DISASSEMBLY
ITEM
QTY.
DESCRIPTION
1
5
NUT FLANGE 5116·18 NYLOK
2
1
EARTH STRAP 3/ax 3/8
3
1
THERMAL SWITCH 255 F
4
2
SCREW PPHM M3.o.5 X 6 SEMS
5
1
DUCT ALTERNATOR INTAKE
6
4
SCREW HHTT M5-0.8 X12 BP
7
1
GROMMET SLEEVE WIO MEMBRANE
8
1
BELLOWS, ALTAIR IN
9
1.8 FT TAPE ELEC UL FOAM 1/8 X112
10
1
ASSY SPACER RING WI DOWEL PINS
11
1
RTR ASSY 7KW ECON VERT
12
1
STR ASSY 7KW ECON VERT
13
1
BEARING CARRIER ECON
14
1
BRUSH HOLDER
15
1
SCREW HHTT M5-0.8 X16
16
7
WASHER LOCK M8·5116
17
4
SCREW IHHC M8·1.25 X315 C8.8
18
1
FAN • CURVED BLADE, 203.5 OD
19
1
GASKET, ALT AIR OUT
20
1
WASHER FLAT .406ID X1.620D
21
1
SCREW IHHC 5116·24 X 12 G8 ZP
22
2
SCREW HHTT M8-1.2 X16 YC
23
1
MUFFLER, ECONOMY HSB
24
2
SCREW SHC 5118-18 X3/4
PART 5
ITEM
QTY.
DESCRIPTION
25
1
EXHAUST GASKET
26
13
SCREW HHTT M6-1.0 X10 VEL CHR
27
1
EXHAUST SHIELD ALTERNATOR
28
4
VlB MNT 1.3axl.0X5116-18 MXM
29
1
WASHER LOCK SPECIAL 5116
30
1
FRAME WELDMENT
31
2
SCREW HHTT M6-1.0 X20 ZINC
32
4
SCREW HHFC M6-1.0X 12 G8.8
33
1
EXHAUST SHIELD, RIGHT SIDE
34
1
EXHAUST SHIELD MUFFLER COVER
35
1
EXHAUST SHIELD, LEFT SIDE
36
1
EXHAUST SHIELD, ENG WRAPPER
37
1
CLAMP STLNNL .75 X.281 Z
38
1
OIL SUMP PLUG SMALL
39
1
OIL SUMP PLUG LARGE
40
1
WIRE, BRUSH POS #4 (NOT SHOWN)
41
1
WIRE, BRUSH NEG #0 (NOT SHOWN)
42
1
CABLE, SC TO SM (NOT SHOWN)
43
2
WIRE, ENG TO GND (NOT SHOWN)
44
1
BATT POS. CABLE COREPOWER (NOT
SHOWN)
45
1
BATT NEG. CABLE COREPOWER (NOT
SHOWN)
46
1
WASHER FLAT 1/4-M6 ZINC
