Options - Icom IC-F3162DT Instruction Manual

D BATTERY PACKS
Battery pack Voltage
950 mAh (min.)
BP-230N
7.4 V
980 mAh (typ.)
1900 mAh (min.)
BP-232N 7.4 V
2000 mAh (typ.)
2250 mAh (min.)
BP-232H
7.4 V
2300 mAh (typ.)
Battery case for AAA
BP-240
(LR03) × 6 alkaline
* 1 When the power save function is turned ON, and the operating
periods are calculated under the following conditions;
TX : RX : standby = 5 : 5 : 90
* 2 Operating period depends on the alkaline cells used.
D CHARGERS
• BC-119N
desktop charger
+ BC-145S
ac adapter
For rapid charging of battery pack. An AC adapter is sup-
plied with the charger, depending on versions.
Charging time: Approximately 3 hours for the BP-232H.
1
Capacity Battery life*
7.35 hrs.
12 hrs.
14 hrs.
2
—*
+ AD-106
charger adapter

OPTIONS

• BC-121N - + AD-106
multi charger
+ BC-157S
ac adapter
For rapid charging of up to 6 battery packs (six AD-106s
are required) simultaneously. An AC adapter should be pur-
chased separately.
Charging time: Approximately 3 hours for the BP-232H.
• BC-160
desktop charger
For rapid charging of battery pack. An AC adapter is sup-
plied with the charger, depending on versions.
Charging time: Approximately 3 hours for the BP-232H.
• BC-171
desktop charger
For regular charging of battery packs. We recommend that
the BP-230N charging. An AC adapter is supplied with the
charger, depending on versions.
Charging time: Approximately 4 hours for the BP-230N.
The BP-232H cannot be charged with the BC-171.
D BELT CLIPS
• MB-93
swivel belt clip
• MB-94
belt clip
Exclusive alligator-type belt clip.
• MB-96N/96F
leather belt hanger
8
(6 pcs.)
charger adapter
+ BC-145S
ac adapter
+ BC-147S
ac adapter
