Installation Manual
WARNING: For your safety the
information in this manual must be
followed to minimize the risk of fire or
explosion or to prevent property damage,
personal injury or death.
Do not store or use gasoline or other flammable
vapor and liquids in the vicinity of this or any
other appliance.
WHAT DO YOU DO IF YOU SMELL GAS
* Do not try to light any appliance.
* Do not touch any electrical switch; do not use
any phone in your building.
* Clear the room, building or area of all
occupants.
* Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
* If you cannot reach your gas supplier, call the
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
070398JEV/abe
ML-130
AVERTISSEMENT: Assurez-vous de bien
suivre les instructions données dans cette
notice pour réduire au minimum le risque
d'incendie ou d'explosion ou pour éviter tout
dommage matériel, toute blessure ou la mort.
Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflammables dans
le voisinage de cet appareil ou de tout autre
appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR
DE GAZ:
* Ne pas tenter d'allumer d'appareil.
* Ne touchez à aucun interrupteur. Ne pas
vous servir des téléphones se trouvant dans
le bâtiment où vous vous trouvez..
* Évacuez la pièce, le bâtiment ou la zone.
* Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions
du fournisseur.
* Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
L'installation et l'entretien doivent être assurés
par un installateur ou un service d'entretien
qualifié ou par le fournisseur de gaz.
For replacement parts, contact the distributor from which the dryer
American Dryer Corporation
Fall River MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
E-mail: techsupport@amdry.com
was purchased or
88 Currant Road
ADC Part No. 113002

Advertisement

Table of Contents
loading

Related Manuals for American Dryer Corp. ML-130

Summary of Contents for American Dryer Corp. ML-130

  • Page 1 For replacement parts, contact the distributor from which the dryer was purchased or American Dryer Corporation 88 Currant Road Fall River MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com...
  • Page 2 Retain This Manual In A Safe Place For Future Reference American Dryer Corporation products embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of safe, efficient, and trouble-free operation. ONLY qualified technicians should service this equipment.

  • Page 3: For Your Safety

    IMPORTANT YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and THE GAS SUPPLY or THE STEAM SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUST- ING, INSTALLATION, or TESTING OF ANY EQUIPMENT per OSHA (Occupational Safety and Health Administration) STANDARDS.
  • Page 4 WARNING The dryer must never be operated with any of the back guards, outer tops, or service panels removed. PERSONAL INJURY or FIRE COULD RESULT. WARNING DRYER MUST NEVER BE OPERATED WITHOUT THE LINT FILTER/SCREEN IN PLACE, EVEN IF AN EXTERNAL LINT COLLECTION SYSTEM IS USED. IMPORTANT PLEASE OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment and/or specified in the installation and operator's manual included with the dryer.

  • Page 5: Table Of Contents

    Table of Contents SECTION I IMPORTANT INFORMATION A. Receiving and Handling ....................... 3 B. Safety Precautions ........................4 SECTION II SPECIFICATIONS/COMPONENT IDENTIFICATION A. Specifications ..........................7 B. Component Identification......................8 SECTION III INSTALLATION PROCEDURES A. Location Requirements......................10 B. Unpacking/Setting Up ........................11 C.
  • Page 6 SECTION VI ROUTINE MAINTENANCE A. Cleaning ........................... 44 B. Adjustments ..........................45 C. Lubrication ..........................45 SECTION VII REVERSING TIMER SPIN/DWELL ADJUSTMENTS ........SECTION VIII PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT COMPONENTS ....................

  • Page 7: Important Information

    SECTION I IMPORTANT INFORMATION A. RECEIVING and HANDLING The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover (or optional box) as a means of preventing damage in transit. Upon delivery, the dryer and/or packaging, and wooden skid should be visually inspected for shipping damage.

