CONTROLS & FEATURES
CONTROLS & FEATURES
(Models AK2500, AK2536)
2 Cycle Speed Selection
3 Delay Off
Delay Off Indication
1 Blower On/Off
By pressing , the blower is turned On and Off.
2
Cycle Speed Selection
Cycle through 3 speed levels by pressing
3
Delay Off
This switch is used for programmed shut down of blower and lights 5 minutes after the function is
activated. Press once, the flashing indicator to the left indicates the function is on. The hood
will completely shut down in 5 minutes.
4
Cycle Lights On/Dim/Off
Switch lights On by selecting this switch. To Dim lights, activate
one more time, will turn lights Off
CONTROLS & FEATURES
(Models AK6500, AK6536, AK6542)
1 Blower On/Off/Speed Selection
0 I II III
1 Blower On/Off/Speed Selection
This switch turns the blower on and off and controls the speed selection. 0 is off, I is low speed,
II is medium speed and III is high speed.
2
Lights On/Off
Turn lights on I or off 0 with this switch.
4 Cycle Lights On/Dim/Off
1 Blower On/Off
I II
III
3 Speed Level Indication
, the display indicates level selected.
again. Selecting
2 Lights On/Off
I I I 0
Models: AK6500, AK6536, AK6542, AK2500, AK2536 Page 8

CLEANING AND MAINTENANCE

SELF CLEAN FEATURE
Using Self Cleaning:
WARNING: Use only non-corrosive & non-abrasive
grease cutting detergents.
DO NOT USE OVEN CLEANERS.
Models AK6500, AK6536, AK6542, AK2500, AK2536 hoods are designed with a self cleaning feature.
The centrifugal blower system automatically liquefies cooking residue accumulated in its internal
housing, and deposits the residue in the cleaning cup. Nevertheless, grease from cooking can also
dry and adhere in the internal housing. Running the self clean function periodically will flush out
accumulated residue in the range hood's internal housing.
Cleaning Frequency:
Cleaning should be completed approximately once a month under normal use.
Detergent:
Non-corrosive, non-abrasive grease cutting spray detergents are recommended.
Self Clean:
Turn blower on lowest speed for cleaning.
With nozzle on 'spray', squirt the grease cutting
detergent through the safety grill,directly onto
blower blades 10-15 times.
Allow self cleaning to complete for 5 minutes,
turn blower off.
Remove cleaning cup. Clean w/ mild detergent
or in dishwasher under normal wash cycle.
(If desired, repeat above steps with water
to rinse out detergent)
Models: AK6500, AK6536, AK6542, AK2500, AK2536 Page 9
