American Dryer Corp. ML-55 Parts Manual

Phase 6 1997 thru 2000
Hide thumbs Also See for ML-55:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
ML-55 Parts Manual
Phase 6
1997 thru 2000
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
E-mail: techsupport@amdry.com
ADC Part No. 450172
012398WM/tf-m

Advertisement

Table of Contents
loading

Related Manuals for American Dryer Corp. ML-55

Summary of Contents for American Dryer Corp. ML-55

  • Page 1 ML-55 Parts Manual Phase 6 1997 thru 2000 American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com ADC Part No. 450172 012398WM/tf-m...
  • Page 2 For your convenience, log the following information: MODEL NO. __________________________________________ “IMPORTANT NOTE TO PURCHASER” POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables dans le voisinage de cet appareil ou de yout autre appareil. ML-55...

  • Page 3: Table Of Contents

    Table of Contents Control Door Assembly... 3 Phase 6 OPL Microprocessor Control Panel Assembly ... 4 Phase 6 OPL Microprocessor Control Box Assembly ... 5 Dual Timer Control Panel Assembly ... 6 Dual Timer Control Box Assembly ... 7 Front Panel/Main Door Assemblies with Mechanical Fasteners for models mfd.
  • Page 4 Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly ...26, 27 Hot Surface Ignition (HSI) Burner Assembly ...28, 29 Sail Switch/Hi-Limit Assemblies ... 30, 31 Air Operated Steam Damper Assembly ... 32, 33 Single Phase (1ø) Rear Electric Relay Panel Assembly... 34, 35 3-Phase (3ø) Motor, Non-Reversing Electric Relay Panel Assembly ...36, 37 3-Phase (3ø) Motor, Reversing Electric Relay Panel Assembly ...

  • Page 5: Control Door Assembly

    Control Door Assembly Illus. No. Part No. Qty. Description 112366 Logo ONLY 881869 White Control Door Assembly (includes illus. nos. 2, 3, and 8) For models mfd. as of October 24, 1997) 881694 Blue Control Door Assembly (includes illus. nos. 2, 3, and 8) For models mfd.

  • Page 6: Phase 6 Opl Microprocessor Control Panel Assembly

    Phase 6 OPL Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112537 Phase 6 OPL Keypad 112276 OPL Stick-on Labels (English Only) ... Not Illustrated 112275 OPL Stick-on Labels (Spanish, Italian, and Hebrew) ... Not Illustrated 112277 3 Language OPL Stick-on Labels (English, Spanish, and Hebrew) ...

  • Page 7: Phase 6 Opl Microprocessor Control Box Assembly

    Phase 6 OPL Microprocessor Control Box Assembly Illus. No. Part No. Qty. Description 881790 Burner Control Wiring 881851 Basket (Tumbler) Hi-Limit Temperature Sensor Harness 881850 Sail Switch Hi-Limit Harness 881852 Power Control Harness (for Non-Reversing Gas Models Only) 881853 Power Control Harness (for Reversing Gas Models Only) 881785 Door Switch Harness...

  • Page 8: Dual Timer Control Panel Assembly

    Illus. No. Part No. Qty. Description 123005 Red Indicator Light - 24 VAC 122400 Rocker Heat Selector Switch 824015 Dual Timer Control Panel Assembly Complete - 24 VAC (includes illus. nos. 1 through 21) 800051 Dual Timer Control Panel ONLY 131917 Push-to-Start Relay - 24 VAC 150207...

  • Page 9: Dual Timer Control Box Assembly

    Dual Timer Control Box Assembly Illus. No. Part No. Qty. Description 122601 9-Pin Socket Connector 122701 Socket Terminal ONLY 122801 Pin/Socket Extraction Tool 315010 9-Pin Connector Bracket 150300 #10 x 1/2” Hex Washer TEK Screw 150002 #6-32 x 1” Phillips Round Head Machine Screw 120715 30-Position Terminal Block 151000...

  • Page 10: Front Panel/Main Door Assemblies With Mechanical Fasteners

    Front Panel/Main Door Assemblies with Mechanical Fasteners for models mfd. as of January 16, 1998 American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 11: For Models Mfd. As Of January 16, 1998

    Front Panel/Main Door Assemblies with Mechanical Fasteners for models mfd. as of January 16, 1998 Illus. No. Part No. Qty. Description 881871 White Front Panel Assembly (includes illus. nos. 1, 12, and 13) 881697 Blue Front Panel Assembly (includes illus. nos. 1, 12, and 13) 102214 30”...

  • Page 12: Front Panel/Main Door Assemblies

    Front Panel/Main Door Assemblies for models mfd. between October 24, 1997 and January 16, 1998 American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 13: Front Panel/Main Door Assemblies

    Front Panel/Main Door Assemblies for models mfd. between October 24, 1997 and January 16, 1998 Illus. No. Part No. Qty. Description 881871 White Front Panel Assembly (includes illus. nos. 1, 11, and 12) 881697 Blue Front Panel Assembly (includes illus. nos. 1, 11, and 12) 102213 29-7/8”...

