Connect the external resistor RT and the multmeter as is shown in the Figure 10.
With the multmeter read the V voltage and calculate the Rx value using the
T
equation shown above.
When it is known the internal resistor value, connect the sensor to the board as is
shown in the Figure 11.
Fig. 11 Wiring diagram to connect NPN proximity sensors with internal pull up resistor.
! % + ' ' ,,
