ML-122 / MLG-122DR
Installation Manual
Phase 7 / Non-Coin / Dual Timer / F.S.S.
! ! ! ! !
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death or
property damage.
– Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
● ● ● ● ●
Do not try to light any appliances.
● ● ● ● ●
Do not touch any electrical switch;
do not use any phone in your
building.
● ● ● ● ●
Clear the room, building or area of
all occupants.
● ● ● ● ●
Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
● ● ● ● ●
If you cannot reach your gas
supplier, call the fire department.
– Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
! ! ! ! !
AVERTISSEMENT:
RISQUE D'INCENDIE OU D'EXPLOSION
Le non-respect des avertissements de
sécurité pourrait entraîner des blessures
graves, la mort ou des dommages
matériels.
– N'entreposer pas et n'utilisez pas
d'essence ni d'autres vapeurs ou
liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
– QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ
● ● ● ● ●
Ne tentez pas d'allumer d'appareil.
● ● ● ● ●
Ne touchez à aucun interrupteur. Ne
vous servez pas des téléphones se
trouvant dans le bâtiment où vous
vous trouvez.
● ● ● ● ●
Évacuez la pièce, le bâtiment ou la zone.
● ● ● ● ●
Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
● ● ● ● ●
Si vous ne pouvez rejoindre le
fournisseur de gaz, appelez le service
des incendies.
– L'installation et l'entretien doivent être
assurés par un installateur ou un service
d'entretien qualifié ou par le fournisseur
de gaz.
American Dryer Corporation
88 Currant Road, Fall River MA 02720-4781 USA
Telephone: +1 (269) 923-3000 / Fax: +1 (508) 678-9447
e-mail: mdl-service@whirlpool.com / www.adclaundry.com
ADC Part No. 113363 - 37
Advertisement
Table of Contents
Related Manuals for American Dryer Corp. MLG-122DR
Summary of Contents for American Dryer Corp. MLG-122DR
- Page 1 ML-122 / MLG-122DR Installation Manual Phase 7 / Non-Coin / Dual Timer / F.S.S. ! ! ! ! ! ! ! ! ! ! WARNING: AVERTISSEMENT: FIRE OR EXPLOSION HAZARD RISQUE D’INCENDIE OU D’EXPLOSION Failure to follow safety warnings exactly...
- Page 2 Retain This Manual in a Safe Place for Future Reference This product embodies advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of safe, efficient, and trouble free operation. Only qualified technicians should service this equipment. OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included with the dryer.
- Page 3 In the State of Massachusetts, the following installation instructions apply: ■ Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gasfitter qualified or licensed by the State of Massachusetts. ■ If using a ball valve, it shall be a T-handle type. IMPORTANT YOU MUST DISCONNECT AND LOCKOUT THE ELECTRIC SUPPLY AND THE GAS SUPPLY OR THE STEAM SUPPLY BEFORE ANY COVERS OR GUARDS...
- Page 4 WARNING UNDER NO CIRCUMSTANCES should the dryer door switch, the lint drawer switch, or the heat safety circuit ever be disabled. DO NOT MODIFY THIS APPLIANCE. The dryer must never be operated with any of the back guards, outer tops, or service panels removed.
-
Page 5: Table Of Contents
SECTION I SAFETY PRECAUTIONS .......................... 2 SECTION II SPECIFICATIONS/COMPONENT IDENTIFICATION ................5 A. ML-122 Specifications ............................ 5 B. MLG-122DR Specifications ..........................7 C. Component Identification ..........................9 SECTION III INSTALLATION PROCEDURES ......................11 A. Location Requirements ..........................11 B. Unpacking/Setting Up ..........................12 C. -
Page 6: Safety Precautions
SECTION I SAFETY PRECAUTIONS WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury, or loss of life. WARNING: The dryer must never be operated with any of the back guards, outer tops, or service panels removed. - Page 7 WARNING: DO NOT use heat for drying articles that contain plastic, foam, sponge rubber, or similarly textured rubberlike materials. Drying in a heated tumbler may damage plastics or rubber and may be a fire hazard. 8. The possible presence of residual quantities of aggressive or decomposed chemicals in the load may produce damage to the machine and harmful fumes.
- Page 8 CE ONLY IMPORTANT: This appliance must only be installed and operated in the country of destination indicated on the dryer’s data plate. If the appliance is to be installed and operated in a country other than the one indicated on the data plate, a data plate amendment must be obtained from American Dryer Corporation.
