FX-BTCVT Bluetooth® Commissioning Converter
Commissioning Guide
FX-BTCVT-1 (Bluetooth Commissioning Converter)
Document Introduction.............................................................................................................2
Concepts.....................................................................................................................................2
Bluetooth Wireless Technology Modules and Adapters.................................................................2
Bluetooth Quick Start Guide.....................................................................................................3
Troubleshooting.........................................................................................................................9
Detailed Procedures................................................................................................................11
Installing the Bluetooth Wireless USB Adapter.............................................................................13
Related Documentation...........................................................................................................14
FX-BTCVT Bluetooth® Commissioning Converter Commissioning Guide
Code No. LIT-12011665
Issued December 5, 2014
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FX-BTCVT Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Johnson Controls FX-BTCVT Series

Summary of Contents for Johnson Controls FX-BTCVT Series

  • Page 1: Table Of Contents

    FX-BTCVT Bluetooth® Commissioning Converter Commissioning Guide FX-BTCVT-1 (Bluetooth Commissioning Converter) Code No. LIT-12011665 Issued December 5, 2014 Document Introduction......................2 Concepts.............................2 Bluetooth Wireless Technology Modules and Adapters..............2 Bluetooth Quick Start Guide.....................3 Troubleshooting.........................9 Detailed Procedures........................11 Verifying the Connection between the Laptop and the Bluetooth Commissioning Converter..11 Installing the Bluetooth Wireless USB Adapter................13 Related Documentation......................14 FX-BTCVT Bluetooth®...

  • Page 2: Document Introduction

    For the latest list of laptop computers with internal Bluetooth wireless modules and USB adapters, Johnson Controls® employees should refer to the Computer Price List available on the Johnson Controls Portal intranet site by Information Technology - Acquisition Services (ITAS). Otherwise, please contact your Johnson Controls representative if you need assistance.

  • Page 3: Bluetooth Quick Start Guide

    Bluetooth Quick Start Guide This quick start guide leads you through the Bluetooth device setup for Windows 7. Your steps may vary depending on the vendor of the Bluetooth wireless device and your operating system. You must repeat steps 1–12 for each Bluetooth converter you set up, because each device is assigned its own COM port.
  • Page 4 Verify that your computer's wireless is turned on. Typically, the internal wireless on/off button is on the side of the laptop or above the keyboard. Usually, a wireless button or icon lights up when the internal wireless is on. The following Note: images are examples of typical wireless icons.
  • Page 5 Select your Bluetooth device and click Next. The Add a device wizard starts. Your device's 12 digit MAC address is printed on the case of the device. To identify your Note: device in the Add a Device wizard, match the address on your BTCVT hardware to the address listed in the wizard.
  • Page 6 A confirmation screen appears and says that the device was successfully added to the computer. Click Close. Note your device's COM port number. To do this, click the Windows start button, select Control Panel > Devices and Printers, right-click the device, and then click Properties. Select the Hardware tab to find the COM port number.
  • Page 7 Launch the FX-PCT, and select Load to test the Bluetooth device connection. The Load Device wizard appears. FX-BTCVT Bluetooth® Commissioning Converter Commissioning Guide...
  • Page 8 Select Bluetooth for the connection type, and enter the Bluetooth COM port number that you discovered in step 9 in the Bluetooth COM Port field. No other parameters are needed to test the Bluetooth device connection. Note: The FX-PCT remembers the most recent COM port entry for future uses. Note: Click Next.

  • Page 9: Troubleshooting

    Troubleshooting Table 1: Troubleshooting Problem Solution You cannot communicate with the Bluetooth Use the following procedure to verify the computer's wireless state, verify the Commissioning Converter from the FX-PCT. COM port, and test the connection between your computer and wireless device.
  • Page 10 Table 1: Troubleshooting Problem Solution When you try to connect to the BTCVT device The Bluetooth driver for the laptop is not fully compatible with the BTCVT with your laptop, this error message appears: device. Contact your network help desk for assistance or go to the manufacturer’s website to download a compatible driver.

  • Page 11: Detailed Procedures

    To test the connection and see the signal quality between your laptop and the Bluetooth Commissioning Converter before using CCT to upload or download a controller, follow these steps: 1. Click the Windows start button, and then click All Programs > Johnson Controls > FX > Bluetooth Wireless Utility.
  • Page 12 3. Click the Status tab to view the signal quality. Note your Wireless Link color and status, then compare your results to Table Table 2: Wireless Link Status Color (Percent) Description and Corrective Action Status Green Good Wireless link is good and optimal for use with FX-PCT. No corrective action required.

  • Page 13: Installing The Bluetooth Wireless Usb Adapter

    Installing the Bluetooth Wireless USB Adapter Note: We recommend that you do not install an external Bluetooth wireless adapter if Bluetooth is built in to your computer. See Bluetooth Quick Start Guide if Bluetooth is built in. Note: The instructions to install the USB adapter may vary depending on the vendor of the USB Adapter. Before installing the USB adapter, familiarize yourself with the vendor’s installation instructions.

  • Page 14: Related Documentation

    Building Efficiency 507 E. Michigan Street, Milwaukee, WI 53202 Metasys® and Johnson Controls® are registered trademarks of Johnson Controls, Inc. All other marks herein are the marks of their respective owners.© 2015 Johnson Controls, Inc. Published in U.S.A. www.johnsoncontrols.com FX-BTCVT Bluetooth® Commissioning Converter Commissioning Guide...
