M32 DIGITAL CONSOLE User Manual
Psychoacoustics: The study of the perception of sound, that is, how we
listen, our psychological responses and the physiological effects on the human
nervous system.
Pschycoacoustic noise: Noise that affects the physiology of the listener.
Q
Quick access button: Button for navigation/ selection of a channel/bus/
processing area.
R
RAM: Abbreviation for 'Random access memory'.
Return: Auxiliary return or aux return. An extra input used for receiving a signal
from the output of an internal or external effect processor. See Bus.
Reverb: An effect where the ambience of a physical space is simulated. This is
done by copying a signal and replaying at regular intervals at ever decreasing
levels. The intervals are so close that each copy is not heard individually.
RMS: Abbreviation for 'root-mean-square'. The square root of the mean of the
sum of the squares. Commonly used as the effective value of measuring a sine
wave's electrical power. A standard in amplifier measurements. The effective
average value of an AC waveform.
RS: Abbreviation for 'right surround'. The right-hand rear speaker in a 5.1
surround system.
S
s: Symbol for 'second'. A unit of time.
Scene: In automation, a set of mix settings for a particular part of a performance,
for example, a play or song.
Sibilance: Energy from a voice, centred around 7 kHz, and caused by
pronouncing 's' , 'sh' or 'ch' sounds.
Side chain: A special circuit that diverts a proportion of the main signal so that
it can be processed, as required. Compressors use the side chain to derive their
control signals.
Signal flow: The path of a signal from one place to another.
SIP™: Abbreviation for 'solo in place'.
SIS: Abbreviation for 'spatial imaging system'. Combines a central loudspeaker
cluster with a left-right system to form three discrete sound channels.
Snapshot: A captured group of mixer settings that reflect the state of the mixer
at a particular moment within a performance. This snapshot can then be recalled
at the required moment in the performance/playback.
Solo: During monitoring, the isolation of one signal by silencing all other signals.
Source: The patch connector from which a signal is patched. See Patching.
SPL: Abbreviation for 'sound pressure level'. Given in decibels (dB), SPL is an
expression of loudness or volume.
Splash screens: The GUI display during power up.
SRC: Abbreviation for 'sample rate converter'.
SSD: Abbreviation for 'solid-state disk'. Data storage device that uses non-
volatile memory to store data. Quicker than the conventional hard disk and less
susceptible to the failures associated with hard disk drives.
Status indicator: A device specifically designed to show the condition of
something. For example, an LED that shows whether a pushbutton is on or off, or
a meter showing the level of a signal.
Stereo: Two separate channels, left and right, used to give the listener the
perception of where the noise is coming from. Usually used with music to give a
fuller, more natural sound.
Stereo image: The perception of the different sound sources coming from far
left, far right or anywhere in between.
Surround: Audio that has more that two speaker locations and, therefore,
more than two channels. Also commonly termed 'surround sound'.
Synchronisation (sync): Coordination of timing between devices.
T
Tab: A 'sheet' in the From and To sections that contains a specific group of patch
connectors. See Patching.
TFT: Abbreviation for 'thin film transistor'.
Threshold: Level at which dynamics processing will begin to operate.
Tie line: A dedicated connection between two systems, typically between FOH
and MON positions.
To section: The rightmost area of the Patching screen that contains the
destination patch connectors. See Patching.
Tooltip: The information box that appears next to the pointer when it passes
over or pauses on items on certain GUI screens, such as the channels on the
Overview and Patching screens.
Touchpad: Also known as 'trackpad'. An input device on a laptop PC for
controlling the on-screen pointer.
Track: Single stream of recorded audio data.
Trackball: Device, located in the primary navigation zone, for GUI screen
navigation and control of the mix and master bays.
Treble: Higher frequencies in a signal.
TW: Abbreviation for 'twin-wire'.
U
Unbalanced audio: A type of audio connection that utilises only two of the
leads of a cable, connector and jack.
Unfold: Navigates the input channels of a group to the input bays.
USB: Abbreviation for 'universal serial bus'. A 'plug and play' interface that
provides a fast connection between a computer and peripherals, such as
keyboards, printers, scanners, digital cameras etc.
V
VCA: Abbreviation for 'variable control association' (also 'voltage
controlled amplifier').
VCA fader: The fader control of a VCA group.
VCA group: A group of channels that are controlled globally, such as via
their group's fader and other controls. Provides an easy and quick method of
manipulating and controlling the numerous channels available on the M32
Control Centre.
VGA: Abbreviation for 'video graphics array'. A graphics display system for PCs
developed by IBM.
Virtual rack: A traditional 19" rack, represented on the GUI. A virtual rack will,
typically, contain internal devices, such as effects and GEQs.
Volt (V): A unit of electrical potential differential or electromotive force.
Volume: General term for a signal's loudness.
W
Window: A small self-contained panel that appears on the GUI, usually after
selection of a specific control. Typically, contains a number of user-selectable
options or information in the form of a message or prompt.
X
X-over: Abbreviation for 'crossover'.
XLR connector: High-quality three-pin audio connector, which is also used for
AES/EBU digital audio connections.
