ML-55II Installation Manual
Warning: For your safety the information
in this manual must be followed to
minimize the risk of fire or explosion or to
prevent property damage, personal injury
or death.
— Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
— What To Do If You Smell Gas
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Clear the room, building or area of all
occupants.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
Phase 7, Non-Coin
Telephone: (508) 678-9000 / Fax: (508) 678-9447
Avertissement: Assurez-vous de bien
suivre les instructions données dans cette
notice pour réduire au minimum le risque
d'incendie ou d'explosion ou pour éviter
tout dommage matériel, toute blessure ou
la mort.
— Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflammables
à proximité de cet appareil ou de tout autre
appareil.
— Que Faire Si Vous Sentez Une
Odeur De Gaz
• Ne pas tenter d'allumer d'appareils.
• Ne touchez à aucun interrupteur. Ne
pas vous servir des téléphones se
trouvant dans le bâtiment.
• Évacuez la pièce, le bâtiment ou la
zone.
• Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
• Si vous ne pouvez rejoindre le
fournisseur de gaz, appelez le service
des incendies.
— L'installation et l'entretien doivent être
assurés par un installateur ou un service
d'entretien qualifié ou par le fournisseur de
gaz.
American Dryer Corporation
88 Currant Road
Fall River MA 02720-4781
e-mail:
techsupport@amdry.com
www.amdry.com
ADC Part No. 113345
Advertisement
Table of Contents
Related Manuals for American Dryer Corp. ML-55II
Summary of Contents for American Dryer Corp. ML-55II
- Page 1 ML-55II Installation Manual Phase 7, Non-Coin Warning: For your safety the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury or death. — Do not store or use gasoline or other flam- mable vapors and liquids in the vicinity of this or any other appliance.
- Page 2 Retain This Manual In A Safe Place For Future Reference American Dryer Corporation products embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of safe, efficient, and trouble free operation. ONLY qualified technicians should service this equipment.
-
Page 3: Table Of Contents
Important You must disconnect and lock out the electric supply and the gas supply or the steam supply before any covers or guards are removed from the machine to allow access for cleaning, adjusting, installation, or testing of any equipment per OSHA (Occupational Safety and Health Administration) standards. -
Page 4: Safety Precautions
AFETY RECAUTIONS Warning For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury, or loss of life. The dryer must never be operated with any of the back guards, outer tops, or service panels removed. -
Page 5: Specifications/Component Identification
PECIFICATIONS OMPONENT ________________ DENTIFICATION Note ADC reserves the right to make changes in specifications at any time without notice or obligation. Dryer Notes Ductwork size varies with installation conditions. Exhaust static pressure must be no less than 0 and must not exceed 0.3 inches (0.74 mb) water column. Steam Dryer Notes Operating height of steam dryer is 81-inches (205.74 cm). -
Page 6: Component Identification
Component Identification _____________ Dryer Front View Illus. No. Description Controls Control (top access) Door Assembly Main Door Assembly Lint Compartment Area (lint screen located behind door) Data Label and Installation Label Dryer Rear View Illus. No. Description Heating Unit 1/8” Compressed Air Supply Inlet (Note: located behind the electric service relay box on steam models only) Electric Service Relay Box... -
Page 7: Unpacking/Setting Up
Unpacking/Setting Up _________________ Remove protective shipping material (i.e., plastic wrap, and/ or optional shipping box) from dryer. Important Dryer must be transported and handled in an upright position at all times. The dryer can be moved to its final location while still attached to the skid or with the skid removed. -
Page 8: Fresh Air Supply Requirements
Important Even though a minimum of only 12-inches (30.48 cm) is required, 18-inches (45.72 cm) or more is suggested. The additional clearance is advantageous for ease of installation and service. Fresh Air Supply Requirements _______ When the dryer is operating, it draws in room air, heats it, passes this air through the basket (tumbler), and exhausts it out of the building. - Page 9 suggested that the use of 90° turns be avoided; use 30° and/or 45° angles instead. The radius of the elbows should preferably be 1-1/2 times the diameter of the duct. Including basket (tumbler)/dryer elbow connections or elbows used for outside protection from the weather, no more than one (1) elbow should be used in the exhaust duct run.
