M32 DIGITAL CONSOLE User Manual
Input/Output Characteristics
Frequency Response @ 48 kHz Sample Rate
Dynamic Range, Analogue In to Analogue Out
A/D Dynamic Range, Preamplifier and Converter (Typical)
D/A Dynamic Range, Converter and Output (Typical)
Crosstalk Rejection @ 1 kHz, Adjacent Channels
Output level, XLR Connectors (Nominal / Maximum)
Output Impedance, XLR Connectors (Unbalanced / Balanced)
Input impedance, TRS Connectors (Unbalanced / Balanced)
Non-Clip Maximum Input Level, TRS Connectors
Output Level, TRS (Nominal / Maximum)
Output Impedance, TRS (Unbalanced / Balanced)
Phones Output Impedance / Maximum output Level
Residual Noise Level, Out 1-16 XLR Connectors, Unity Gain
Residual Noise Level, Out 1-16 XLR Connectors, Muted
Residual Noise Level, TRS and Monitor out XLR Connectors
Display
Main Screen
Channel LCD Screen
Main Meter
Power
Switch-Mode Power Supply
Power Consumption
Physical
Standard Operating Temperature Range
Dimensions
Weight
0 dB to -1 dB 20 Hz – 20 kHz
106 dB 22 Hz - 22 kHz unweighted
109 dB 22 Hz - 22 kHz unweighted
109 dB 22 Hz - 22 kHz unweighted
100 dB
+4 dBu / +21 dBu
50 Ω / 50 Ω
20 kΩ / 40 kΩ
+21 dBu
+4 dBu / +21 dBu
50 Ω / 50 Ω
40 Ω / +21 dBu (Stereo)
-85 dBu 22 Hz-22 kHz unweighted
-88 dBu 22 Hz-22 kHz unweighted
-83 dBu 22 Hz-22 kHz unweighted
7" TFT LCD, 800 x 480 Resolution, 262k Colours
128 x 64 LCD with RGB Colour Backlight
24 Segment (-57 dB to Clip)
Auto-Ranging 100-240 VAC (50/60 Hz) ± 10%
120 W
5°C – 40°C (41°F – 104°F)
891 x 612 x 256 mm (35.1 x 23.9 x 10.1")
24.5 kg (53.9 lbs)
