Tf/tl series woodburning fireplace
Hide thumbs

Advertisement

Table of Contents

For use in U.S./Canada
Underwriter's Laboratories Report No. MH6018
CFM Specialty Home Products
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
www.temcofireplaces.com
DO NOT DISCARD THIS MANUAL: Retain for future use.
TF/TL Series

Woodburning Fireplace

7461
Homeowner's Installation and Operating Manual
TF/TL
cover
2/04
For Models:
TF36
TF36i
TF42
TF42i
TL36
TL36i
TL42
TL42i
20007461 6/05 Rev. 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TF36 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Temco TF36

Summary of Contents for Temco TF36

  • Page 1: Woodburning Fireplace

    For Models: TF36 TF36i TF42 TF42i TL36 TL36i TL42 TL42i TF/TL Series Woodburning Fireplace 7461 Homeowner's Installation and Operating Manual TF/TL cover For use in U.S./Canada Underwriter's Laboratories Report No. MH6018 2/04 CFM Specialty Home Products 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777 www.temcofireplaces.com...

  • Page 2: Table Of Contents

    fireplace. The TF/TL Series fireplaces are solid fuel, woodburning These fireplaces are not approved for installation in fireplaces. The TF36/42 is a clean-face fireplace and the mobile homes. TL36/42 unit has fixed grilles.

  • Page 3: Specifications And Framing

    Electrical Access �����" (337mm) If elbows are offset to the back of the unit, chase depth will be 22⁵⁄₈" (575mm). FP526 Fig. 1 TF36 Series specifications and framing. BR36 SPECS 10/28/98 TL36 Series Woodburning Fireplace — Circulating Model ��" (559mm)
  • Page 4 TF/TL Series Woodburning Fireplaces TF42 Series Woodburning Fireplace ��" (711mm) Rough Opening Depth 11" Dia. 49" (1245mm) ����" (279mm) �����" (187mm) ���" (13mm) (521mm) 8" Dia. 20" (203mm) Recessed (508mm) ���" Nailing Flange Rough Opening Width 47" (1194mm) Rough Opening Height ���"...

  • Page 5: Parts Identification

    TF/TL Series Woodburning Fireplaces Front Width Back Width Depth TF/TL36 33¹⁄₄" 19⁵⁄₈" 15¹⁄₄" (845 mm) (499 mm) (387 mm) TF/TL42 39¹⁄₄" 25⁵⁄₈" 15¹⁄₄" (997 mm) (651 mm) (387 mm) FP1531 FP1531 Fig. 4a Hearth dimensions. hearth dimensions 9/04 djt Chase Installation Insulation methods shown are optional for cold climate, not a requirement for unit operation.

  • Page 6: Chimney Requirements

    TF/TL Series Woodburning Fireplaces Chimney Requirements - Offset Installations OFFSET CHIMNEY FLUE EXIT RISE CHIMNEY SECTION FP282 30˚ 30˚ Elbow Offsets FP282 ELBOW RETURN MBUF ELBOW 5/26/96 1¹⁄₂' 3' 4' Offset Rise 30˚ 3" 11" OFFSET 8¹⁄₄" 20" ELBOW RISE 11¹⁄₄"...

  • Page 7: Planning Information

    TF/TL Series Woodburning Fireplaces Planning Information Preplanning an installation is very important to ensure The Ten Foot Rule safety and to save time and money. An installer must Major U.S. building codes specify a minimum chimney predetermine where a fireplace will be set and how the height above the roof top.