  • Page 8: Safety Precautions

    B. SAFETY PRECAUTIONS WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury, or loss of life. WARNING: The dryer must never be operated with any of the back guards, outer tops, or service panels removed.
  • Page 9 7. A program should be established for the inspection and cleaning of lint in the burner area, exhaust duct work, and area around the back of the dryer. The frequency of inspection and cleaning can best be determined from experience at each location. WARNING: The collection of lint in the burner area and exhaust duct work can create a potential fire hazard.

  • Page 10: A. Specifications

    SECTION II SPECIFICATIONS/COMPONENT IDENTIFICATION A. SPECIFICATIONS 130 lbs. 60 kg AXIMUM APACITY DRY WEIGHT 44-1/2" 113 cm ASKET TUMBLER I AM ETER 42-1/2" 107.9 cm ASKET TUMBLER EPTH 3/4 HP .560 kw ASKET OTOR 3 HP 2.238 kw LOWER OTOR 31-3/8"...

  • Page 11: Specifications

    Specifications MLG-130 (Gas) MLE-130 (Electric) MLS-130 (Steam) EXHAUST DIM. DIM. DUCT DIA. "A" "B" GAS and 12" (30.5 cm) 11-1/4" (28.6 cm) 9-1/2" (24.1 cm) ELECTRIC STEAM 16" (40.6 cm) 9" (22.9 cm) 9" (22.9 cm) NOTE: ADC reserves the right to make changes in specifications at any time, without notice or obligation.

  • Page 12: Component Identification

    B. COMPONENT IDENTIFICATION 1. DRYER FRONT VIEW Illus. No. Description Microprocessor Control/Keyboard Panel Assembly (Controls) Control (Top Access) Door Assembly Main Door Assembly Lint Door Assembly Lint Drawer Emergency Stop Button Wire Diagram (located behind Control Door) Top Console (Module) Assembly...
  • Page 13 2. DRYER REAR VIEW Illus. No. Description Basket (drive) Motor Assembly Blower Motor Mount Assembly Impellor (fan/blower) Assembly Idler Bearing Mount Assembly Tumbler Bearing Mount Assembly Electric Service Relay Box Heating Unit Data Label and Installation Label * Electric service connections are made in this box.

  • Page 14: Installation Procedures

    SECTION III INSTALLATION PROCEDURES Installation should be performed by competent technicians in accordance with local and state codes. In the absence of these codes, the installation must conform to applicable AMERICAN NATIONAL STANDARDS: ANSI.Z223.1-LATEST EDITION (National Fuel Gas Code) ANSI/NFPA NO. 70-LATEST EDITION (National Electric Code) In CANADA, the installation must conform to CANADIAN STANDARDS: CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (L.P.

  • Page 15: Unpacking/Setting Up

    B. UNPACKING/SETTING UP Remove protective shipping material (i.e., plastic wrap, and/or optional shipping box) from dryer. IMPORTANT: Dryer must be transported and handled in an upright position at all times. The dryer can be moved to its final location while still attached to the skid or with the skid removed.
  • Page 16 4) Disconnect the (2) pin connector from the Phase 6 Microprocessor Controller (computer). Refer to the wiring diagram on the Control Door. 5) Disconnect the ground (GND) wire from the Phase 6 Microprocessor Controller (computer). NOTE: b 2 and b 3 apply only to models manufactured after August 1997. Models manufactured prior August 1997 require a Pin Extraction Tool (ADC Part No.

  • Page 17: Dryer Enclosure Requirements

    C. DRYER ENCLOSURE REQUIREMENTS Even though a 12-inch clearance is acceptable, it is recommended that the rear of the dryer be positioned approximately two (2) feet (24-inches) from the nearest obstruction (i.e., wall) for ease of installation, maintenance, and service. Bulkheads and partitions should be made from noncombustible materials. The clearance between the bulkhead header and the dryer must be a minimum of four (4) inches and must not extend more than four (4) inches to the rear of the front.

  • Page 18: Fresh Air Supply Requirements

    D. FRESH AIR SUPPLY REQUIREMENTS When the dryer is operating, it draws in room air, heats it, passes this air through the basket (tumbler), and exhausts it out of the building. Therefore, the room air must be continually replenished from the out- doors.

