Summary of Contents for Johnson Controls CWCVT
- Page 1 CWCVT Wireless MS/TP Converter User Guide Building Technologies & Solutions LIT-12014120 www.johnsoncontrols.com 2023-03-21 Release 1.0...
- Page 2 CWCVT Wireless MS/TP Converter User Guide...
-
Page 3: Table Of Contents
Working with Johnson Controls BAS Tools..................9 Connecting a computer to the CWCVT in Wi-Fi AP Router Mode............9 Using Wi-Fi AP Router mode with Johnson Controls BAS Tools (SCT example)........9 Working with CWa..........................10 Connecting the CWa to the CWCVT......................10 Using the CWCVT from the CWa.......................10... - Page 4 CWCVT Wireless MS/TP Converter User Guide...
-
Page 5: Introduction
Johnson Controls BAS Tools and BACnet MS/TP controllers wired to an MS/TP bus. For example, you can connect the CWCVT to the System Configuration Tool (SCT) or a mobile device that runs the Connected Workflow Application (CWa) mobile application. -
Page 6: Screen Layout
MS/TP connection status Wireless connection status Page title and information Display rotation The display can rotate 180 degrees to make the CWCVT easier to use for both right- and left-handed users. About this task: To rotate the display, complete the following steps: Press and hold the A button to rotate the display to the opposite orientation. -
Page 7: Cwcvt Pages
MS/TP connections. This page makes it easier to view the connection status when you work on a ladder or at a distance of the controller that the CWCVT is plugged into. The Wireless Status indicates the following states:... -
Page 8: Connect Info And Pairing Info Page
When you connect the CWCVT wirelessly for the first time, you can view the Connect Info or Pairing Info page to see the CWCVT’s name and the PIN or Password that you need to enter on the host mobile device or computer to authorize the wireless connection. When the CWCVT is in BLE mode, the page is named Pairing Info and when the CWCVT is in Wi-Fi mode, the page is named Connect Info. -
Page 9: Working With Johnson Controls Bas Tools
However, if the wireless connection is lost, you may need to re-connect. Working with Johnson Controls BAS Tools You can use the CWCVT with Johnson Controls BAS Tools when the CWCVT is in Wi-Fi AP Router mode. Connecting a computer to the CWCVT in Wi-Fi AP Router Mode 1. -
Page 10: Working With Cwa
CWCVT-XX:XX:XX device. a. Connect to the device. b. Enter the PIN code. You can find the PIN code on the Pairing Info page of the CWCVT. Use the A button on the CWCVT to navigate to the Pairing Info page. -
Page 11: Configuration Settings And Diagnostics
USB-C cable, connect to 5 V, 500 mA, USB power source Figure 4: RJ12 pinout Configuration Settings and Diagnostics You can view the CWCVT's configuration settings and diagnostic information from either the CWa or from a web browser such as Google Chrome or Microsoft Edge ®... -
Page 12: Viewing Settings And Diagnostics From A Browser
CWCVT. Launch a browser on the host device. Enter the IP address as shown on the Connect Info page of the CWCVT. The default is: http:\ \192.168.142.1. Note: The CWCVT uses an HTTP connection and WPA2 to encrypt over-the-air traffic. - Page 13 BLE network number Write 1-65534 Used to route BACnet messages to the BLE bus. Typically, no need to change. Note: For more details about MS/TP communications bus see the MS/TP Communications Bus Technical Bulletin, LIT-12011034. CWCVT Wireless MS/TP Converter User Guide...
-
Page 14: Ble Settings
Bluetooth devices. Name rules: • Minimum three characters • Maximum 32 characters • Any printable character Note: Printable characters include: a-z, A-Z, 0-9, and ~`!@#$%^&*()_-+=<>,. CWCVT Wireless MS/TP Converter User Guide... -
Page 15: Wi-Fi Settings
SSID) that is visible from a characters Where host device you attempt to xx:xx:xx is pair with the CWCVT over its the last three Wi-Fi Access Point. values of the Typically, no need to change. Wi-Fi MAC You may want to change this Address. -
Page 16: Ms/Tp Diagnostics
The amount of time in milliseconds for the MS/TP token to make it around the token loop. Dropped Tokens A running count of the number of times the CWCVT detects that any device on the MS/TP bus fails to use and pass the token causing the token to be recovered. -
Page 17: Wi-Fi Diagnostics
Refresh button at the bottom of the table is pressed. These values reset to 0 on every power cycle. Note: These values do not update when connected to the CWCVT in BLE Router mode. BLE diagnostics... -
Page 18: Ms/Tp To Sd Card Capture
MS/TP to SD Card Capture About this task: The CWCVT features a micro SD card slot that you can use to capture MS/TP bus traffic for diagnostic purposes. The CWCVT supports 32 GB, FAT32 formatted micro SD cards. A unique .pcap MS/TP capture file is created each time you enable or disable the MS/TP Capture feature. -
Page 19: Factory Reset
Factory Reset page appears. a. To confirm the reset, press the B button. b. To cancel the reset, do not press any button until the CWCVT returns to its previous screen. Firmware updates The CWCVT firmware updates automatically when the CWCVT is connected to the CWa mobile application. -
Page 20: Troubleshooting
1. Verify that the CWCVT is in Wi-Fi AP Router mode. the CWCVT and now it gives a 2. Verify that your computer is in wireless range of the CWCVT. connection error. 3. Verify the computer’s Wi-Fi is turned on from the Settings >... -
Page 21: Frequently Asked Questions
IP controller, use the SA bus only. Can I access all MS/TP controllers Yes, the CWCVT can access all controllers on a FC bus trunk or with the CWCVT from a single network from any of the three CWCVT connection points - SA location? bus, sensor, or FC bus. -
Page 22: Repair Information
CHINA Contact information Contact your local branch office: www.johnsoncontrols.com/locations Contact Johnson Controls: www.johnsoncontrols.com/contact-us © 2023 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision and are subject to change without notice.
