Enjoying music in the remote zone

ZONE 2 indicator
STANDBY/ ON
ST ANDBY ZONE 2
POWER
ON OFF
REC OUT ZONE 2
PHONES
ZONE 2

Controlling the TX-DS787 from the remote zone

1. Aiming at the remote sensor, press the ON
button on the remote controller.
Note:
Be aware that if you start using the system in the remote zone
(Zone 2) while a recording is going on in the main zone, the
recording will be stopped in the main zone.
2. Press the appropriate input selector button on
the remote controller to select the desired
source.
3. Adjust the volume to the desired level.
Adjusting the volume for the remote zone at the
TX-DS787
Following the procedure given below, you can adjust the volume
for the remote zone at the TX-DS787 without using the remote
controller.
1. Press the ZONE 2 VOL button.
2. While "ZONE 2Volume" is displayed, turn the
SSC dial to adjust the volume to the desired
level.
Controlling the TX-DS787 without the remote
controller
1. Press the Zone 2 button on the TX-DS787.
48
FM MUTE /
PTY/ TP MODE DOWN
LISTENING MODE
DISPLAY DIRECT STEREO / DTS
SURROUND
AUDIO SELECTOR
1 2 3 4
DVD VIDEO VIDEO VIDEO VIDEO TAPE
VCR 1 VCR 2
Input source buttons
ZONE 2 VOL
MASTER VOLUME
CHARACTER / BASS /
TUNING UP MEMORY TREBLE CH LEVEL ZONE 2 VOL
DSP/ PRESET
SMART SCAN
CONTROLLER
PUSH TO ENTER
THX MENU EXIT
VIDEO / 4 VIDEO CAM INPUT
FM AM PHONO C D
S VIDEO VIDEO
AV RECEIVER
SSC
2. Select a source.
After pressing the Zone 2 button, you must press an input
source button within 3 seconds. The Zone 2 indicator lights.
Ex.: When the CD button is pressed.
To select the same source for the remote zone that is selected
for the main zone, press the Zone 2 button again until
"Zone2Sel:SOURCE" appears in the display.
When "Zone2Sel:Off" is displayed, the output to the remote
zone is turned off.
Caution:
If you are not using the system in the remote Zone, always
press the ZONE 2 button consecutively to turn the ZONE 2
function off.
Notes:
• If the source for the main zone is selected as the source for the
remote zone and the source for the main zone is changed, then
the source for the remote zone will change as well.
• In the remote zone, you can only play the source in the 2-
channel mode. You cannot play the source in the remote zone
in the surround mode.
• You can only play the source in the Stereo mode or Direct
mode in the main zone, when you are playing the source in the
remote zone.
• If the Rec Out button is pressed in the main room while
someone is using the system in the remote zone, the Zone 2
function will be deactivated and the source will turn off in the
remote zone.
• The Zone 2 terminal is an analog output. Digital signals are not
output. If no sound is heard from the selected input source,
check if the component is connected to the analog inputs.
• Please note that some third-party multi-room system
components may not be fully compatible with the Onkyo
multi-room system components.
ON
AUDIO
TRACK
REC
DVD
INPUT T1
V1
SELECTOR
STEREO
1
buttons SURROUND
L AUDIO R 4
Re-EQ
TX-DS 787
7
LATE NIGHT
+ 10
HOME THEATER CONTROLLER
VOL
MUTING
DISC
OPEN/CLOSE
CD
T2 TUN PH
V2 V3 V –
DIRECT DSP
2 3
THX DSP
5 6
CH SEL LEVEL +
8 9
DIMMER LEVEL –
0 ENT
RC-390M
