- Page 1 INSTALLATION & USER GUIDE For Lifelike Sound and Natural Looks Outdoors LSR-5 / 6 ALL WEATHER ROCK LOUDSPEAKER...
-
Page 2: Table Of Contents
LSR-5 / 6 ALL WEATHER ROCK LOUDSPEAKER TABLE OF CONTENTS Features...1 Product Overview...1 Package Contents ...2 Preparing for Installation...2 Installation...2 Specifications ...5 Warranty...5... -
Page 3: Features
FEATURES LSR-5 5-1/4” injection molded polypropylene woofer with butyl rubber surround 3/4” liquid cooled polycarbonate dome tweeter Multi-layer fiberglass construction Weather, corrosion and UV resistant Rust proof aluminum grille Installation friendly design: Includes security bracket and cable Includes 3’ burial rated cable with water-proof wire-nuts FEATURES LSR-6 6-1/2”... -
Page 4: Package Contents
2. Run the cable to the loudspeaker locations. 3. Do not cover the wire until you verify loudspeaker operation. 4. Strip two to three inches of the speaker cables’ outer jacket away from the insulated conductors. 5. Strip 1/2" of insulation from the end of each wire. - Page 5 Figure 2 Security Cable in Eyelet 3. Feed the opposite end of the nylon security cable through the exposed portion of the cable that was just fed through the security eyelet, as shown in Figures 3 and 4. Figure 3 Security Cable Looping Through Figure 4 Security Cable after Looping 4.
- Page 6 Stainless steel wire rope clamps sized to the aircraft cable chosen x 2 Prepare a hole that is at least one-foot deep, or three-feet deep if the speaker is being installed in an area that has a frost line. The hole should be at least eight inches in diameter.
-
Page 7: Specifications
If the above conditions are met, the purchaser’s sole remedy shall be to return the product to JOBSITE, in which case JOBSITE will repair or replace, at its sole option, the defective product without charge for parts or labor. JOBSITE will... - Page 8 JobSite Systems, a Niles Audio Corporation company, 12331 S.W. 130 Street, Miami, Fl 33186. ©2004 Niles Audio Corporation. JobSite, Pure Custom and Niles are registered trademarks of Niles Audio Corporation and the JobSite Logo is a trademark of Niles Audio Corporation. All other trademarks are the property of their respective owners.
