Summary of Contents for Jobsite LSC-BG
Page 1
For Music and Voice Reproduction from In-Ceiling Locations LsC-BG BUILdeR GRade IN-CeILING LOUdsPeaKeR...
Page 2
LsC-BG BUILdeR GRade IN-CeILING LOUdsPeaKeR FeatURes: • Specifically designed for in-ceiling applications • D esigned for maximum value, achieving excellent audio performance while maintaining affordability • L SC-BG is compatible with Jobsite NCB-6 new-construction brackets (sold separately). exIstING CONstRUCtION INstaLLatION: • P lace the cardboard paint mask/hole template up to the drywall in the selected location and mark the hole size. • Drill a starting hole • Use a sheetrock or keyhole saw to cut the hole. New CONstRUCtION INstaLLatION: • F ollow the instructions included with the bracket to install the bracket to the joists. • Install the drywall over the bracket • Drill a starting hole • Use a sheetrock or keyhole saw to cut the hole sPeCIFICatIONs: • Woofer is 6-1/2" polypropylene with a urethane surround. • Tweeter is 3/4" fluid-cooled ultra-wide dispersion Kaladex • Power handling: 5-50 watts • Frequency Response: 67Hz to 20kHz +/-4dB...
