Features & Controls - Zephyr AK9358BS Use, Care And Installation Manual

ZEPHYRONLINE.COM
Touch Controls
1. Blower On/O
By pressing the blower is switched on and o . When switched on, the blower starts up on speed level 1.
ACT Verification
- Airflow Control Technology (ACT) allows the installer to set the maximum blower CFM to align with local
codes and regulations.
- To verify the maximum blower CFM:
- With hood o , hold the
number 3 displays = max. 590 CFM, and if number 2 displays = max. 390 CFM.
2. Speed Selection
- Press to decrease fan speed. 6, 5, 4, 3, 2, 1.
- If fan is on Speed 1 and
- Press to increase fan speed. Fan On, 1, 2, 3, 4, 5, 6.
- If hood is o and
ACT Enabled Speed Selections
- When ACT is enabled, the number of blower speeds will be reduced as follows:
- 590 CFM = Maximum 3 speeds
- 390 CFM = Maximum 2 speeds
3. Delay O
This feature is used for programmed shut down of blower 5 minutes after the function is activated. Press
once, a dot flashes
completely shut down after 5 minutes.
4. Lights Low/High/O
Switch lights on to low by pressing
5. Display Window
The display window indicates speed levels and features such as ba e filter clean reminder, delay o and
clean air indicator.
Monsoon II Use, Care, and Installation Guide
1
Blower On/O
Display (speed level, delay o , filter clean)
5
2 Adjust 6 Speed Levels
button for 3-4 seconds. If number 6 displays = default max. CFM, if
is pressed, the fan will power o .
is pressed, the fan will turn on speed 1.
in the lower right side of display
once, press a second time for high and again to shut o lights.
Features & Controls
4 Lights Low/High/O
3 5 Min Delay O
indicating the function is on. The blower will
