28 C 3: F
HAPTER EATURES AND
Back and Front
Panels
Power
receptacle
S
PECIFICATIONS
Table 6 Features of the SuperStack II NETBuilder SI Bridge/Router (continued)
Feature
Memory
Serial ports
Boundary routers
(model 4xx only)
Figure 3 shows the back panel of the SuperStack II bridge/router.
Figure 3 Back Panel
On/off
switch
RPS
connector
Figure 4 shows the front panel of the model 4xx bridge/router and the
model 5xx bridge/router.
Description
8 MB flash memory and 16 MB DRAM.
Two (model 4xx) or four (model 5xx) Flex-WAN
serial ports that can connect to RS-232, V.35,
RS-449, X.21, or RS-530 interfaces. See "Serial
Connectors and Flex-WAN Cables" on page 45 for
information about Flex-WAN cables.
One active serial or WAN port. The remaining two
ports can be used for back-up.
MODEL: xxxxxxx
S/N:
NETBUILDER
1SC05427
xxxxxx
xxx 8.3
NTWK
080002 04BA1E LAN
100-240VAC, 50/60HZ, 1.0-0.5A
04BA1F WAN-A
ADDR:
04BA20 WAN-B
250V, F2A
04BA21 WAN-C
FOR CONTINUED PROTECTION
AGAINST FIRE HAZARD
REPLACE FUSE ONY WITH
20-0261-000
SAME TYPE AND RATING 07/31/95
3COM CORP. SANTA CLARA, CA. MADE IN USA
Product
information label
