- Page 1 SelectGloss™ 21P OPERATOR MANUAL AND PARTS LIST OPERATOR MANUAL AND PARTS LIST OPERATOR MANUAL AND PARTS LIST OPERATOR MANUAL AND PARTS LIST OPERATOR MANUAL AND PARTS LIST Kent MODEL 56010814 12/99 Form Number 56041488...
- Page 2 RECORD THIS IMPORTANT INFORMATION DATE OF PURCHASE PURCHASED FROM ADDRESS CITY STATE PHONE CONTACT MACHINE SERIAL NUMBER ENGINE ENGINE SERIAL NUMBER IMPORTANT PHONE NUMBERS Medical Emergency Police Fire Department...
- Page 3 • Keep nuts and bolts tightened and hose connections snug. • Refer to engine manufacturer's service manual or contact Nilfisk-Advance for engine repairs or adjustments not listed in this manual. • Never alter or reconstruct the fuel system. To do so may be dangerous and will void the factory warranty.
-
Page 4: Specifications
Even though NFPA 58 8-4.5 says... " these machines shall be permitted to be used in buildings frequented by the public, including the times when such buildings are occupied by the public." Nilfisk-Advance suggests use when occupancy of a given work area is at a minimum. -
Page 5: Table Of Contents
TABLE OF CONTENTS Propane Machine Safety A. Purpose ..........................1 B. Refueling and Storage of Fuel Cylinders ................1 C. Safety in Engineering ......................1 D. Use and Care ........................1 Machine Preparation A. Adding Oil ..........................1 B. Filling the Fuel Cylinder ......................2 C. -
Page 6: Propane Machine Safety
National Fire Protection Association in Quincy, Massachusetts (1-800-334-3555). C. Safety in Engineering Nilfisk-Advance engineers and manufactures machines utilizing U.L. (Underwriters Laboratories) approved components where possible. The U.L. logo will be affixed to a particular component. This means the component is listed. Component recognition for the following parts is important: fuel cylinders, couplings, regulators, and fuel lines. -
Page 7: Filling The Fuel Cylinder
II. Machine Preparation (continued) B. Filling the Propane Fuel Cylinder Nilfisk-Advance uses the 20 lb. capacity aluminum fuel cylinder which meets the D.O.T. 4E240 standards. These cylinders are also listed by U.L.. Filling should ONLY be done by a qualified propane dealer. -
Page 8: Idling And Stopping The Machine
III. Operating Instructions (continued) C. Idling and Stopping the Machine If for any reason the machine needs to idle for short periods of time, simply raise the burnishing head and move the throttle to the SLOW position. Allowing the engine to idle excessively will increase the concentration of carbon monoxide! WARNING To stop the engine, close the service valve on the fuel cylinder by turning it clockwise. -
Page 9: Scheduled Maintenance
IV. SCHEDULED MAINTENANCE Following proper scheduled maintenance procedures will provide years of uninterrupted service. REGULAR SERVICE PERIOD (Performed At Indicated Hour Intervals) ITEM or TYPE of SERVICE Each 20 hrs. 50 hrs. 100 hrs. 300 hrs. Engine Oil Check Level Change 2,4,5 2,4,5... -
Page 10: General Maintenance Procedures
V. General Maintenance Procedures A. Fuel System The fuel system works from vacuum created by the engine running. Turning the safety fill cylinder valve on pressurizes the system for flow to the carburetor once the engine starts to crank. 1. Adjusting the Regulator: Note: The regulator and carburetor, on this machine has been factory pre-set. -
Page 11: Changing Oil
B. Engine Maintenance (continued) 3. Changing the Oil Run engine for 5 minutes to warm oil. Locate oil drain plug and place a receptacle where the oil will drain into the receptacle. Open the oil drain plug. Allow oil to drain completely into receptacle. Close the oil drain plug and set the machine upright. -
Page 12: Adjusting The Handle
D. Adjusting the Handle * Insert lever bolt through handle bracket and hinge bushing to locate handle in operating position. VI. TROUBLESHOOTING SYMPTOM POSSIBLE CAUSES 1. Hard to Start Spark plug or head bolts loose. Blown head gasket. Insufficient vacuum. Coil, air gap needs adjusting. - Page 14 SelectGloss™ 21P Handle, Deck & Engine Parts List ITEM REF. NO. DESCRIPTION ITEM REF. NO. DESCRIPTION 56630108 Cable, Throttle, Control, 32" ......1 56630141 Washer, .755 x 1.005 x .060, SS ..... 1 56630102 Block, Wheel, 14GA ........1 56630119 Velcro, Studs ..........
- Page 15 Nilfisk-Advance, Inc. 14600 21st Avenue North Plymouth, MN, 55447-3408 www.nilfisk-advance.com Phone: 800-989-2235 Fax: 800-989-6566 ©1999 Nilfisk-Advance, Inc., Plymouth, MN 55447-3408 Printed in the U.S.A.
