Page 1: Quick Installation Guide
JetNet 6059G Series Industrial 9-port Gigabit Managed Ethernet Switch Quick Installation Guide www.korenix.com V1.0... -
Page 2: Package Checklist
Introduction JetNet 6059G series is an Industrial Gigabit Managed Ethernet Switch with 9 full gigabit ports and 32G switching backplane to ensure high quality data transmission in industrial applications requiring high-bandwidth connectivity. In addition to 4 Giga RJ-45 ports, the switch is equipped with 5 Giga RJ-45/SFP combo ports to deliver maximum throughput and flexibility for high-density connection while providing Giga uplink or Giga Ring connection. -
Page 3: Wiring The Power Inputs
Grounding JetNet 6059G There is one grounding screw on the bottom side of JetNet 6059G. Connect the frame grounding of JetNet 6059G to the grounding surface to ensure safety and prevent noise to interfere communication. Wiring the Power Inputs 1. Insert the positive and negative wires into the V+ and V- contact on the terminal block connector. - Page 4 flashing to indicate the communication is occurred between 2 devices. 2. Connecting the SFP Port: Plug in SFP fiber transceiver. We recommend using Korenix certificated SFP mini GBIC transceiver. Cross-connect the transmit channel at each end to the receive channel at the opposite end as illustrated in the Figure-5.
-
Page 5: Device Management
Device Management JetNet 6059G Industrial Managed Switch provides both in-band and out-band configuration methods. You can configure the switch via the RS232 console with the attached console cable. Or you can remotely manage the switch via network. You can choose Telnet/SSH, Web/HTTPS management. - Page 6 User’s manual of JetNet 6059G included in the packing or downloadable from the Korenix Website – www.korenix.com. Korenix Customer Service KoreCARE is Korenix Technology’s global service center, where our professional staffs are ready to answer your questions at any time. Korenix global service center’s e-mail is KoreCARE@korenix.com...
- Page 7 Tel:+886-2-89111000 Fax:+886-2-29123328 Business service:sales@korenix.com Customer service:koreCARE@korenix.com CPQ000N6059000...
