- Page 1 Metasys® CCT Bluetooth® Technology Communication Commissioning Guide Building Technologies & Solutions LIT-12011038 www.johnsoncontrols.com 2019-05-27...
-
Page 3: Table Of Contents
Contents Document Introduction......................... 3 Bluetooth Wireless Technology Modules and Adapters............3 Bluetooth Quick Start Guide......................4 Setting up the BTCVT Wireless Commissioning Converter............4 Bluetooth Quick Start Guide for Windows 7................. 5 Bluetooth Quick Start Guide for Windows 10............... 6 Troubleshooting.......................... -
Page 5: Document Introduction
Document Introduction This document describes how to install the supported Bluetooth wireless adapters and ® commission your Controller Configuration Tool (CCT) to communicate with the Bluetooth Wireless Commissioning Converter (BTCVT). Note: In other documentation, the Bluetooth Commissioning Converter may be referred to as the Wireless Commissioning Converter. -
Page 6: Bluetooth Quick Start Guide
Bluetooth wireless adapter is installed and configured, you do not need to configure it again until software or hardware configurations change. Bluetooth Quick Start Guide This quick start guide leads you through the Bluetooth device setup for Windows 7 and Windows 10. -
Page 7: Bluetooth Quick Start Guide For Windows 7
Figure 2: BTCVT Wireless Commissioning Converter. 3. Verify that your computer's wireless is turned on. Typically, the internal wireless on/off button is on the side of the laptop or above the keyboard. Bluetooth Quick Start Guide for Windows 7 To connect the BTCVT with Windows 7, follow these steps: 1. -
Page 8: Bluetooth Quick Start Guide For Windows 10
Note: When Connected appears, the blue LED on the BTCVT device turns on and remains solid (not flashing), indicating a successful connection to the CCT. The SA/FC on the BTCVT turns on and flashes, indicating that communications to the field controller are established. -
Page 9: Troubleshooting
8. Select Bluetooth for the connection type, and enter the Bluetooth COM port number that you discovered in step 6. We recommend you set the Baud Rate to 38400. Note: The CCT remembers the most recent COM port entry for future uses. 9. - Page 10 Table 1: Troubleshooting Problem Solution If you plug in the Bluetooth wireless USB adapter before the installation software prompts you to do so, the computer may install its own drivers and may not communicate properly with the Bluetooth wireless USB adapter. If this occurs, use the following recovery procedure: 1.
-
Page 11: Detailed Procedures
Commissioning Converter before using CCT to upload or download a controller, follow these steps: 1. Go to Program Files (x86) > Johnson Controls > CCT > bin and double click WirelessUtility.exe. 2. On the Configuration tab, enter the COM port number assigned to your Bluetooth device, and then click Connect. - Page 12 Figure 4: Entering the COM Port Number in the Configuration Tab 3. Click the Status tab to view the signal quality. Note your Wireless Link color and status, then compare your results to Table 2. Figure 5: Viewing Signal Quality in the Status Tab Metasys®...
-
Page 13: Installing The Bluetooth Wireless Usb Adapter
Table 2: Wireless Link Status Status Color (Percent) Description and Corrective Action Wireless link is good and optimal for use with CCT. No corrective action required. Green Good Note: To maintain a strong Wireless Link status, keep your computer as close to the Wireless Commissioning Converter as possible. - Page 14 Note: If the installation does not start automatically, on the Start menu, go to Run or press the Windows key + R. In the field that appears, enter the vendor setup program, for example D: \setup.exe (where D is the letter of your CD-ROM or DVD drive). Click Install Bluetooth Driver.
-
Page 15: Related Documentation
15. See Setting up the BTCVT Wireless Commissioning Converter to set up your device. Related Documentation Table 3 provides a list of documents related to the CCT and the Wireless Commissioning Converter. Table 3: CCT and Wireless Commissioning Converter Documentation For Information On See Document LIT or Part Number... - Page 16 © 2019 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision and are subject to change without notice.
