CONTINUOUS FLOW ICEMAKER
Installation and Service Manual
Part No. 638085278
August 1999
Revision C
THIS DOCUMENT CONTAINS IMPORTANT INFORMATION
This Manual must be read and understood before installing or operating this equipment
IMI CORNELIUS INC; 1997--99
500-Series
700-Series
1000-Series
2000-Series
Distributed By:
Commercial Refrigeration Service, Inc.
WWW.WorldRestaurantSupply.COM
toll free (866) Ice Maker
(623) 869-8881
PRINTED IN U.S.A
