Summary of Contents for Jobsite LSC-8
- Page 1 INSTALLATION & USER GUIDE For Accurate Music and Voice Reproduction from In-Ceiling Locations LSC-8 8" IN-CEILING LOUDSPEAKER...
-
Page 2: Table Of Contents
LSC-8 8" IN-CEILING LOUDSPEAKER TABLE OF CONTENTS Features ...1 Product Overview ...2 Package Contents ...2 Preparing for Installation ...2 Installation ...3 Operation ...4 Specifications ...4 Warranty ...5... -
Page 3: Features
■ Rust proof aluminum grilles ■ Installation friendly design: Suitable for painting ■ Connection terminals accept up to 12 gauge speaker wire ■ Quick mounting system for new construction or retrofit installations ■ Includes hole template and paint mask ■... - Page 4 The illustration shows how a typical JobSite LSC-8 loudspeaker mounts into a ceiling. Dogs swivel 90°, then clamp the speaker frame to the drywall. Frames are molded with a slight texture to assure good paint adhesion. Mounting screws tighten the “dogs”, clamping the speaker to...
-
Page 5: Installation
10. Tightly twist the end of each wire until no frayed ends remain. 11. Attach the speaker wires to the speaker terminal connectors. Connect the negative output from the amplifier to the black terminal and the positive output to the red terminal. -
Page 6: Operation
Removing the Grilles: To remove the grille from the LSC-8, obtain a small paper clip (size #1, common) and bend the last quarter inch of it into an “L” shape. Holding the paper clip with a pair of pliers, insert the end with the “L”... -
Page 7: Warranty
LIMITED WARRANTY JobSite Systems (“JOBSITE”), a Niles Audio Corporation company, warrants its passive products (those not requiring AC or battery power) to the original purchaser to be free of manufacturing defects in material and workmanship for a period of ten years from date of purchase. - Page 8 WWW.JOBSITESYSTEMS.COM © 2005 JobSite Systems. All rights reserved. JobSite, Pure Custom and Niles are registered trademarks of Niles Audio Corporation and the JobSite Logo is a trademark of Niles Audio Corporation. All other trademarks are the property of their respective owners. Some JobSite products (or components thereof) are manufactured under one or more U.S.
