Page 1: Service Manual
Summary and features Summary and features Service Manual Model QSVMI-09A QSVMI-12A QSVMI-18A... -
Page 3: Technical Specifications
Technical specifications Technical specifications Model QSVMI-09A QSVMI-18A QSVMI-12A Fan Motor Speed (r/min) 1150/1050/900/750 1150/1050/900/750 1250/1050/950/800 (SH/H/M/L) Output of Fan Motor (w) Input Power of Heater (w) Fan Motor Capacitor (uF) Fan Motor RLA(A) 0.26 0.26 0.26 Fan Type-Piece Cross flow fan – 1 Cross flow fan –... - Page 4 Part name Part name Air inlet Displayer Front panel Wrapping tape Air guide board Air out Amplified sketch for displayer Remote control Setting temp. Heating Cooling Power/Run Auto Water drainage pipe Dehumidify Remote control receiving window Connection pipe and connection wire...
- Page 5 Outline and installation dimension Outline and installation dimension QSVMI-09A QSVMI-12A Air inlet grid 9.84 inch 30.32 inch 7.48 inch Mark for left outlet pipe hole Mark for right outlet pipe hole Top view diagram Back view 2.76 inch 7.87 inch 7.87 inch...
- Page 6 QSVMI-18A Air inlet grid 11.22 inch 32.68 inch 7.87 inch Mark for left outlet pipe hole Top view diagram Mark for right outlet pipe hole Back view 2.76 inch 7.87 inch 7.87 inch Ceiling...
-
Page 7: Electrical Circuit Diagram
Electrical circuit diagram Electrical circuit diagram 5 5 5 5 5 QSVMI-09A QSVMI-12A QSVMI-18A These circuit diagrams are subject to change without notice, please refer to the one supplied with the unit. -
Page 8: Cooling Mode
Controller Function Manual and Operating Method 6 6 6 6 6 Controller Function The unit for temperature is centigrade in this function manual. If there's Fahrenheit, the transition relation is TFahrenheit =TCentigrade 1.8+32. Temperature Parameter Indoor ambient temperature (T Evaporator inlet pipe temperature (T amb. -
Page 9: Timer Function
In cooling and fan mode, after setting sleep procedure 1h, Tpreset will increase 33.8 ; 2h later, Tpreset will increase 35.6 then remain the temperature, Tpreset will not exceed 86 ; under heating, after setting sleep procedure 1h, Tpreset will decrease 33.8 ; 2h later, Tpreset will decrease 35.6 , then remain the temperature, Tpreset will not exceed 60.8 ; the setting temperature will not change under fan and auto mode. - Page 10 4. Display 4.1 Basic Display (1) When the unit is energized, the display symbol display, then only power lamp is light. (2) When use remote control to turn on the unit, the running LED is light, and the current setting running mode lamp displayed at the same time.
- Page 11 Dissassembly Procedures Dissassembly Procedures 7 7 7 7 7 Operating Procedures / Photos Disassemble Front Panel Panel Protection plate Lift the front panel upward. Firstly, screw off a screw fixing the upper protection plate at the receiving window and remove the protection plate. Then, pull away the connection terminal.
- Page 12 Operating Procedures / Photos Disassemble Lower Guide Louver Manually bend the lower guide louver to loose the clasp at the guide louver. Remove the lower guide louver.(Note:to remove the upper guide louver,you must open the front case first, then screw off the screws fixing the upper guide louver and the water tray , bend clasp Guide Louver...
- Page 13 Operating Procedures / Photos Disassemble Cover of Electric Box Loosen the three clasps, and pull upward to remove the cover of the electric box. cover of the electric box clasp Disassemble Electric Box room sensor pipe temp. sensor Remove the grounding wire of the evaporator. Take out the pipe temp.
- Page 14 Operating Procedures / Photos Evaporator clasp screw Evaporator screw Disassemble Motor Use screwdriver to unscrew the two screws fixing motor clamp the motor clamp, and remove the motor clamp. Unscrew the three holding screws at the shaft sleeve, and remove the motor. Screw screw Axial fan...
- Page 15 Operating Procedures / Photos Disassemble Cross Flow Fan After remove the motor, pull out it from the left bearing holder. Cross Flow Fan Bearing Holder...
-
Page 16: Explosive View And Spare Parts List
Explosive view and spare parts list Explosive view and spare parts list Exploded View of Component 1... - Page 17 Components and Parts List Part Code Description QSVMI-09A Wall-Mounting Frame 01252220 Rear Case 222020016 Evaporator Assy 010020534 Cross Flow Fan 10352001 Ring of Bearing 76512203 Drainage Pipe 0523001401 Water Tray 201820270 Swing Louver 10512088 Swing Linkage 1 10582002 Swing Linkage 2...
- Page 18 Exploded View of Component 2...
- Page 19 Components and Parts List 2 Part Code Description QSVMI-12A Wall-Mounting Frame 01252384 Rear Case 222020503 Evaporator Assy 01002250 Cross Flow Fan 10352005 Ring of Bearing 76712015 Drainage Pipe 0523001401 Water Tray 201820306 Swing Louver 105120413 Swing Linkage 105824397 Front Case `200022958 Screw Cover 242520072...
- Page 20 Exploded View of Component 3...
- Page 21 Components and Parts List 3 Part Code Description QSVMI-18A Wall-Mounting Frame 01252004 Rear Case 22202329 Fan Bearing 76512203 Screw Cover 24252015 Swing Louverb 105120472 Swing Louver 10512430 Swing Link 1 10582057 Swing Link 2 10582058 Water Tray 20182057 Guide Louver （ up ） 10512085 Guide Louver （...
- Page 24 QUIETSIDE CORPORATION www.quietside.com West Office 8750 Pioneer Blvd. Santa Fe Springs, CA 90670 USA Phone: 562-699-6066 Fax: 562-699-4351 East Office 6 Pine Hill Drive Carlisle, PA 17013 Phone: 886-243-6498/ 717-243-2535 Fax: 717-243-7917 TX Office 3001 Northern Cross Blvd. Suite 361...