  • Page 19: Exhaust Requirements

    E. EXHAUST REQUIREMENTS 1. General Exhaust Duct Work Information Exhaust duct work should be designed and installed by a qualified professional. Improperly sized duct work will create excessive back pressure which results in slow drying, increased use of energy, overheating of the dryer, and shutdown of the burner by the airflow (sail) switches, burner hi-limits, or basket (tumbler) hi-heat thermostats.
  • Page 20 a. Outside Duct Work Protection 1) To protect the outside end of horizontal duct work from the weather, a 90° elbow bent down- ward should be installed where the exhaust exits the building. If the duct work travels vertically up through the roof, it should be protected from the weather by using a 180° turn to point the opening downward.
  • Page 21 It is suggested that the duct work from each dryer (minimum of 14-inches for a gas dryer or a 72 Kw electric dryer and 16-inches for a steam dryer or an 80 Kw electric dryer) not exceed twenty (20) feet with no more than two (2) elbows (excluding dryer connection).
  • Page 22 14-inch (minimum for gas dryers or 72 Kw electric dryers) or 16-inch (minimum for steam dryers or 80 Kw electric dryers) duct is added. IMPORTANT: The ML-130 is not provided with a back draft damper. When exhausted into a multiple (common) exhaust line, a back draft damper must be installed at each dryer duct.
  • Page 23 IMPORTANT: Exhaust back pressure measured by a manometer in the exhaust duct should not exceed 0.3 inches of water column. The duct work should be smooth inside with no projections from sheet metal screws or other obstructions which will collect lint. When adding ducts, the duct to be added should overlap the duct to which it is to be connected.
  • Page 24 MULTIPLE DRYER VENTING (MLG-130 and MLE-130) with 80 Kw Electric Oven with 16” Diameter (2,500 cfm) Exhaust Connections At Common Duct MULTIPLE DRYER VENTING (MLS-130) with 14” Diameter (2,750 cfm) Exhaust Connections At Common Duct...

  • Page 25: Electrical Information

    F. ELECTRICAL INFORMATION 1. Electrical Requirements It is your responsibility to have ALL electrical connections made by a properly licensed and competent electrician to assure that the electrical installation is adequate and conforms with local and state regulations or codes. In the absence of such codes, ALL electrical connections, material, and workmanship must conform to the applicable requirements of the National Electrical Code ANSI NFPA NO.70-LATEST EDITION, or in CANADA, the Canadian Electrical Codes Parts 1 &...
  • Page 26 2. Electrical Service Specifications MLG-130 (Gas) MLS-130 (Steam) (per dryer) LECTRIC ERVICE PECIFICATIONS IMPORTANT: 208 VAC and 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage. NOTE: A. Fuse ratings are dual-element, time-delay, current limiting, class RK1 or RK5 ONLY. B.
  • Page 27 MLE-130 (72 Kw E LECTRIC (per dryer) LECTRIC ERVICE PECIFICATIONS IMPORTANT: 208 VAC and 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage . NOTE: A. Fuse ratings are dual-element, time-delay, current limiting, class RK1 or RK5 ONLY. B.
  • Page 28 MLE-130 (80 Kw E LECTRIC (per dryer) LECTRIC ERVICE PECIFICATIONS IMPORTANT: 208 VAC and 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage . NOTE: A. Fuse ratings are dual-element, time-delay, current limiting, class RK1 or RK5 ONLY. B.
  • Page 29 3. Electrical Connections NOTE: A wire diagram is located in the front electrical control box for connection data. The only electrical input connections to the dryer are the 3-phase (3ø) power leads (L1,L2, and L3), GROUND, and in the case of 4 wire service, the NEUTRAL. Providing local codes permit, power connections to the dryer can be made by use of a flexible underwriters laboratory list cord/pigtail (wire must conform to ratings of the dryer), or the dryer can be hard wired directly to the service breaker.
  • Page 30 4. GROUNDING Grounding (earth) connections must be provided and installed in accordance with state and local codes. In the absence of these codes, grounding must conform to applicable requirements of the National Electrical Code ANSI/NFPA NO. 70-LATEST EDITION, or in CANADA, the Canadian Electrical Codes Parts 1 &...

