Service Manual
Steps
7.Remove axial flow blade
Remove the nut
thenremove the axial
8.Remove motor and motor support
Remove the 4 tapping screws
the motor.Pull out the lead-out wire and
remove themotor. Remove the 2 tapping
screws
support to re-move it.
9.Remove clapboard sub-assy
Loosen the screws of the clapboard sub-
assy .The clapboard sub-assy has a
hook on thelower side. Lift and pull the
clapboard sub-assy to remove.
Installation and Maintenance
the blade and
blade.
motor support. Lift motor
Procedure
axial blade
motor support
motor
clapboard sub-assy
65
