I N S T A L L A T I O N G U I D E
for the
SB-S-IMPRZA/10W6v2 SB-S-IMPRZA/10W6v2
2002 - Up Subaru Impreza Sedans 2002 - Up Subaru Impreza Sedans
(will not fit sport wagons) (will not fit sport wagons)
Thank you for choosing a JL Audio Stealthbox
installation, your new vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox
dealer. The installation professionals employed by your dealer have the necessary tools and experience
to disassemble and reassemble your vehicle properly. Also, keep in mind that your warranty coverage
extends to 1 year if your system is installed or approved by your authorized JL Audio dealer. If you
prefer to perform your own installation, please read this installation guide completely
before beginning the process.
® for your automotive sound system. With proper
® installed by your authorized JL Audio
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
SB-S-IMPRZA/10W6v2_INSTR_SKU#011218 SB-S-IMPRZA/10W6v2_INSTR_SKU#011218
INSTALLATION
D I F F I C U L T Y :
2
S T E P 1
Remove the heavy carpet flooring from the trunk.
Flip over the thin underlying carpeting, as shown in the
picture at the right.
S T E P 2
Locate and remove the round sticker that covers an exsisting
factory hole. The sticker will be painted the same color as the
exterior of the vehicle.
S T E P 3
Enlarge this factory hole, using an Uni-bit® or 1/2-inch
drill bit.
Note: Before drilling, make sure that you are not going
to be drilling into any gas lines, brake lines, transmission
lines, electrical wiring, transfer case (4x4 vehicles)
or anything else that might cause a reduction in your
weekly pay. Always wear eye protection when drilling!
Continued on Next Page
OUT
OF 5
