- Page 1 Operating Manual UK air/water Heat PUMPs OUtdOOr installatiOn niBe aP-aw30 We reserve the right to make technical changes. 83054206bUK – Translation of the operating manual...
-
Page 2: Please Read First
Indicates suggestions that help to save energy, raw materials and costs. Reference to other sections of the operating manual. Reference to other instructions of the manufac- turer. NIBE AP-AW30 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual... -
Page 3: Table Of Contents
Contents INfoRmATIoN foR opERAToRS ANd quAlIfIEd SpEcIAlISTS TEchNIcAl dATA / ScopE of dElIvERy Ap-AW30-25E - Ap-AW30-31E ........20 plEASE REAd fIRST ..............2 pERfoRmANcE cuRvES SymbolS ..................2 hEATING cApAcITy/cop / poWER coNSumpTIoN / INTENdEd uSE ................4 hEAT pump pRESSuRE loSS Ap-AW30-25E ..............22 ExcluSIoN of lIAbIlITy ............4... -
Page 4: Intended Use
EC conformity The unit bears the cE mark of conformity. Ec declaration of conformity NIBE AP-AW30 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual... -
Page 5: Customer Service
We reserve the right to make technical changes 83054206bUK – Translation of the operating manual NIBE AP-AW30... -
Page 6: Operating Principle Of Heat Pumps
€ When letting in fresh air, do not leave windows open for an extended period, thus saving energy and reducing your heating costs. NIBE AP-AW30 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual... -
Page 7: Care Of The Unit
In order to ensure prob- lem-free operations, the ice must be removed on a reg- ular basis. We reserve the right to make technical changes 83054206bUK – Translation of the operating manual NIBE AP-AW30... -
Page 8: Scope Of Delivery
(connected on heat pump side). dered separately. Inspect delivery for outwardly visible signs of dam- With the Ap-AW30-31E, you must select the electrical age… heating element for the specific system and order it sep- arately. -
Page 9: Installation Location
Never use components and hydraulic connec- tions on the unit for purposes of transport. We reserve the right to make technical changes 83054206bUK – Translation of the operating manual NIBE AP-AW30... -
Page 10: Attaching The Air Flow Baffles
• To do so, loosen the two quick-release screws on the lower facing panels… NIBE AP-AW30 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual... - Page 11 Remove top cover and inet side (= operator side) and water connection set securely aside… side… We reserve the right to make technical changes 83054206bUK – Translation of the operating manual NIBE AP-AW30...
-
Page 12: Installation / Connection To Heating Circuit
(see “Electrical connection work”, “heat pump side connection of control and sensor wires”) )… attentIon during extended interruptions in work, close the unit with the lower facing panels. NIBE AP-AW30 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual... -
Page 13: Condensate Discharge
2 hot water outflow (forward flow) connection 3 condensate water hose Install the condensate water hose in the unit so that there is no contact with refrigerant pipes… We reserve the right to make technical changes 83054206bUK – Translation of the operating manual NIBE AP-AW30... -
Page 14: Buffer Tank
If the heat pump will be used for heating hot water, you must integrate special hot-water tanks in the heat pump system. The storage volume must be sufficient so that NIBE AP-AW30 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual... - Page 15 Ensure clockwise rotary field of the load power supply (compressor). – incorrect rotary field com- pressor during operation cause serious, irreparable damage compressor. We reserve the right to make technical changes 83054206bUK – Translation of the operating manual NIBE AP-AW30...
-
Page 16: Rinsing, Filling And Bleeding The System
“Terminal diagrams” and “circuit diagrams” for the respective model. operating manual of the heating and heat pump regulator. Seal empty pipes on unit side… NIBE AP-AW30 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual... -
Page 17: Water Quality Of The Fill And Additional Water In Hot Water Heating Systems
This is the only way to comply with the vdI 2035 requirements and We reserve the right to make technical changes 83054206bUK – Translation of the operating manual NIBE AP-AW30... -
Page 18: Insulating The Hydraulic Connections
Clockwise rotary field of the load power supply (compressor). • Installation and assembly of the heat pump according to the information in this operating manual. NIBE AP-AW30 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual... -
Page 19: Safety Temperature Limiter
1 Safety temperature button on electric heating element 2 Reset button We reserve the right to make technical changes 83054206bUK – Translation of the operating manual NIBE AP-AW30... -
Page 20: Technical Data / Scope Of Delivery
*) depending on components tolerances and flow **) comply with local regulations n.n. = not detectable w.w. = to choice ¹) hot water return ²) hot water flow NIBE AP-AW30 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual... - Page 21 AP-AW30-25E AP_AW30-31E — ı • ı — — ı • ı — — ı • — ı • • • 27,3 ı 3,9 35,0 ı 4,0 14,1 ı 4,2 19,1 ı 4,2 26,1 ı 3,3 34,4 ı 3,5 13,7 ı 3,4 18,9 ı...