-
Page 9: Specifications/Component Identification
SECTION II SPECIFICATIONS/COMPONENT IDENTIFICATION A. ML-122 SPECIFICATIONS MAXIMUM CAPACITY (DRY WEIGHT) 120 lb 54.43 kg 112.09 cm TUMBLER DIAMETER 44-1/8” TUMBLER DEPTH 40-9/16” 103.02 cm 1,016.57 L TUMBLER VOLUME 35.90 cu ft TUMBLER / DRIVE MOTOR 1 hp 0.75 kW BLOWER / FAN MOTOR 3 hp 2.24 kW... - Page 10 ML-122 SPECIFICATIONS NOTE: ADC reserves the right to make changes in specifications at any time without notice or obligation. American Dryer Corp. 113363 - 37...
-
Page 11: Mlg-122Dr Specifications
B. MLG-122DR SPECIFICATIONS MAXIMUM CAPACITY (DRY WEIGHT) 120 lb 54.43 kg TUMBLER DIAMETER 44-1/8” 112.09 cm 103.02 cm TUMBLER DEPTH 40-9/16” TUMBLER VOLUME 35.90 cu ft 1,016.57 L TUMBLER/DRIVE MOTOR 1 hp 0.75 kW 2.24 kW BLOWER/FAN MOTOR 3 hp DOOR OPENING (DIAMETER) 31-3/8”... - Page 12 MLG-122DR SPECIFICATIONS NOTE: ADC reserves the right to make changes in specifications at any time without notice or obligation. American Dryer Corp. 113363 - 37...
-
Page 13: Component Identification
C. COMPONENT IDENTIFICATION 1. Dryer Front View Illus. No. Description Microprocessor Control/Keypad Panel Assembly (controls) Control (top access) Door Assembly Main Door Assembly Lint Panel Assembly Lint Door Wire Diagram (located behind control door) Top Console (module) Assembly 113363 - 37 www.adclaundry.com... - Page 14 2. Dryer Rear View Illus. No. Description Electrical Service Connections Top Console Heating Unit Relay/Wiring Box Data Label and Installation Label Air Connection Exhaust Transition Piece American Dryer Corp. 113363 - 37...
-
Page 15: Installation Procedures
SECTION III INSTALLATION PROCEDURES Installation should be performed by competent professional in accordance with local, state, and country codes. A. LOCATION REQUIREMENTS Before installing the dryer, be sure the location conforms to local, state, and country codes. In the absence of such codes or ordinances the installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or the Natural Gas and Propane Installation Code, CSA B149.1 or LATEST EDITION (for General Installation and Gas Plumbing). -
Page 16: Unpacking/Setting Up
B. UNPACKING/SETTING UP Remove protective shipping material (i.e., plastic wrap and/or optional shipping box) from dryer. IMPORTANT: Dryer must be transported and handled in an upright position at ALL times. The dryer can be moved to its final location while still attached to the skid or with the skid removed. To unskid the dryer, locate and remove the four (4) lag bolts securing the base of the dryer to the wooden skid. - Page 17 To Remove Top Console (module): a. Disconnect the ground wire (A in the illustration below) located at the rear upper left corner of the dryer. b. Remove the six (6) sets of nuts and washers (B in the illustration below) holding the console (module) to the base.
-
Page 18: Dryer Enclosure Requirements
C. DRYER ENCLOSURE REQUIREMENTS Bulkheads and partitions should be made of noncombustible material. NOTE: Allowances must be made for opening the control door. 38-inches (76.2 cm) for optimum opening of load door. The maximum thickness of the bulkhead for gas dryers is 4-inches (10.16 cm). For electric and steam dryers the maximum thickness of the bulkhead is 1-inch (2.54 cm) within 3-inches (7.62 cm) from the top of the control door. -
Page 19: Exhaust Requirements
It is not necessary to have a separate make-up air opening for each dryer. Common make-up air openings are acceptable. However, they must be set up in such a manner that the make-up air is distributed equally to ALL the dryers. EXAMPLE: For a bank of six (6) dryers, two (2) unrestricted openings measuring 3 feet by 3 feet (0.91 meters by 0.91 meters) are acceptable. - Page 20 When single dryer venting is used, the ductwork from the dryer to the outside exhaust outlet should not exceed 20 feet (6.09 meters). In the case of multiple (common) dryer venting, the distance from the last dryer to the outside exhaust outlet should not exceed 20 feet (6.09 meters). The shape of the ductwork is not critical as long as the minimum cross-sectional area is provided.
- Page 21 IMPORTANT: The minimum duct size for a gas unit is 16-inches (40.64 cm), (12-inches [30.4 cm] for MLG-122DR), for a round duct and 14-1/4” x 14-1/4” (36.2 cm x 36.2 cm), (10-3/4 x 10-3/4 [27.3 cm x 27.3 cm] for MLG-122DR), for a square duct. THE DUCT SIZE MUST NOT BE REDUCED ANYWHERE DOWNSTREAM OF THE DRYER.
