SIGNODE BXT2
SIGNODE ENGINEERED PRODUCTS
Hand Tool Division
3610 W. Lake Avenue,
Glenview, Illonois 60025
www.signode.com
4

TABLE OF CONTENTS

SHORT INSTRUCTIONS
1 Technical data
2 General information
2.1 Information on environmental protection
3 Safety instructions
4 Description
4.1 Construction
4.2 Operating panel
4.3 Function
5 Operating instructions
5.1 Charging the battery
5.2 Operating the tool
5.3 Checking the seal
5.4 Checking battery charge
5.5 Setting mode of operation
5.6 Setting strap tension
5.7 Setting soft tension
5.8 Setting welding time
5.9 Setting strap width
6 Special functions
6.1 Switch touch-pad lock on and off
6.2 Sleep mode
6.3 Tool reset
7 Preventive and corrective maintenance
7.1 Cleaning/replacing tension wheel
7.2 Cleaning/replacing tooth plate
7.3 Replacing knife
7.4 Trouble shooting
8 Wear parts / Recommended spare parts
8.1 Parts list
Exploded drawing
DECLARATION OF CONFORMITY
We take sole responsibility for declaring that the tool
BXT2 to which this declaration refers is in full conformi-
ty with the current requirements of the guidelines laid
down by the council on 22th June 1998 (98/37/ECC),
"Machine Guidelines".
Furthermore, electrical installations are in conformity
with the guideline laid down by the council on 12.
December 2006 (2006/95/EEC) "Low Voltage Guide-
lines" and 15. December 2004 (2004/108/EEC)
"EMV Guidelines".
Harmonised standards applied:
EN ISO 12100-1, EN ISO 12100-2, EN 349,
EN 1050, EN 61000-6-1, EN 61000-6-3
15.11.2008
General Manager
Packaging Technology:
U. Schweizer
Page
2
4
8
8
10
12
12
12
12
14
14
14
18
18
18
20
20
20
20
22
22
22
22
24
24
24
24
26
28
28
32
General Manager Prod.
Packaging Technology:
M. Binder
07.09