  • Page 31: Gas Information

    G. GAS INFORMATION It is your responsibility to have ALL plumbing connections made by a qualified professional to assure that the gas plumbing installation is adequate and conforms with local and state regulations or codes. In the absence of such codes, ALL plumbing connections, materials, and workmanship must conform to the applicable requirements of the National Fuel Gas Code ANSI Z223.1-LATEST EDITION, or in CANADA, the Canadian Installation Codes CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (L.P.
  • Page 32 2. Technical Data a. Gas Specifications Type of Gas Natural Gas Liquid Propane Gas Manifold Pressure* 3.5 - 4.0 inches W.C. 10.5 - 11.0 inches W.C. Inline Pressure 6.0 - 12.0 inches W.C. 11.0 inches W.C. * Measured at the gas valve pressure tap when the gas valve is on. b.
  • Page 33 3. Piping/Connections ALL components/materials must conform to National Gas Code Specifications, or in CANADA, the Canadian Installation Codes (for General Installation and Plumbing). It is important that gas pressure regulators meet applicable pressure requirements and that gas meters be rated for the total amount of ALL the appliance BTU's being supplied.
  • Page 34 IMPORTANT: The dryer and its individual shut-off valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5 kPa). NOTE: The dryer must be isolated from the gas supply piping system by closing its individual manual shut-off valve during any pressure test of the gas supply system at test pressures equal to or less than 1/2 psig (3.5 kPa)

  • Page 35: Steam Information

    H. STEAM INFORMATION It is your responsibility to have ALL plumbing connections made by a qualified professional to assure that the gas plumbing installation is adequate and conforms with local and state regulations or codes. IMPORTANT: Failure to comply with the requirements stipulated in this manual can result in component failure which will VOID THE WARRANTY.
  • Page 36 b. The steam supply piping to the dryer must include a 12-inch rise along with a drip trap and check valve. This will prevent any condensate from entering the steam coil. c. Flexible hoses or couplings must be used. The dryer vibrates slightly when it runs and this will cause the steam coil connections to crack if they are hard piped to the supply and return mains.
  • Page 37 4. Steam Damper Air System Connections The M-130 is manufactured with a pneumatic (piston) damper system which requires an external supply of compressed air. The air connection is made to the steam damper solenoid valve which is located at the rear inner top area of the dryer just in front of the electric service relay box. (Refer to the bottom illustration on page 34).
  • Page 38 5. Steam Damper Air Piston (Flow Control) Operation Adjustment Although the steam damper operation was tested and adjusted prior to shipping at 80 PSI, steam damper operation must be checked before the dryer is put into operation. Refer to page 37 or instructions to check steam damper operation.

  • Page 39: Preparation For Operation/Start-Up

    I. PREPARATION FOR OPERATION/START-UP The following items should be checked before attempting to operate the dryer: 1. Read ALL "CAUTION," "WARNING," and "DIRECTION" labels attached to the dryer. 2. Check incoming supply voltage to be sure that it is the same as indicated on the dryer data label located in the front top console area as shown in the illustration on page 9.

  • Page 40: Preoperational Tests

    J. PREOPERATIONAL TESTS ALL dryers are thoroughly tested and inspected before leaving the factory. However, a preoperational test should be performed before the dryer is publicly used. It is possible that adjustments have changed in transit or due to marginal location (installation) conditions. 1.
  • Page 41 IMPORTANT: There is no regulator provided in an L.P. dryer. The water column (W.C.) pressure must be regulated at the source (L.P. tank) or an external regulator must be added to each dryer. b. Electric Models 1) Check the oven contactor(s) to insure that the electric oven is cycling properly. c.
  • Page 42 8. Each dryer should be operated through one (1) complete cycle to assure that no further adjustments are necessary and that ALL components are functioning properly. 9. Make a complete operational check of ALL operating controls. a. Microprocessor controller (computer) programs/selections... 1) Each microprocessor controller (computer) has be preprogrammed by the factory with the most commonly used parameter (program) selections.