-
Page 22: Performance Curves
AP-AW30-25E Performance curves Qh (kW) Temp„ (°C) Pe (kW) 35°C 1VD 50°C 1VD 35°C 2VD 50°C 2VD Temp„ (°C) Temp„ (°C) ∆p (bar) 0,4000 0,3500 0,3000 0,2500 0,2000 0,1500 0,1000 p∆” 0,0500 0,0000 “” (m³/h) 823156a Legende: DE823129L/170408 “” Volumenstrom Heizwasser... -
Page 23: Ap-Aw30-31E
Performance curves AP-AW30-31E Qh (kW) Temp„ (°C) Pe (kW) 35°C 1VD 50°C 1VD 35°C 2VD 50°C 2VD Temp„ (°C) Temp„ (°C) ∆p (bar) 0,1000 0,0875 0,0750 0,0625 0,0500 0,0375 p∆” 0,0250 0,0125 0,0000 10,0 “” (m³/h) 823147a Legende: DE823129L/170408 “”... -
Page 24: Sound Pressure Level
(A) dB (A) dB (A) dB (A) dB (A) dB (A) dB (A) dB (A) dB (A) dB (A) dB (A) AP-AW30-25E AP-AW30-31E NIBE AP-AW30 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual... -
Page 25: Dimensional Drawings Ap-Aw30-25E
Dimensional drawings AP-AW30-25E 1 2 3 Legende: UK819351b All dimensions in mm LW 100H-A 1774 1353 R 1" R 1" Front view Side view 1943 1523 R 1" R 1" Top view Heating water outflow (forward flow) 1931 1050 1780... -
Page 26: Ap-Aw30-31E
AP-AW30-31E Dimensional drawings 1779 1258 1 2 3 ÄM 999/2011 20.7.2011 PEP 020/2009 12.11.2009 Zust. Änderungstext Datum Legend: UK819326 All dimensions in mm. Front view Side view Top view Heating water outflow (forward flow) Heating water inflow (return flow) Condensate hose diameter 36... -
Page 27: Installation Plans Ap-Aw30-25E
Installation plans AP-AW30-25E 2 3 4 >2000 ≥1500 ≥3000 ≥5350 Legend: UK819378 All dimensions in mm. Front view ≥ ... Top view ≥ … Minimum clearances Recess in base Local heat pipe for heating water forward/return flow Empty pipe for electric cables, minimum diameter 70mm Condensate discharge, minimum diameter 50mm Water-permeable surface (gravel, …) in the air outlet area... -
Page 28: Ap-Aw30-31E
AP-AW30-31E Installation plan 2 3 4 >2000 ≥1500 ≥3000 ≥5350 Legend: UK819327 All dimensions in mm. Front view ≥ ... Top view ≥ … Minimum clearances Recess in base Local heat pipe for heating water forward/return flow Empty pipe for electric cables, minimum diameter 70mm Condensate discharge, minimum diameter 50mm Water-permeable surface (gravel, …) in the air outlet area... - Page 29 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual NIBE AP-AW30...
-
Page 30: Terminal Plans
AP-AW30-25E Terminal plan 3~N/PE/400V/50Hz 3~N/PE/400V/50Hz 3~N/PE/400V/50Hz 1~N/PE/230V/50Hz B10 A ZW2/SST NIBE AP-AW30 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual... -
Page 31: Ap-Aw30-31E
Terminal plan AP-AW30-31E 3~PE/400V/50Hz 3~N/PE/400V/50Hz 3~N/PE/400V/50Hz 1~N/PE/230V/50Hz B10 A ZW2/SST We reserve the right to make technical changes 83054206bUK – Translation of the operating manual NIBE AP-AW30... -
Page 32: Ap-Aw30-25E
AP-AW30-25E Circuit diagram 1/3 +10V +24V NIBE AP-AW30 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual... - Page 33 Circuit diagram 2/3 AP-AW30-25E We reserve the right to make technical changes 83054206bUK – Translation of the operating manual NIBE AP-AW30...
- Page 34 AP-AW30-25E Circuit diagram 3/3 NIBE AP-AW30 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual...
-
Page 35: Ap-Aw30-31E
Circuit diagram 1/2 AP-AW30-31E We reserve the right to make technical changes 83054206bUK – Translation of the operating manual NIBE AP-AW30... - Page 36 AP-AW30-31E Circuit diagram 2/2 NIBE AP-AW30 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual...
-
Page 37: Ec Declaration Of Conformity
AP-BW30-58* 065288 (106616 02) AP-AW10-10C 064120 (106442 46) AP-BW30-69* 065289 (106617 02) AP-AW10-12C 064121 (106443 46) AP-BW30-29H* 065284 (106618 02) AP-AW30-25E 064116 (106546 02) AP-BW30-56H* 065287 (106621 02) AP-AW30-31E* 064117 (106547 02) AP-BW30-110* 065290 (106372 04) AP-BW30-125* 065291 (106373 04) - Page 38 NIBE AP-AW30 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual...
- Page 39 We reserve the right to make technical changes 83054206bUK – Translation of the operating manual NIBE AP-AW30...
- Page 40 Puh: 09-274 697 0 Fax: 09-274 697 40 E-mail: info@nibe. www.nibe.fi AIT France, 10 rue des Moines, 67500 Haguenau Tel : 03 88 06 24 10 Fax : 03 88 06 90 15 E-mail: info@nibe.fr www.nibe.fr NIBE Energy Systems Ltd, 3C Broom Business Park, Bridge Way, Chester eld S41 9QG Tel: 0845 095 1200 Fax: 0845 095 1201 E-mail: info@nibe.co.uk www.nibe.co.uk...
