Compatibility
Table 4 lists compatible tools, Operating Systems, and
controllers used over the Zone Bus and N2 Bus with
the CVTPRO converter.
Table 4: Compatibility Chart
Tool
HVAC PRO Software (part of
M-Tool Release 5.0 or later)
VBT1400
VBT1200
GX-9100 Software
Configuration Tool (part of
M-Tool Release 5.0 or later)
XTM Configuration Tool
NDM Configuration Tool
Note: The CVTPRO converter is not compatible with Zone Terminal Units (ZTUs). For ZTUs, use the CBLPRO-2
converter. See the Auxiliary Gear Technical Bulletin (LIT-6363080) for details on Johnson Controls® converters.
1 For proper CVTPRO converter operation when running on Windows NT OSs, Service Pack 6 must be installed.
2 For proper CVTPRO converter operation when running on Windows 2000 OSs, use the Professional Edition only, and
Service Pack 2 must be installed.
3 On Zone Bus applications running on Windows 2000 OSs, HVAC PRO Version 8.04B or later must also be installed.
* When using the VMA14x0 with HVAC PRO software (versions prior to Version 8.04B only) over the Zone Bus with
Windows NT OSs, a Device Conflict box appears whenever the user attempts an operation (for example, upload or
download). To bypass the box, select Yes or No and the box disappears. The selected operation continues as
expected.
Battery Power Recommendations
The CVTPRO converter requires two (user-supplied)
AAA alkaline type batteries on N2 Bus applications
(when the External Power Adapter is not used).
Battery life varies depending on the N2 Bus load,
ambient temperature and type of batteries. See
Table 5 and observe the following guidelines.
Always have a spare set of new batteries on hand.
When performing long downloads with the
CVTPRO converter, use the External Power
Adapter instead of batteries.
Bus Operating System
N2 Bus Windows 98 SE/Windows NT
Windows 2000PE
Zone Bus Windows 98 SE/Windows 2000PE
OS
Zone Bus Windows NT
Zone Bus Palm Personal Digital Assistant (PDA)
with OS Version 3.5 or later
Zone Bus Palm PDA with OS Version 2.x or later
N2 Bus Windows 98 SE/Windows NT
Windows 2000PE
N2 Bus Windows 98 SE/
Windows 2000PE
N2 Bus Windows 98 SE/ Windows NT
Windows 2000PE
AS-CVTPROx00-1 Zone Bus/N2 Bus Interface Converter Installation
Compatible controllers include the Air Handling Unit
(AHU), Unitary Controller (UNT), Variable Air Volume
Controller (VAV), Network Dialer Module (NDM),
and VMA.
1
/
2
OS
2, 3
1
1
/
2
OS
1 1
Windows NT /
2
OS
1
/
2
OS
Table 5: *Typical Battery Life in CVTPRO Converter
AAA Battery:
Manufacturer
and Model/Type
Ray-O-Vac® Industrial Plus
Duracell® CopperTop
Eveready® Energizer Max®
* using a CVTPRO converter in continuous operation
on a fully loaded N2 Bus at room temperature (70 F
[21 C])
Compatible Controller
AHU1xx
UNT1xx
UNT11xx
VAV1xx
VMA14x0
VMA14x0*
VMA14x0
VMA12x0
DT-9100
DX-9100
XT9100 (XP91xx)
XTM-905 (XPx-xxx)
XTM-105 (XPx-xxx)
NDM
Battery Life
4-1/2 hours
5-1/2 hours
6-1/2 hours
