CHARGING THE BATTERY PACK

1
AC Adapter/Charger
AA-P30
CHARGE indicator 1
POWER indicator
CHARGE indicator 2
3
TIME TAKEN FOR RECHARGING
Battery pack
BN-V416
BN-V428
BN-V438
* When charged at temperatures between 20°C (68°F) and 25°C (77°F).
•When charging Battery Packs after a long storage period, charging time will be longer than
the time indicated above.
6
Power cord
Recharging time of a single pack
Approx. 2 hr. 10 min.
Approx. 3 hr. 20 min.
Approx. 4 hr. 20 min.
1
Make sure you unplug the DC cable from
the AC Adapter/Charger. Connect one end
of the power cord to the AC Adapter/
Charger and the other end to the wall
outlet. The POWER indicator lights.
2
2
Remove the battery pack's protective cap.
Attach the battery pack with the
mark aligned with the corresponding
marks on the AC Adapter/Charger. The
CHARGE Indicator begins blinking to
indicate charging has started. When two
battery packs are attached, they will be
recharged in the order that they are
attached.
3
When the CHARGE indicator stops
blinking but stays lit, charging is finished.
Slide the battery and lift off. Remember to
unplug the AC Adapter/Charger's power
cord from the AC outlet.
MEMO:
● Perform charging where the temperature
is between 10°C (50°F) and 35°C (95°F).
20°C (68°F) to 25°C (77°F) is the ideal
temperature range for charging. If the
environment is too cold, charging may
be incomplete.
● When plugging the power cord into an
AC Adapter/Charger, push it all the way
in until it stops.
Successive recharging time of two packs
Approx. 4 hr. 20 min.
Approx. 6 hr. 40 min.
Approx. 8 hr. 40 min.