- Page 22 (123.82 cm) apart. The main duct should be tapered, with the diameter increasing before each individual 16-inch (40.64 cm), (12-inches [30.4 cm] for MLG-122DR) duct. IMPORTANT: When exhausted into a multiple (common) exhaust line, a back draft damper must be installed at each dryer duct.
- Page 23 ML-122 Multiple Dryer Venting 16-Inch (40.64 cm) Diameter Minimum Exhaust Connections at Common Duct IMPORTANT: For extended ductwork runs, the cross section area of the ductwork can only be increased to an extent. Maximum proportional ductwork runs cannot exceed 20 feet (6.09 meters) more than the original limitations of 20 feet (6.09 meters) with two (2) elbows.
- Page 24 2-inches (5.08 cm) larger than the duct (all the way around). The duct must be centered within this duct. MLG-122DR Multiple Dryer Venting 12-Inch (30.48 cm) Diameter Minimum Exhaust Connections at Common Duct American Dryer Corp.
-
Page 25: Electrical Information
F. ELECTRICAL INFORMATION 1. Electrical Requirements It is your responsibility to have ALL electrical connections made by a properly licensed and competent electrician to ensure that the electrical installation is adequate and conforms to local and state regulations or codes. In the absence of such codes, ALL electrical connections, material, and workmanship must conform to the applicable requirements of the National Electrical Code ANSI/NFPA NO. - Page 26 b. Electric Models ONLY ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER) IMPORTANT: 208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage. NOTES: When fuses are used they must be dual element, time delay, current limiting, class RK1 or RK5 ONLY .
-
Page 27: Gas Information
NOTE: A CIRCUIT SERVICING EACH DRYER MUST BE PROVIDED. 4. Grounding A ground (earth) connection must be provided and installed in accordance with state and local codes. In the absence of these codes, grounding must conform to applicable requirements of the National Electrical Code ANSI/NFPA NO. - Page 28 * Measured at the gas valve pressure tap when the gas valve is on. b. Gas Connections: Inlet connection ______1-1/4” F.P.T. Inlet supply size ______1-1/4” Diameter Pipe (minimum) Btu/hr input _________415,000 (104,580 kcal/hr) 300,000 (75,650 kcal/hr) for MLG-122DR American Dryer Corp. 113363 - 37...
- Page 29 Part No. Qty. D.M.S.* Part No. ML-122 415,000 104,580 140839 140819 882233 MLG-122DR 300,000 75,650 140863 — — — — Shaded areas are stated in metric equivalents * Drill Measurement Size (D.M.S.) equivalents are as follows: Natural Gas ......... #2 = 0.2210” (5.6134 mm).
- Page 30 NOTE: A consistent water column test pressure of 3.5 inches (8.7 mb) for natural gas and 10.5 inches (26.1 mb) for propane dryers is required at the gas valve pressure tap of each dryer for proper and safe operation. A plugged tap 1/8” N.P.T. minimum, accessible for a pressure gauge connection, must be installed in the main gas supply line immediately upstream of the dryers.
-
Page 31: Steam Information
H. STEAM INFORMATION It is your responsibility to have ALL plumbing connections made by a qualified professional to ensure that the gas plumbing installation is adequate and conforms to local and state regulations or codes. IMPORTANT: Failure to comply with the requirements stipulated in this manual can result in component failure, which will VOID THE WARRANTY. - Page 32 d. Shutoff valves for each dryer should be installed in the supply line, return line, and drip trap return line. This will allow the dryer to be isolated from the supply main and the return main if the dryer needs maintenance work.
- Page 33 a. Air Requirements Compressed Air Pressure Air Supply 5.51 bar Normal 80 psi Minimum Supply 70 psi 4.82 bar Maximum Supply 90 psi 6.21 bar Shaded areas are stated in metric equivalents b. Air Connection Air connection to system — 1/4” quick connection c.
-
Page 34: Water Information
6. Steam Damper Air Piston (Flow Control) Operation Adjustment Although the steam damper operation was tested and adjusted prior to shipping at 80 psi (5.51 bar), steam damper operation must be checked before the dryer is put into operation. Refer to page 34 for instructions to check steam damper operation. - Page 35 INSTALLATION 1. Requirements The fire suppression system must be supplied with a minimum water pipe size of 1/2” and be provided with 40 psi +/- 20 psi (2.75 bar +/- 1.37 bar) of pressure. For use of optional manual bypass, a second source with the same piping and pressure requirements is required.
- Page 36 OPTIONAL MANUAL BYPASS Provisions are made in the dryer’s fire suppression system for the installation of an optional manual bypass. Depending on the model dryer, the connections for the manual bypass are made at the “T” or “three way” fitting located in the outlet supply side of the water solenoid valve.
