DISASSEMBLY
ITEM
QTY.
DESCRIPTION
1
1
ENGINE 432CC GASEOUS
2
2
SCREW, HHFCS M6·1 X16 G8.8
3
1
NUT HEX LOCK M5-0.8 NYINS ZINC
4
1
BRACKET, 432CC GOVERNOR ADJUST
5
1
SPRING, GOV MAIN LV432 EHSB
6
1
BOLT, GOV ADJUST M5
7
1
GASKET, AlRBOX
8
2
ASSEMBLY, KNOB, M6 ORANGE
9
1
AlRBOX COVER, 432CC OHV
10
1
ELEMENT, AIR FILTER
11
1
ASSY AIRBOX W/CHOKE 432CC OHV
12
1
WASHER NYLON .257
13
2
SCREW PPHM #40-4O X3/8 SEMS
14
1
CHOKE ROD 432CC EHSB
15
1
SPRING, CHOKE RETURN
16
1
COTTER PIN 1/4" SHAFT .091 WI
17
1
SOLENOID, 6VDC MOLEX
18
1
BREATHER HOSE 432CC OHV
19
2
WASHER FLAT 1/4-M6 ZINC
20
4
WASHER LOCK M6-1/4
21
1
SCREW HHC M6-1.0 X35 C8.8 BLK
22
2
INTAKE MOUNTING ROD 432CC
23
2
NUT FLANGE M6-1.0 NYLOK
24
2
CLAMP HOSE BAND .75"
PART 5
ITEM
QTY.
DESCRIPTION
25
1.8FT
LPG HOSE ASSEMBLY
26
1
NUT HEX LOCK M3-0.5 NY INS
27
1
BALL STUD,10 MM
28
1
ASSY THROTTLE ROD
29
1
GASKET INTAKE 432CC OHV
30
1
ASSY THROTTLE BODY 432CC OHV
31
1
GASKET INTAKE 432CC OHV
32
1
HOSE 3.18ID SAE J30R7 METRIC
33
1
SPRING, GOV, ANTI-LASH
34
1
SCREW HHFC M6-1.0 X12 G8.8
35
1
TIE WRAP , BEADED RELEASABLE
36
1
ASSY HOSE OIL DRAIN 6.0" LG ORG
37
1
BARBED STR 3/8NPT X3/8 VS
38
1
CLAMP , HOSE OETIKER STPLSS 18.5
39
2
NUT HEX 1/4-20 STEEL
40
1
CONTACTER, STARTER SOLENOID
41
2
SCREW, HHTT M6X1.0 X10
42
1
NUT HEX M6-1.0 G8 CLEAR ZINC
43
2
WASHER LOCK #8-M4
44
2
NUT HEX #8.32 STEEL
45
3
BOOT, VINYL STARTER·SOLENOID
46
1
JET REGULATOR 4.38 (LP)
1
JET REGULATOR 5.00 (NG)
47
1
O-RING 5 X 1.5 NITRILE 70
Section 5.2
Exploded Views
Page 99
