WIRELESS 868 MHz TEMPERATURE STATION
Instruction Manual
INTRODUCTION:
Congratulations on purchasing this 868MHz Temperature Station
time and indoor / outdoor temperature
readings. With only two easy to use keys, this
innovative product is ideal for use in the home or office.
« Instant Transmission+» is the up and coming state-of-the-art new
wireless transmission technology, exclusively designed and developed by
LA CROSSE TECHNOLOGY.
"IT +" offers you an immediate update of all your outdoor data measured
from the transmitters: follow your climatic variations in real-time!
which displays the
23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WS9090 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for La Crosse Technology WS9090

Summary of Contents for La Crosse Technology WS9090

  • Page 1 WIRELESS 868 MHz TEMPERATURE STATION Instruction Manual INTRODUCTION: Congratulations on purchasing this 868MHz Temperature Station which displays the time and indoor / outdoor temperature readings. With only two easy to use keys, this innovative product is ideal for use in the home or office. «...
  • Page 2 THE TEMPERATURE STATION Hanging hole Battery compartment display SET key Stand MIN/MAX/+ key FEATURES: The Temperature Station • DCF-77 Radio Controlled time with manual settings • Time display (hour, minutes, seconds) • Time reception ON/OFF • 12/24 hour time format •...

  • Page 3: The Outdoor Temperature Transmitter

    • Low battery indicator • Table standing or wall mountable THE OUTDOOR TEMPERATURE TRANSMITTER • Remote transmission of outdoor temperature to temperature station by 868MHz • Weather-resistant casing • Wall mounting case • Mount in a sheltered place. Avoid direct rain and sunshine SETTING UP: Note: This temperature station receives only one outdoor transmitter.
  • Page 4 after 3 minutes, the batteries will need to be removed from both units and reset from step 1. In order to ensure sufficient 868 MHz transmission however, this should under good conditions be a distance no more than 100 meters between the final position of the Temperature station and the transmitter (see notes on “Mounting”...

  • Page 5: Battery Change

    Insert batteries observing the correct polarity (see marking). Replace compartment cover. INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE TRANSMITTER The Temperature Transmitter uses 2 x AA, IEC LR6, 1.5V battery. To install and replace the batteries, please follow the steps below: Remove the battery compartment cover at the back of the transmitter.

  • Page 6: Function Keys

    FUNCTION KEYS: Temperature Station: There are two easy-to-use function keys in the Temperature Station SET key MIN/MAX/+ key SET key • Press and hold for about 3 seconds to enter the Manual setting modes: manual time, year, date, month, weekday, 12/24 hour time format, time zone, time reception ON/OFF, and temperature settings.

  • Page 7: Lcd Screen And Settings

    LCD SCREEN AND SETTINGS DCF Tower Icon (for time reception) Time Calendar Low battery icon Low battery (transmitter) icon (station) Outdoor Indoor transmission temperature signal* Outdoor temperature * When the outdoor signal is successfully received by the Weather Station, this icon will be switched on.
  • Page 8 • Display the signal reception symbol indicating that receiver is receiving outdoor data. • Low battery indicator DCF-77 RADIO CONTROLLED TIME The time base for the radio controlled time is a Cesium Atomic Clock operated by the Physikalisch Technische Bundesanstalt Braunschweig which has a time deviation of less than one second in one million years.

  • Page 9: Manual Time Setting

    • During nighttime, the atmospheric disturbances are usually less severe and reception is possible in most cases. A single daily reception is adequate to keep the accuracy deviation below 1 second. MANUAL SETTING The following manual settings can be done in the setting mode: •...

  • Page 10: Calendar Setting

    Press the SET key to enter the minutes. The minute digits start flashing. Use the MIN/MAX/+ key to set the minute. Press again the SET key to confirm and enter the Calendar setting mode. Note: The unit will still try and receive the signal despite it being manually set. When it does receive the signal, it will change the manually set time into the received time.

  • Page 11: 12/24 Hour Time Display Setting

    Press the SET key to enter the weekday (the weekday digit will be flashing). Use MIN/MAX/+ key to adjust the weekday. Press the SET key to confirm and enter the 12/24 hour time display mode. 12/24 HOUR TIME DISPLAY SETTING To set the time format to 12h or 24h display mode (default 24h): Flashing Use the MIN/MAX/+ key to select the “12h”...

  • Page 12: Time Reception On/Off Setting

    Press the SET key to confirm and enter the Time reception ON/OFF setting mode. TIME RECEPTION ON/OFF SETTING In area where reception of the radio-controlled time (DCF time) is not possible, the time reception function can be turned OFF. The clock will then work as a normal Quartz clock.
  • Page 13 The “° C” or “ °F” will be flashing, use the MIN/MAX/+ key to toggle between “° C” and “° F”. Confirm with the SET key and exit the manual setting modes. CHECKING THE MIN/ MAX TEMPERATURES In normal mode display, press the MIN/MAX/+ key to display the outdoor display...

  • Page 14: Low Battery Indicator

    Press the MIN/MAX/+ to return to current indoor and outdoor temperature display. RESETTING THE MIN/ MAX TEMPERATURE Note: All the indoor and outdoor MIN/MAX records will the reset at the same time. Press the MIN/MAX/+ key once to enter the indoor temperature display. Press the SET key .
  • Page 15 Using other electrical products such as headphones or speakers operating on the same signal frequency (868MHz) may prevent correct signal transmission and reception. Neighbors using electrical devices operating on the 868MHz signal frequency can also cause interference. Note: • When the 868MHz signal is received correctly, do not re-open the battery cover of either the transmitter or Temperature station, as the batteries may spring free from the contacts and force a false reset.
  • Page 16 Wall mount Fix a screw (not supplied) into the desired wall, leaving the head extended out the by about 5mm. Hang the station onto the screw. Remember to ensure that it locks into place before releasing. Free standing With the foldout stand, the weather station can be placed onto any flat surface.

  • Page 17: Care And Maintenance

    To wall mount: Secure the bracket onto a desired wall using the screws and plastic anchors. Clip the remote temperature sensor onto the bracket. Note: Before permanently fixing the transmitter wall base, place all units in the desired locations to check that the outdoor temperature reading is receivable.

  • Page 18: Specifications

    • Do not make any repair attempts to the unit. Return them to their original point of purchase for repair by a qualified engineer. Opening and tampering with the unit may invalidate their guarantee. • Never touch the exposed electronic circuit of the device as there is a danger of electric shock should it become exposed.

  • Page 19: Liability Disclaimer

    LIABILITY DISCLAIMER: • The electrical and electronic wastes contain hazardous substances. Disposal of electronic waste in wild country and/or in unauthorized grounds strongly damages the environment. • Please contact your local or/and regional authorities to retrieve the addresses of legal dumping grounds with selective collection. •...
