Steps
4.Remove front panel
Remove connection screws connecting
the front panel with the chassis and the
motor support, and then remove the front
panel.
5.Remove right side plate
Remove connection screws connecting
the right side plate with the valve support
and the electric box. Then remove the
right side plate.
6.Remove electric box assy
Remove the 2 screws
elec-tric box. Lift to remove the cover.
Loosen thewire and disconnect the
terminal. Lift to re-move the electric box
assy.
64
Procedure
front panel
the cover of
electric box assy
Service Manual
right side plate
