-WAN Cables
Cable
Length Cable Type
4 ft. RS-232 DTE (straight-through cable to connect to a DCE)
RS-232 DCE (crossover cable to connect to a DTE)
V.35 DTE (straight-through cable to connect to a DCE)
V.35 DCE (crossover cable to connect to a DTE)
X.21 DTE (straight-through cable to connect to a DCE)
X.21 DCE (crossover cable to connect to a DTE)
RS-449 DTE (straight-through cable to connect to a DCE)
RS-449 DCE (crossover cable to connect to a DTE)
RS-530 DTE (straight-through cable to connect to a DCE)
V.35 extended shroud DTE (straight-through cable to connect to a DCE)
V.35 extended shroud DCE (crossover cable to connect to a DTE)
10 ft. RS-232 DTE (straight-through cable to connect to a DCE)
RS-232 DCE (crossover cable to connect to a DTE)
V.35 DTE (straight-through cable to connect to a DCE)
V.35 DCE (crossover cable to connect to a DTE)
X.21 DTE (straight-through cable to connect to a DCE)
X.21 DCE (crossover cable to connect to a DTE)
RS-449 DTE (straight-through cable to connect to a DCE)
RS-449 DCE (crossover cable to connect to a DTE)
RS-530 DTE (straight-through cable to connect to a DCE)
V.35 extended shroud DTE (straight-through cable to connect to a DCE)
V.35 extended shroud DCE (crossover cable to connect to a DTE)
* The V.35 extended shroud cable is required for some equipment, particularly IBM legacy equipment.
Flex-WAN cables can be purchased from 3Com. Table 11 lists each
Flex-WAN cable and part number. Cable pinouts are provided in the
following sections.
Serial Connectors and Flex-WAN Cables
Part Number
3C89002
3C89004
3C89006
3C89008
3C89010
3C890012
3C890014
3C890016
3C890018
* 3C890020
* 3C89022
3C89001
3C89003
3C89005
3C89007
3C89009
3C890011
3C890013
3C890015
3C890017
*
3C890019
*
3C890021
47
Pinouts
page 48
page 49
page 50
page 51
page 52
page 53
page 54
page 55
page 55
page 50
page 51
page 48
page 49
page 50
page 51
page 52
page 53
page 54
page 55
page 55
page 50
page 51
