- Page 1 ECO300K ECO300KS ECO400K ECO400KS Int. Service (+49) 6838/907 172 für Service 06838/907 172 for service (+44) 0845 602 4285 pour service 03 87 95 39 28 voor service 020 684 7978 pro pouÏití v CZ & SK zur Verwendung in der EU...
-
Page 2: Table Of Contents
Electrical Installation + electronic Gate stops: control: Page 3, figure Page 2, figure Security: Page 4 CONTENT OF THE CARTON ECO300KS/ECO400KS CONTENT OF THE CARTON ECO300K/ECO400K (1) Motor (1) Motor 2x (2) Electronic Control (2) Electronic Control (3) Postbracket (3) Postbracket 2x... -
Page 3: Before You Begin
GATE CONFIGURATION BEFORE YOU BEGIN The drive mechanism needs room to the side permitting How far must the gate wing open? correct installation of drive arms. Please make sure that this 90 degrees or up to 115 degrees. An opening angle in excess is available. -
Page 4: Maintenance Work
GATE FITTING ELECTRONIC CONTROL The control board should be the last item to be connected, i.e. The gate fitting must be installed so that it is horizontal mounting the motors, laying the necessary cable and fitting relative to the post bracket. The distance between the gate light barriers or contact strips. -
Page 5: Infrared Sensor
SAFETY OVERVIEW OF CONNECTIONS FLASHING LAMP (OPTIONAL) Description of terminal occupancy Usage of a flashing lamp is mandatory. It serves a safety-related Mains cable connection: purpose in that it warns persons in the vicinity of the gate/door Terminal 1 N (blue) that the given gate/door is moving. - Page 6 ANTENNA (OPTIONAL) DESCRIPTION OF LEDS An external antenna is not a mandatory requirement. A short LED 1 Monitors the light barrier for door closing. antenna is located on the control unit's radio adapter. Should LED ON = OK the range of the remote control need to be extended, fit an LED 2 Monitors the light barrier for door opening external antenna compatible with 433 MHz (the ANT4X-1LM...
-
Page 7: Initial Operation
D e c l a r a t i o n o f I n c o r p o r a t i o n button before making any further settings. Automatic Gate Opener Models ECO300K/300KS/400K/400KS, when installed and maintained according to all the Manufacturer’s instructions in 9. - Page 8 EU HU, RU, BG országokban való használatra Za uporabu u Hrvatskoj i Slovaçkoj per l'uso nell'UE voor gebruik in de EEG www.liftmaster.com Para ser utilizado na UE fdo u˝ytku w PL Email: info@chamberlain.com для исп. в РФ...
- Page 9 OPTIONAL FLA230-2 OPTIONAL ANT4X - 1LM OPTIONAL FLA230-2 OPTIONAL ANT4X - 1LM...
- Page 11 max.3,5m (ECO400) oder max.2,5m (ECO300)
- Page 12 ECO300/300S A=15cm =ca. 90 B=15cm ECO400/400S 87/118 A=19cm B=19cm =ca. 90...
- Page 13 = 90 = 90...
- Page 14 6x50...
- Page 15 10 A 11 A...
- Page 16 12 A 6,3 yF 6,3 yF Optional...
- Page 18 13 A 2 3 0 V / 50 Hz 14 A Standard Optional 14 B 14 C NC C NO...
- Page 19 14 D Standart = 1x Aktiv 10 11 12 13 13 14 14 1 1 19 20 20 21 21 22 min 0,5 mm m 24V~ 24V~ NC C Optional = 2x Aktiv 10 11 12 13 14 1 19 20 21 22 min 0,5 24V~ 24V~...
- Page 20 14 F Optional = 4x 2x Aktiv + 2x Aktiv 10 11 19 20 21 22 min 0,5 m m m ,5 m 24V~ 24V~ 24V~ 24V~ NC C 24V~ 24V~ 24V~ 24V~ 15 A 709223 © Chamberlain GmbH, 2003...
