INTRODUCTION:
Congratulations on purchasing this state-of-the-art weather projection station as an example of innovative design and quality piece of
engineering. Providing radio controlled time, date, calendar, moon phase, indoor and outdoor temperature, indoor and outdoor relative
humidity, this unit will never keep you guessing on current and future weather conditions. Operation of this product is simple and
straightforward. By reading this operating manual, the user will receive a better understanding of the weather projection station together
with the optimum benefit of all its features.
FEATURES:
•
WWVB Radio controlled time with manual setting option
•
Time reception ON/OFF (user selectable)
•
12/24 hour time display
•
DST ON/OFF (daylight saving time)
•
US time zone map
•
Time zone option ±12 hours
•
Month, date, weekday calendar display
•
Alarm setting with snooze function
•
Automatic daylight saving time
•
Display 12 moon phases throughout the year with moon/tide
indication
•
Weather forecasting with 3 weather icons
•
Weather tendency indicator
•
Indoor comfort indicator
•
Temperature display with MIN/MAX records and time of reception
•
Remote transmission of outdoor temperature and humidity to Weather Projection Station by 433 MHz
•
Rain proof casing
•
Wall mounting case
TO INSTALL AND REPLACE BATTERIES IN THE WEATHER PROJECTION STATION
The Weather Projection Station uses 3 x AA, IEC LR6, 1.5V batteries. To install and replace the batteries, please follow the
steps below:
WS-9025
Weather Projection Station
Instruction Manual
The Weather Projection Station
LCD
Display
Function
keys
The Outdoor Thermo-hygro Transmitter
1.
Insert finger or other solid object in the space at the bottom center of the battery compartment and lift
up to remove the cover.
2.
Insert batteries observing the correct polarity (see marking).
3.
Replace compartment cover.
SNOOZE
key
Function
keys
Projector
Battery
compartment
•
Indoor and outdoor temperature display in ºC/ºF Humidity data with
MIN/MAX records
•
Indoor and outdoor humidity display as RH%
•
Can receive up to 3 transmitters
•
Time projection display (hour and minute)
•
Outdoor temperature projection display (degrees ºC or ºF)
•
Alternate projection display mode selectable
•
Projection with adjustable brightness and projection orientation
possible
•
LCD contrast selectable
•
LED back light
•
Low battery indicator
•
Table standing
•
AC/DC power adapter included
Rain protection
cover
Wall mounting
base
Advertisement
Table of Contents
Related Manuals for La Crosse Technology WS-9025U
Summary of Contents for La Crosse Technology WS-9025U
- Page 1 INTRODUCTION: Congratulations on purchasing this state-of-the-art weather projection station as an example of innovative design and quality piece of engineering. Providing radio controlled time, date, calendar, moon phase, indoor and outdoor temperature, indoor and outdoor relative humidity, this unit will never keep you guessing on current and future weather conditions. Operation of this product is simple and straightforward.
-
Page 2: Battery Installation
TO INSTALL AND REPLACE BATTERIES IN THE THERMO-HYGRO TRANSMITTER The Thermo-hygro transmitter uses 2 x AA, IEC LR6, 1.5V batteries. To install and replace the batteries, please follow the steps below: Remove the battery cover. Insert the batteries, observing the correct polarity (see marking). Replace the battery cover on the unit. -
Page 3: About Wwvb Radio Controlled Time
RESETTING The Weather Projection Station and the Thermo-hygro transmitter need to be reset when one of the following conditions occur: • Unsuccessful 433MHz signal reception. • Malfunction on the units. • Batteries replacement. For resetting, remove all batteries from the units and unplug the AC-DC adapter from any power source. Wait at least for 3 minutes before powering up the Weather Projection Station again. - Page 4 LCD SCREEN The LCD screen is split into 5 sections displaying the information for time and time zone, moon phase and date, weather forecast, indoor data, and outdoor data. Time reception icon (for WWVB time) Time Moon phase icon Weather endency indicator Indoor temperature in ºF/ ºC...
- Page 5 MANUAL TIME SETTING: In case the Weather Projection Station cannot detect the WWVB-signal (for example due to disturbances, transmitting distance, etc.), the time can be manually set. The clock will then work as a normal Quartz clock. Hour flashing The hour digit will start flashing. Use the CH/+ key to set the hour.
- Page 6 SNOOZE ACTIVATION AND STOPPING THE ALARM: The snooze function can be activated when the alarm is ringing by pressing the SNOOZE key. However the snooze will only be activated when the snooze time is set other than OFF in snooze setting. Otherwise the snooze function will not be activated.
- Page 7 OUTDOOR RELATIVE HUMIDITY AND OUTDOOR TEMPERATURE The last LCD section shows the outdoor temperature and humidity, the reception indicator, the MIN/MAX outdoor data. A number in the center will also be shown if more than one transmitter has been used. Outdoor reception indicator Maximum record data Outdoor...
-
Page 8: Specifications
SPECIFICATIONS: Temperature measuring range: Indoor +14.2°F to +139.8°F with 0.1°F resolution -9.9ºC to +59.9ºC with 0.1ºC resolution (“OFL” displayed if outside this range) Outdoor -21.8°F to +157.8°F with 0.1°F resolution -29.9ºC to +69.9ºC with 0.1ºC resolution (“OFL” displayed if outside this range) Relative humidity measuring range: Indoor and outdoor 1% to 99% with 1% resolution...
