Navigating Through The Setup Menu - Onkyo Integra TX-DS898 Instruction Manual

Setup menus
Advanced Menu
0.Hardware Setup
1.Speaker Setup
2.Input Setup
3.Audio Adjust
4.Preference

Navigating through the Setup menu

You can change settings using the buttons on the front panel and on
the remote controller.
The buttons on the remote controller correspond to those on the TX-
DS898 as shown below.
Button on remote controller
Setup
UP
DOWN
LEFT
RIGHT
Enter
Return
30
→Basic Menu
|ENTER|Quit:|SETUP|
Main menu
Button on TX-DS898
SETUP
SETUP
UP
DOWN
LEFT
RIGHT
ENTER
ENTER
RETURN
RETURN
1.Speaker Setup
1.Speaker Config
2.Speaker Distance
3.Level Calibration
4.Bass Peak Level
|ENTER|Quit:|SETUP| Quit:|SETUP|
Menu
When using the buttons on the front panel
1. Press the SETUP button.
The main menu screen of the Main menu appears on your TV
monitor.
2. Using the and
that you want to enter.
3. Press the ENTER button to enter the selected menu.
The screen for that menu appears.
4. Using the and
menu that you want to enter, and press the ENTER
button.
Each sub-menu has different settings that can be changed as
desired, and they are all explained below. To change a setting,
first select it using the
the setting using the
5. Press the RETURN button to set the new settings and
return to the previous menu screen, and again to
return to the main screen.
Note:
Press the SETUP button to exit the Setup menu immediately.
When using the remote controller
1. Select AV Amp in the Home menu.
2. Tap the down scroll button twice to display the third
operation menu.
3. Perform steps 1 to 5 given above.
You can perform the same operation using the buttons on the
remote controller that correspond to those on the front panel.
1-1.Speaker Config
a.Subwoofer :Yes
b.Front :Small
c.Center :Small
d.Surround L/R:Small
e.Surround Bk :Small
f.Powered Zone2
:Not Activated
Quit:|SETUP|
Sub-menu
cursor buttons, select the menu
cursor buttons, select the sub-
and cursor buttons, and then change
and cursor buttons.
