Your hearing aids at a glance

1 Earhook - your custom made earmold attaches to
your hearing aids using the earhook
2 Microphone - sound enters your hearing aids
through the microphones.
protects microphones from dirt & debris
3 Push button - switches between listening programs
or changes the volume level or SmartFocus 2,
depending on your customized fitting
4 Lever - controls either the volume or SmartFocus 2,
depending on your customized fitting
5 Battery door (on & off)
your hearing aids, partly open the door to turn off
your hearing aids. Opening the door all the way
gives you access to change the battery
6 Tubing - part of the earmold that attaches it to
the earhook
7 Earmold - allows the sound to pass from the
hearing aids to the ear and holds the hearing aids
in place
8 Slim tube - sound travels down the slim tube to
the ear canal
2
Microphone shield
- close the door to turn on
9 Dome
canal
10 Retention piece
slim tube from moving out of the ear canal
-
2
3
2
4
5
2
3
2
4
5
- holds the slim tube in place in your ear
- helps prevent the dome and
1
6
7
8
9
10
3
