Enjoying music in the remote zone

ZONE 2 indicator
STANDBY/ON
STANDBY
POWER
ON OFF
ZONE 2 ( GRN )
REC ( RED )
AUDIO DVD
SELECTOR
PURE AUDIO UPSAMPLING
PHONES
REC OUT ZONE 2 OFF STEREO SURROUND
2
ZONE LEVEL
OFF
ZONE 2
ZONE 2 LEVEL

Playing music using the buttons on the TX-DS898

1. Press the Zone 2 button on the TX-DS898.
2. Select a source.
After pressing the Zone 2 button, you must press an input source
button within 5 seconds. The Zone 2 indicator lights.
Ex.: When the CD button is pressed.
To select the same source for the remote zone that is selected
for the main zone, press the Zone 2 button again until
"Zone2Sel:SOURCE" appears in the display.
When "Zone2Sel:Off" is displayed, the output to the remote
zone is turned off.
Notes:
• If a sleep time is set with the Sleep button, it will also work for
the remote zone.
• If the source for the main zone is selected as the source for the
remote zone and the source for the main zone is changed, then
the source for the remote zone will change as well.
• The Zone 2 terminal is an analog output. Digital signals are not
output. If no sound is heard from the selected input source, check
if the component is connected to the analog inputs.
• If the REC OUT button is pressed in the main room while
someone is using the system in the remote zone, the Zone 2
function will be deactivated and the source will turn off in the
remote zone.
• If you select FM (or AM) with the input source buttons when the
source for the remote zone (Zone 2) is set to AM (or FM), the
output for the remote zone also changes to AM (or FM).
• 7.1-channel playback in the main room is disabled if the
Powered Zone 2 setting of the Speaker Config sub-menu is set to
"Activated."
• When you are using the remote zone (Zone 2),
operation will not work.
• When you are using the remote zone (Zone 2), the Pure Audio
setting will not work.
• When you are not using the remote zone (Zone 2), press the
ZONE 2 button and then press the OFF button to turn off the
ZONE 2 indicator.
58
VIDEO 1 VIDEO 2 VIDEO 3 VIDEO 4 VIDEO 5
TAPE FM AM PHONO C D
DISPL AY
VIDEO
THX DSP DIMMER FM MODE MEMORY SETUP ENTER RETURN
CLEAR TUNING PRESET
DIGITAL S VIDEO
Input source buttons
/
MASTER VOLUME
Input
selector
buttons
5 /VIDEO CAM INPUT
VIDEO L AUDIO R
Selecting an input source using the remote
controller
When using the remote controller, select Zone 2 in the Home menu
to display the Zone 2 operation menu.
Turning on the Zone 2 and putting it in the standby state
when the TX-DS898 is in the standby state:
Tap the ON button.
Selecting an input source:
Press an input source button.
If you select Tuner of the input selector buttons, you can select a
preset channel using the CH +/– buttons.
Note:
Each time you press one of the Zone 2 buttons on the remote
controller, the STANDBY indicator on the TX-DS898 flashes for
five seconds. During this time, you will not be able to perform
operations in the main zone using the remote controller.
Adjusting the volume for the remote zone using
the remote controller
When the remote zone (Zone 2) speakers are connected to the
SURR BACK/ZONE 2 SPEAKERS terminals, or to an amplifier
connected to the SURR BACK/ZONE 2 PRE OUT terminals,
adjust the volume as shown below.
Press the ZONE 2 LEVEL / buttons on the front panel.
Adjusting the volume:
system
Press the VOL / buttons.
Note:
When the remote zone (Zone 2) speakers are connected to the pre-
main amplifier that is connected to the ZONE 2 terminal of the TX-
DS898, adjust the volume for the remote zone at the pre-main
amplifier.
–
CONT
+
MUTE
LIGHT
+
CH
ON
–
VOL
VOL
CH + / –
VOL
+
CH
–
