Installation
Please ensure that the driver installation is complete prior to the physical
installation (plugging in) of the USB RS232 Serial Hub.
Driver Installation
Windows 2000/XP/Server 2003
1. Before connecting the Serial Hub to the host computer, insert the included Driver
CD into the computer's CD/DVD drive.
2. AutoPlay should automatically launch and display all of the folders on the CD. If not,
open "My Computer" and double-click on the CD/DVD drive.
3. Enter the folder "232 drv_100804", then double-click the file "Win_Setup.exe".
4. This will launch the driver Installation wizard. The installation screen will
automatically close once complete, and all the necessary drivers installed.
5. Connect the Serial Hub to the computer via USB. The Serial Hub will be
automatically detected and Windows should begin installing the drivers.
6. Once Windows has installed the drivers, the serial ports will be ready for use.
Instruction Manual
*installation photos for reference only
3
