- Page 1 OWNER’S MANUAL INSTALL MANUAL MODELS: QS36-VJ220 QS36-VP220...
- Page 2 ON/OFF Press it to start or stop operation. MODE Press it to select operation mode (AUTO/COOL/DRY/FAN/HEAT). Press it to decrease temperature setting. Press it to increase temperature setting. Press it to set fan speed. Press it to set swing angle. HEALTH SAVE Press it to turn on or off health function.
-
Page 3: Digital Display
Up & down swing icon: is displayed when pressing the up & down swing button. Press this button again to clear the display. Left & right swing icon: is displayed when pressing the left & right swing button.Press this button again to clear the display. SET TIME display: After pressing TIMER button, ON or OFF will blink.This area will show the set time. - Page 4 X-FAN: Pressing X -FAN button in COOL or DRY mode,the icon "X-FAN" is displayed and the indoor fan will continue operation for 10 minutes in order to dry the indoor unit even though you have turned off the unit. After energization, X-FAN OFF is defaulted. X-FAN is not available in AUTO, FAN and HEAT mode.
-
Page 5: Temperature Parameters
1. Temperature Parameters Indoor preset temperature (T preset Indoor ambient temperature (T 2. Basic Functions Once energized, in no case should the compressor be restarted within less than 3 minutes. In the situation that memory function is available, for the first energization, if the compressor is at stop before de-energization, the compressor will be started w ithout a 3-minute lag;... -
Page 6: Heating Mode
Protection Protection is the same as that under the cooling mode. (3) Heating Mode Working conditions and process of heating If T Tpreset +3.6 ºF , the unit enters heating mode, in which case the four-way valve, the compressor and the outdoor fan amb. - Page 7 b.Under AUTO mode,if T +1.8 ºF is detected,the unit will select to run under cooling mode,in which case implicit preset preset temperature is 77 ; if T -1.8 , the compressor will stop, the outdoor fan will stop with a time lag of 1 minute, and ºF ºF preset...
- Page 8 Designation of sensors Faults The sensor is detected to be open-circuited or short-circuited for Indoor ambient temperature successive 30 seconds The sensor is detected to be open-circuited or short-circuited for Indoor tube temperature successive 30 seconds The sensor is detected to be open-circuited or short-circuited for Outdoor ambient temperature successive 30 seconds The sensor is detected to be open-circuited or short-circuited for...
- Page 11 Space to the ceiling 5.9 in. Above Space to the wall 5.9 in. Above 5.9 in. Above Space to the wall 118.1 in. Above Above Air outlet side Space to the floor The dimensions of the space necessary for correct ●...
- Page 12 Wall Wall Mark on the middle of it Gradienter Space to Space to the wall the wall 59.1in. 59.1in. above above Right Left Φ2.6in. Φ2.6in. (Rear piping hole) (Rear piping hole) Indoor Outdoor Wall pipe Seal pad Φ2.6 outlet pipe of indoor unit outlet pipe of drain hose...
- Page 13 External connection Gas side piping electric wire Liquid side piping Tailing 3 Tailing 2 Tailing1 Gas side piping Liquid side piping insulation Finally wrap it Fig.3 insulation with tape Water drainage pipe Fig.4 Left Right Left rear Right rear Fixing hook Mounting board Mounting...
- Page 14 Manifold Valve Multimeter Manometer -29.9in.Hg Hi handle Lo Handle Charging hose Low pressure valve Vacuum pump Fig.6 Drain-water hole Bottom frame Drain plug Drain connecter Hose (available commercially, inner dia. 16mm)
- Page 15 Fig. a Fig. b Air filter Healthy filter Fig. c...