  • Page 8: Installation

    firestop. It is vital that some air be al- TEMCO Fireplace Products dealer for assistance. lowed to flow through this very thin gap. CAUTION: WHEN INSTALLING A FIREPLACE IN AN INSULATED ENCLOSURE, BE SURE ALL REQUIRED AIR SPACES ARE MAINTAINED.
  • Page 9 TF/TL Series Woodburning Fireplaces Framing Option For Circulating Models Only — Framing can be constructed before or after the fire- EB1 (Receptacle) Hook-Up: place is set in place, however, most installers build the frame before setting the fireplace. • Wiring should be installed by a certified electrician.
  • Page 10 TF/TL Series Woodburning Fireplaces Determine offset distance of your chimney arrangement Straight-Up Chimney Installation from centerline of fireplace to centerline of chimney To mark the centerline of the flue, put the fireplace where it is to pass through ceiling. in final position and measure out from the wall: 8¹⁄₄" Locate center point of the chimney on ceiling as though (210mm) a straight up chimney arrangement is to be used.
  • Page 11 TF/TL Series Woodburning Fireplaces The following table gives firestop spacer model num- Installing Outside Air Kit bers: An outside air kit is installed in all TF/TL Series Fire- Angle of Chimney at Ceiling places. If desired, or if local codes mandate the use of Size of Chimney Vertical 30°...
  • Page 12 TF/TL Series Woodburning Fireplaces Installing the Chimney System Pipe Section Start by attaching the first chimney section to the collar Pipe on top of the fireplace. Install the pipe as pictured in Figure 16. When you Lance get a good lock, you will hear the pipe clearly snap Pipe together.
  • Page 13 TF/TL Series Woodburning Fireplaces Firestop spacers are not available for nor are they re- quired on vertical walls. DO NOT put any sealant around the area where the Attic outer pipe slides through the firestop spacer. If you Insulation seal this area, it may cause a fire hazard. Shield Nails Canadian Requirements for...
  • Page 14 TF/TL Series Woodburning Fireplaces Install Remainder of Chimney Sections Air Space Clearances Since you have already preplanned the height of your Combustible framing material MUST NOT termination according to the Ten Foot Rule, continue to penetrate AIR SPACE (shaded areas). install pipe to the predetermined height.
  • Page 15 TF/TL Series Woodburning Fireplaces Mantel Clearance - Radiant Model - No Mantel Clearance - Radiant Mantel Clearance - Noncombustible Facing Material Model - with Noncombustible Circulating Model Facing Material Combustible Combustible Combustible Mantel and Mantel and Mantel and 12" 12" Trim 12"...
  • Page 16 TF/TL Series Woodburning Fireplaces Side Wall Protection Hearth Installation Adjacent combustible side walls that are within mini- A hearth extension is required to protect a combustible mum dimensions shown in Figure 23 of the fireplace floor in front of the fireplace. Refer to Figure 23 for mini- opening must be protected with CFM Corporation Wall mum dimensions and mounting detail.
  • Page 17 TF/TL Series Woodburning Fireplaces WARNING: HEARTH EXTENSION MUST BE IN- STALLED IN ACCORDANCE WITH FIGURE 23 AND Wall Covering MUST NOT COVER THE BOTTOM FRONT OPENING Noncombustible 2 x 4" HEADER - OF THE CIRCULATING MODEL. Decorative Do not notch at Facing standoffs.
  • Page 18 1" manufactures a wide variety of gas logs for use in Min. Supply Line Gas Line Tube TEMCO fireplaces.) Be sure to have the appliance installed in accordance Ceramic Repack Insulation with building codes. Knockout Gas connection may enter from either left or right side 1/2"...

  • Page 19: Replacement Parts

    TF/TL Series Woodburning Fireplaces CFM Specialty Home Products reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, with out notice. TF/TL SERIES For units: WF1C02, WF1CI2, WF1R02, WF1RI2, WF2CO2, WF2CI2, WF2R02, WF2RI2, WF1C04, WF1CI4, WF1R04, WF1RI4, WF2C04, WF2CI4, WF2R04, WF2RI4 Item/Model Number TF/TL36/36i...

  • Page 20: Accessories

    TF/TL Series Woodburning Fireplaces Accessories The following accessories for this appliance are available from your local TEMCO distributor. Should you need ad- ditional information beyond what your distributor can furnish, contact: CFM Specialty Home Products, 410 Admiral Blvd., Mississauga, Ontario, Canada L5T 2N6, Attn: Technical Services.
  • Page 21 TF/TL Series Woodburning Fireplaces Chimney Components U.S. Component Description Model Number Round Top Termination Top used to terminate chimney at roof. (Flashing not included.) RLTSK8 Round Top Termination - Top used to terminate chimney at chase. Extended (Flashing not included.) RLTSK8L Flashing Metal finishing required around Contemporary...
  • Page 22 TF/TL Series Woodburning Fireplaces (Chimney Components con't.) Canada Component Description Model Number Chimney Collar Enclosure Installs on the "over the chimney collar" of the CCE-SK fireplace; provides outside air to assist in cooling the chimney system. Attic Insulation Shield Used to prevent insulation from coming in AIS-SK contact with the chimney system.
  • Page 23 TF/TL Series Woodburning Fireplaces LIMITED WARRANTY AND EXCLUSIONS For TEMCO Fireplace Products Wood Burning Fireplaces This Limited Warranty covers the above described • Cracks in refractories that do not affect safe operation. fireplace and chimney systems. Accessories such as •...

  • Page 24: Warranty

    Customer Copy To register your warranty, please provide the information indicated on this form and mail to: CFM Corporation Attn: Warranty Registration 410 Admiral Blvd. Mississauga, Ontario Canada L5T 2N6 Installer’s Signature Print Installer’s Name Purchaser _____________________________________ WARRANTY REGISTRATION Please answer the following questions (Check Box): Address ______________________________________ 1.