  • Page 14: For Models Mfd. Prior To October 24, 1997

    Illus. No. Part No. Qty. Description 881741 White Main Door Handle 881760 Blue Main Door Handle 151011 5/16-18 Acorn Nut 881552 White Main Door ONLY 881550 Blue Main Door ONLY 881816 White Main Door Assembly 881820 Blue Main Door Assembly (includes illus.

  • Page 15: Main Door Switch Assembly For Models Mfd. As Of October 24, 1997

    Main Door Switch Assembly for models mfd. as of October 24, 1997 Illus. No. Part No. Qty. Description 150006 #6-32 x 7/8” Phillips Pan Head Machine Screw 152013 #6-32 Hex Nut 153010 #6 Star Washer 137005 Single Pole Door Switch 150443 1/4-20 x 3/4”...

  • Page 16: Main Door Switch Assembly For Models Mfd. Prior To October 24, 1997

    Illus. No. Part No. Qty. Description 150006 #6-32 x 7/8” Phillips Pan Head Machine Screw 152013 #6-32 Hex Nut 153010 #6 Star Washer 137005 Single Pole Door Switch 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 881726 White Main Door Switch Housing ONLY 881698 White Main Door Switch with Housing Assembly (includes illus.

  • Page 17: Drop Lint Door Assembly

    Drop Lint Door Assembly Illus. No. Part No. Qty. Description 800150 Knob Latch Kit Assembly (includes illus. nos. 1 through 3) 160200 Knob Latch ONLY with 2 Screws (without cam) 160009 Knob Latch Adjustable Cam ONLY 150425 #12-24 x 3/8” Round Head Machine Screw ONLY (screw for Knob Latch Adjustable Cam) 157000 Drop Lint Door Spring...

  • Page 18: Lint Trap Assembly

    Illus. No. Part No. Qty. Description 800402 Non-Reversing Lint Trap Assembly Complete (includes illus. nos. 1, 3, 4, and 5) 800404 Non-Reversing Lint Trap ONLY 800407 Reversing Lint Trap Assembly Complete (includes illus. nos. 1, 3, 4, and 5) 800406 Reversing Lint Trap ONLY 154200 5/32”...

  • Page 19: Basket (Tumbler)/Supportassemblies

    Basket (Tumbler)/Support Assemblies Illus. No. Part No. Qty. Description 881774 Basket (Tumbler) ONLY with Felt Collar 881829 Non-Reversing Basket (Tumbler) and Support Assembly Complete (includes illus. nos. 1 through 10) 881777 Reversing Basket (Tumbler) and Support Assembly Complete (includes illus. nos. 1 through 10) 100902 5/16-18 x 31”...
  • Page 20 Sensor Bracket Assemblies Microprocessor Sensor Bracket Assembly Non-Computer Sensor Bracket Assembly MAN0238 American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 21: Sensor Bracket Assemblies

    Sensor Bracket Assemblies Illus. No. Part No. Qty. Description 880251 1/4" Temperature Sensor Probe Assembly (includes illus. nos. 1 and 5 through 8) 130103 225º Large Automatic Thermostat 153010 #6 Star Washer 152000 #6-32 Hex Nut 121028 Insulated Terminal ONLY 122701 Socket Terminal ONLY 122605...
  • Page 22 Tumbler Bearing Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 23: Tumbler Bearing Assembly

    Tumbler Bearing Assembly Illus. No. Part No. Qty. Description 880220 1-3/4” Flange Bearing with Nylock Set Screws 153005 3/8” Lock Washer 152005 3/8-16 Hex Nut 150508 3/8-16 x 3/4” Hex Head Machine Bolt 153005 3/8” Lock Washer 152005 3/8-16 Hex Nut 150600 3/8-16 x 1-1/2”...
  • Page 24 Idler Bearing Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 25: Idler Bearing Assembly

    Idler Bearing Assembly Illus. No. Part No. Qty. Description 100106 5L-690 V-Belt (idler to basket [tumbler]) 101140 14” x 3” Compound Pulley 100114 4L-630 V-Belt (idler to motor) 154301 5/16-18 x 1” Allen Set Screw 100705 3/16” x 3/16” x 1-3/8” Key 301850 5/8”...
  • Page 26 Non-Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 27: Non-Reversing Totally Enclosed, Fan-Cooled (T.e.f.c.) Motor Mount Assembly

    Non-Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly Illus. No. Part No. Qty. Description 100114 4L-630 V-Belt (motor to idler) 100701 3/16” x 3/16” x 1” Key 101133 5/8” x 2-1/4” Motor Pulley (for 60 Hz Models Only) 101130 5/8” x 2-1/2” Motor Pulley (for 50 Hz Models Only) 150501 5/16-18 x 3/4”...
  • Page 28 Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 29: Reversing Totally Enclosed, Fan-Cooled (T.e.f.c.) Motor Mount Assembly

    Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly Illus. No. Part No. Qty. Description 100114 4L-630 V-Belt (motor to idler) 100701 3/16” x 3/16” x 1” Key 101133 5/8” x 2-3/4” Motor Pulley (for 60 Hz Models Only) 101130 5/8” x 2-1/2” Motor Pulley (for 50 Hz Models Only) 120200 3/8”...