-
Page 37: Preparation For Operation/Start-Up
WARNING: Electrical power must be provided to the dryer at ALL times. If the main electrical power supply to the dryer is disconnected, the fire suppression system is INOPERATIVE!! WARNING: ELECTRICAL SHOCK HAZARD – Electrical shock hazard can result in serious injury. -
Page 38: Preoperational Test
K. PREOPERATIONAL TEST ALL dryers are thoroughly tested and inspected before leaving the factory. However, a preoperational test should be performed before the dryer is publicly used. It is possible that adjustments have changed in transit or due to marginal location (installation) conditions. Installer must instruct the user on how to correctly operate the dryer before leaving. -
Page 39: Preoperational Instructions
6. Make a complete operational check of ALL safety-related circuits (i.e., lint drawer switch, and sail switch on gas models). NOTE: To check for proper sail switch operation, open the main door and while holding main door switch plunger in, start the dryer. The dryer should start but the heat circuit should not be activated (on). - Page 40 NOTE: Press and hold the “UP ARROW” to view the tumbler temperature at any time. NOTE: The dryer can be stopped at any time by pressing the “STOP/CLEAR” key, at this time the dryer will go into a cycle pause. If the “STOP/CLEAR” key is pressed again at this point, the cycle that was in progress will be cancelled and returned to the “READY”...
-
Page 41: Compressed Air Requirements
M. COMPRESSED AIR REQUIREMENTS The dryer requires an external supply of compressed air (3.25 cfh at 80 psi [0.09 cmh at 5.51 bar] for gas models and 4.25 cfh at 80 psi [0.12 cmh at 5.51 bar] for steam models). For steam models, compressed air is necessary for the standard air operated steam damper. -
Page 42: Shutdown Instructions
N. SHUTDOWN INSTRUCTIONS If the dryer is to be shut down (taken out of service) for a period of time, the following must be performed: 1. Discontinue power to the dryer either at the external disconnect switch or the circuit breaker. 2. -
Page 43: Service/Parts Information
SECTION IV SERVICE/PARTS INFORMATION A. SERVICE Service must be performed by a qualified trained technician, service agency, or gas supplier. If service is required, contact the reseller from whom the ADC equipment was purchased. If the reseller cannot be contacted or is unknown, contact the ADC Service Department for a reseller in your area. -
Page 44: Warranty Information
SECTION V WARRANTY INFORMATION A. RETURNING WARRANTY CARDS Before any dryer leaves the ADC factory test area, a warranty card is placed on the back side of the main door glass. These warranty cards are intended to serve the customer where we record the individual installation date and warranty information to better serve you should you file a warranty claim. - Page 45 2. Each part must be tagged with the following information: a. Model number and serial number of the dryer from which part was removed. b. Nature of failure (be specific). c. Date of dryer installation. d. Date of part failure. e.
-
Page 46: Routine Maintenance
SECTION VI ROUTINE MAINTENANCE A. CLEANING A program and/or schedule should be established for periodic inspection, cleaning, and removal of lint from various areas of the dryer, as well as throughout the ductwork system. The frequency of cleaning can best be determined from experience at each location. -
Page 47: Adjustments
90 DAYS Remove lint from around tumbler, drive motors, and surrounding areas. Remove lint from the gas valve burner area with a dusting brush or vacuum cleaner attachment. Remove lint accumulation from inside the control box and at rear area behind the control box. 6 MONTHS Inspect and remove lint accumulation in customer furnished exhaust ductwork system and from dryer’s internal exhaust ducting. -
Page 48: Manual Reset Burner Hi-Limit Instructions
SECTION VII MANUAL RESET BURNER HI-LIMIT INSTRUCTIONS A. PHASE 7 This dryer was manufactured with a manual reset burner hi-limit thermostat, which is monitored by the Phase 7 computer. If the burner hi-limit is open prior to the start of the drying cycle, the dryer will start momentarily and then shut down, the Phase 7 computer will display “BURNER HIGH LIMIT FAULT”... -
Page 49: Data Label Information
SECTION VIII DATA LABEL INFORMATION STANDARD LABEL AGA LABEL When contacting ADC, certain information is required to ensure proper service/parts information from ADC. This information is on the data label that is affixed to the left side panel/wall area behind the control door. When contacting ADC please have the model number and serial number available. -
Page 50: Procedure For Functional Check Of Replacement Components
SECTION IX PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT COMPONENTS 1. Microprocessor Controller (Computer) Board a. Upon completing installation of the replacement microprocessor controller (computer) board, reestablish power to the dryer. b. Start the drying cycle by pressing any of the preset cycles in letters A-F. c. - Page 51 2. For Models with Direct Spark Ignition (DSI) Module (Type I) Theory of Operation: Start the drying cycle. When the gas burner ignites within the chosen trial for ignition time (6-seconds), the flame sensor detects gas burner flame and signals the DSI module to keep the gas valve open as long as there is a call for heat.
- Page 52 ADC Part No. 113363 37 - 09/20/21...