  • Page 43: Operating Instructions

    K. OPERATING INSTRUCTIONS NOTE: Before attempting to start the dryer that the main door is closed and the lint drawer is securely in place. 1. To start the dryer: a. Microprocessor (computer) dryers... 1) Display L.E.D. (light emitting diode) display will read “REAdY” (meaning no cycle in progress). 2) Press the letter on the keyboard (touchpad) corresponding to the cycle desired (i.e., Key “E”)...

  • Page 44: Shut Down Instructions

    L. SHUT DOWN INSTRUCTIONS If the dryer is to be shut down (taken out of service) for a period of time, the following MUST BE performed; 1. Discontinue power to the dryer either at the external disconnect switch or the circuit breaker. 2.

  • Page 45: Service/Parts Information

    SECTION IV SERVICE/PARTS INFORMATION A. SERVICE 1. Service must be performed by a qualified trained technician, service agency, or gas supplier. If service is required, contact the distributor from whom the ADC equipment was purchased. If the distributor cannot be contacted or is unknown, contact the ADC Service Department for a distributor in your area.

  • Page 46: Warranty Information

    SECTION V WARRANTY INFORMATION A. RETURNING WARRANTY CARD(S) 1. Before any dryer leaves the ADC factory test area, a warranty card (ADC Part No. 112254) is placed on the back side of the main door glass. These warranty cards are intended to serve the customer where we record the individual installation date and warranty information to better serve you should you file a warranty claim.
  • Page 47 2. Each part must be tagged with the following information: a. Model number and serial number of the dryer from which part was removed. b. Nature of failure (be specific). c. Date of dryer installation. d. Date of part failure. e.

  • Page 48: Routine Maintenance

    SECTION V ROUTINE MAINTENANCE A. CLEANING A program and/or schedule should be established for periodic inspection, cleaning, and removal of lint from various areas of the dryer, as well as throughout the duct work system. The frequency of cleaning can best be determined from experience at each location. Maximum operating efficiency is dependent upon proper air circulation.

  • Page 49: Adjustments

    90 DAYS Remove lint from around basket (tumbler), drive motors, and surrounding areas. Remove lint from the gas valve burner area with a dusting brush or vacuum clearer attachment. NOTE: To prevent damage, avoid cleaning and/or touching the Hot Surface Ignitor. Remove lint accumulation from inside the control box and at rear area behind the control box.

  • Page 50: Reversing Timer Spin/Dwell Adjustments

    SECTION VII PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT COMPONENTS 1. Microprocessor (computer) Board a. Upon completing installation of the replacement microprocessor (computer) board, reestablish power to the dryer. b. Start the drying cycle by pressing any of the preset cycles in letters A-F. c.
  • Page 51 Verify that the motor(s) heat, and door indicator lights on the back side of the microprocessor (computer) board are lit. (Refer to the illustration below.) "FAN" (Blower) L.E.D. indicator "FOR" (Forward) output L.E.D. indicator "Rev" (Reverse) output L.E.D. indicator "Air" (Air Jet) output L.E.D. indicator "HT 1"...
  • Page 52 e. Open main door. The dryer must stop and ALL indicator dots of the microprocessor (computer) L.E.D. (light emitting diode) display must go out. (Refer to illustration on page 47.) f. Try to restart the dryer with the main door open. g.
  • Page 53 ADC 113002 1- 08/12/97-50 2* 12/19/97-50 3* 10/21/98-50 4* 01/12/99-50 5* 01/05/00-16 6- 01/19/00-20 7- 08/03/00-25 8* 11/22/00-25...