  • Page 31: Hot Surface Ignition (Hsi) Burner Assembly

    Hot Surface Ignition (HSI) Burner Assembly Illus. No. Part No. Qty. Description 318403 HSI (Hot Surface Ignition) Burner Shield 881597 Hot Surface Ignitor (HSI) - 24 VAC (2-1/2” length) 128921 HSI (Hot Surface Ignition) Flame Sensor 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 141105 Large Burner Tube 150103...
  • Page 32 Sail Switch/Hi-Limit Assemblies American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 33: Sail Switch/Hi-Limit Assemblies

    Sail Switch/Hi-Limit Assemblies Illus. No. Part No. Qty. Description 154004 Twin Speed Nut 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 802799 Sail Switch Box Cover and Bracket ONLY 150303 #4 x 3/4” Pan Head “A” Machine Screw 122200 Sail Switch ONLY (for Microprocessor [computer] Models Only) 122404...

  • Page 35: Air Operated Steam Damper Assembly

    Air Operated Steam Damper Assembly Illus. No. Part No. Qty. Description 165011 Steam Coil Assembly 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 152002 1/4-20 Hex Nut 153007 1/4” Lock Washer 820321 Steam Damper Hinge Assembly 803416 Steam Damper Assembly (includes illus.
  • Page 37 Single Phase (1ø) Motor, Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw -------- 24 VAC Transformer (refer to Step Down Transformer Usage Listing on page 46) 150247 #10 x 1/2” Hex Washer TEK Screw - Green 121010 L-70 Ground Lug 824828...

  • Page 39: 3-Phase (3Ø) Motor, Non-Reversing Electric Relay Panel Assembly

    3-Phase (3ø) Motor, Non-Reversing Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 150300 #10 x 1/2” Hex Washer TEK Screw -------- 24 VAC Transformer (refer to Step Down Transformer Usage Listing on page 46) 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 136008 Fuse Holder ONLY 136057...

  • Page 41: 3-Phase (3Ø) Motor, Reversing Electric Relay Panel Assembly

    3-Phase (3ø) Motor, Reversing Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 150300 #10 x 1/2” Hex Washer TEK Screw -------- 24 VAC Transformer (refer to Step Down Transformer Usage Listing on page 46) 137060 Arc Suppressor (A.S.) Board 137013 Nylon Standoff 132448...

  • Page 43: Dual Timer Non-Reversing Electrical Panel Assembly

    Dual Timer Non-Reversing Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 150300 #10 x 1/2” Hex Washer TEK Screw -------- 24 VAC Transformer (refer to Step Down Transformer Usage Listing on page 46) 132449 2-Pole Contact Block (for 208-240 volt models Only) 132445 3-Pole Contactor (for 120 volt models Only)

  • Page 45: Dual Timer Reversing Electrical Panel Assembly

    Dual Timer Reversing Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 132449 2-Pole Contact Block 132422 12 - 24 Volt Varistor 132448 Reversing Contactor with 24 VAC Coil 132447 Blower Motor Contactor 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 136008 Fuse Holder ONLY 136057...

  • Page 46: Outer Top/Back Guard Assemblies

    Illus. No. Part No. Qty. Description 322809 Back Electrical Box Cover 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 314414 Top Back Guard 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 312534 Outer Top (NO OUTER TOP on Gas Heat Reclaimer Models and Steam Models)

  • Page 47: Hot Surface Ignition (Hsi) Burner Assembly Specifications

    Hot Surface Ignition (HSI) Burner Assembly Specifications HSI Burner Orifice Listing* M odel Number Reclaimer ML-55 ML-55HR * Consult factory for elevations over 2,000 feet. HSI Burner Assembly Listing (for Microprocessor [computer] Models Only) M odel Btu/hr Number Rating ML-55...
  • Page 48 OW N OLTAGE ERVICE 3 or 4 240/380 460/480 460/480 NOTE: Each transformer requires one (1) Transformer Termination Kit (ADC Part No. 881763). American Dryer Corporation Step Down Transformer Usage Listing for Microprocessor (computer) Models ONLY RANSFORM ER SAGE ADC P 132070 132082 132082...

  • Page 49: Additional Parts Available

    Additional Parts Available Part No. Description 112039 “Black/White/Green Ground” Label 112280 “Clean Lint Screen” Label 112284 “Phase 6 OPL Program Location Summary” Label 114001 “CAUTION - Exhaust Lint Screen” Label 114006 “WARNING - Fire Hazards” Label 120100 3/8” Straight (BX) Connector 120300 3/8”...
