OPERATION AND MAINTENANCE MANUAL
106 MODEL B SUPER DUTY RATCHET WRENCH
IMPORTANT SAFETY INFORMATION ENCLOSED.
READ THIS MANUAL BEFORE OPERATING TOOL.
FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD RESULT IN INJURY.
Always operate, inspect and maintain this tool in
accordance with American National Standards
Institute Safety Code for Portable Air Tools
(ANSI B186.1).
For safety, top performance and maximum dura-
bility of parts, operate this tool at 90 psig
(6.2 bar/620 kPa) maximum air pressure at the
inlet with 3/8" (10 mm) inside diameter air supply
hose.
Air powered tools can vibrate in use. Vibration,
repetitive motions or uncomfortable positions may
be harmful to your hands and arms. Stop using
any tool if discomfort, tingling feeling or pain oc-
curs. Seek medical advice before resuming use.
Always turn off the air supply and disconnect the
air supply hose before installing, removing or
The use of other than genuine Ingersoll–Rand replacement parts may result in safety hazards, decreased tool perfor-
mance and increased maintenance, and may invalidate all warranties.
Ingersoll–Rand is not responsible for customer modification of tools for applications on which Ingersoll–Rand was not
consulted.
Repairs should be made only by authorized trained personnel. Consult your nearest Ingersoll–Rand Authorized Servi-
center.
It is the responsibility of the employer to place the information in this manual into the hands of the operator.
Refer All Communications to the Nearest
Ingersoll–Rand Office or Distributor.
E Ingersoll–Rand Company 1994
Printed in U.S.A.
for
TPB1714
adjusting any accessory on this tool, or before per-
forming any maintenance on this tool.
Keep hands, loose clothing and long hair away
from rotating end of tool.
Anticipate and be alert for sudden changes in mo-
tion during start up and operation of any power
tool.
Tool accessory may continue to rotate briefly after
throttle is released.
Do not lubricate tools with flammable or volatile
liquids such as kerosene, diesel or jet fuel.
Do not remove any labels. Replace any damaged
label.
Use accessories recommended by Ingersoll–Rand.
Use only impact sockets and accessories. Do not
use hand (chrome) sockets or accessories.
03537016
Form P6878
Edition 4
February, 1994

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 106 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ingersoll-Rand 106

  • Page 1 03537016 Form P6878 Edition 4 February, 1994 OPERATION AND MAINTENANCE MANUAL 106 MODEL B SUPER DUTY RATCHET WRENCH TPB1714 IMPORTANT SAFETY INFORMATION ENCLOSED. READ THIS MANUAL BEFORE OPERATING TOOL. FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD RESULT IN INJURY. Always operate, inspect and maintain this tool in...
  • Page 2: Warning Label Identification

    WARNING LABEL IDENTIFICATION FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD RESULT IN INJURY.
  • Page 3: Installation

    The filter removes dust and moisture. The 106 Model A Ratchet Wrench is designed for muffler and shock absorber work, replacement of water pumps, radiators and air conditioning units and general automotive repair.
  • Page 4 (Dwg. TPB839)
  • Page 5 Ratchet Pawl ..... . . 106–43A Rotor ....... 106–53 Ratchet Anvil .
  • Page 6: Maintenance Section

    7. Using a thin bladed screwdriver, push out the Pawl Retaining Pin (49) and remove the Ratchet Pawl (42). Each time a 106 Model B Ratchet Wrench is disassembled 8. Using a pair of needle nose pliers, remove the Ratchet...
  • Page 7 MAINTENANCE SECTION 3. Whenever grasping a tool or part in a vise, always use 13. Using a pair of snap ring pliers, insert the Anvil Re- leather–covered or copper–covered vise jaws. Take taining Ring (47) in the groove in the Ratchet Head. If extra care with threaded parts and housings.
  • Page 8: Troubleshooting Guide

    MAINTENANCE SECTION 12. Slide the Rotor Pinion Spacer (22) onto the splined 16. Slide the Ring Gear Spacer (25) into the Motor hub of the Rotor until it contacts the Front Rotor Housing until it contacts the Ring Gear. Bearing. 17.
  • Page 9 NOTES...
  • Page 10 NOTES...
  • Page 11 NOTES...
