Summary of Contents for Quietside QSCE-093
-
Page 15: Safety Instructions
Report all Shipping Damage to Carrier IMMEDIATELY, Check units and box exterior for damage Note to Installer This manual to is to aid the qualified HVAC contractor in the Installation and Maintenance of this Quietside R410a Ductless Mini Split Please read and understand these instructions prior to installing the unit, failure to comply with these... - Page 16 Ensure that all panels can be removed for service as required Certification All Quietside Ductless Mini Splits are certified by UL under UL standard 1995 in both Canada and the US Performance is certified by our certification under the ARI 210/240 Program...
-
Page 17: Unit Installation
Low Ambient Controller : ICM 326H must be used in Data Room or Commercial applications For a wiring diagram please contact Quietside or follow general diagram supplied with ICM Controller Probe must be located in the fin pack or on a return bend that measures approx 100 DegF during normal... - Page 18 Installation and Maintenance Manual Unit Installation (Cont) Step3 Drill Hole for Line Set etc Remove mounting bracket from the rear of the Indoor unit, then use a Phillips head screwdriver to remove the unit pipe strap, and if unit is a heat pump the defrost sensor also must be taken from the retainer so that it can be connected to the Outdoor unit.
- Page 19 DO NOT INSTALL A LIQUID LINE SIGHT GLASS OR FILTER DRIER IN THE SYSTEM Run the line set to the Outdoor unit, avoid tight bends and kinking the lines. Quietside does not recommend brazing line sets together or to the unit connections...
- Page 21 The basic system installation is now complete The unit is now ready for start up - Use this time to ensure that worksite is tidy. Quietside recommend the use of Slimduct products to hide the refrigerant line set interconnects - available from your Quietside distributor...