-
Page 10: Electrical Information
Important For extended ductwork runs, the cross section area of the ductwork only increased to an extent. When the ductwork approaches the maximum limits noted in this manual, a professional heating, ventilating, and air-conditioning (HVAC) firm should be consulted proper venting information. -
Page 11: Electrical Connections
Electrical Service Specifications Important Figures shown are for non-reversing models only. For reversing models contact the factory. Gas and Steam Models only ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER) MPORTANT: 208 VAC and 240 VAC ARE NOT THE SAME. When ordering, specify exact voltage. NOTES: A. - Page 12 Single-Phase Electrical Lead Connections White or Red Black Neutral Positive or L2 For 110V Applications For 208-230/240V Applications A ground lug is provided in the rear electrical box to connect your service ground. 3-Phase (3ø) Wiring Connections/Hookup The electrical connections on all 3-phase (3ø) gas and steam dryers are made into the rear service box located at the upper left area of the dryer.
-
Page 13: Gas Information
The electrical input connections are made at the electric oven contactor located inside the assembly at the rear center upper section of the dryer. The ground connection is made to a copper lug also provided in this area. To gain access, remove oven rear service cover. -
Page 14: Steam Information
TYPE OF GAS Natural Btu/hr kcal/hr Rating Rating Qty. D.M.S.* Part No. 160,000 40,320 140820 Liquid Propane Conversion Kit Part Number 881598 Shaded area is stated in metric equivalent * Drill Measurement Size (D.M.S.) equivalents are as follows: Natural Gas ... #29 = 0.1360” (3.4544 mm). Liquid Propane Gas .. -
Page 15: Installation Instructions
Operating Steam Pressure Maximum 125 psig* Heat Input (Normal Load) Consumption (Approximate) 144.7 lbs/hr Shaded areas are stated in metric equivalents *The minimum operating pressure is 100 psig (689.47 kPa) for optimum results. Installation Instructions To ensure an adequate supply of steam is provided, be sure that the steam supply lines and steam return lines are sized and laid out as stipulated in this manual. - Page 16 Steam Damper Air System Connections The dryer is manufactured with a pneumatic (piston) damper system, which requires an external supply of compressed air. The air connection is made to the steam damper solenoid valve, which is located at the rear inner top area of the dryer just in front of the electric service relay box.
-
Page 17: Preparation For Operation/Start-Up
Preparation For Operation/Start-Up ___ The following items should be checked before attempting to operate the dryer: • Read all “CAUTION,” “WARNING,” and “DIRECTION” labels attached to the dryer. • Check incoming supply voltage to be sure that it is the same as indicated on the dryer data label. -
Page 18: Preoperational Instructions
Check the electric service phase sequence (3-phase [3ø] models only). While the dryer is operating, check to see if the blower wheel (impellor/fan) is rotating in the proper direction. Looking from the front, the blower wheel (impellor/fan) should spin in the clockwise (CW) direction. If it is, the phasing is correct. -
Page 19: Service/Parts Information
ERVICE ARTS NFORMATION Service _______________________________ Service must be performed by a qualified trained technician, service agency, or gas supplier. If service is required, contact the reseller from whom the ADC equipment was purchased. If the reseller cannot be contacted or is unknown, contact the ADC Service Department for a reseller in your area. -
Page 20: Routine Maintenance
OUTINE AINTENANCE Cleaning ______________________________ A program and/or schedule should be established for periodic inspection, cleaning, and removal of lint from various areas of the dryer, as well as throughout the ductwork system. The frequency of cleaning can best be determined from experience at each location. -
Page 21: Procedure For Functional Check Of Replacement Components
ROCEDURE FOR UNCTIONAL HECK OF EPLACEMENT _________________ OMPONENTS Microprocessor Controller (Computer) Board _________________________________ Upon completing installation of the replacement microprocessor controller (computer) board, reestablish power to the dryer. Start the drying cycle by pressing any of the preset cycles in letters A-F. -
Page 22: Data Label Information
ABEL NFORMATION When contacting American Dryer Corporation, certain information is required to ensure proper service/parts information from ADC. This information is on the data label that is affixed to the upper left side panel area behind the top control (access) door. When contacting ADC, please have the model number and serial number available. -
Page 23: Fire Suppression System (F.s.s.)
