I N S T A L L A T I O N G U I D E
for the
SB-F-F1502/10W3v3 SB-F-F1502/10W3v3
2004 - 2008 Ford F-150 Super Crew & Super Cab 2004 - 2008 Ford F-150 Super Crew & Super Cab
2006 - 2008 Lincoln Mark LT 2006 - 2008 Lincoln Mark LT
Thank you for choosing a JL Audio Stealthbox
installation, your new vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox
dealer. The installation professionals employed by your dealer have the necessary tools and experience
to disassemble and reassemble your vehicle properly. If you prefer to perform your own installation,
please read this installation guide completely
before beginning the process.
& &
® for your automotive sound system. With proper
® installed by your authorized JL Audio
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
SB-F-F1502/10W3v3_INSTR_SKU#011251 SB-F-F1502/10W3v3_INSTR_SKU#011251
INSTALLATION
D I F F I C U L T Y :
1
ESTIMATED TIME:
1 HOUR HOUR
S T E P 1
Remove all contents from the rear seating area.
Lift up both seats.
Remove the jack, jack tools and the jack's mounting bracket.
The jack and the jack tools must be relocated.
S T E P 2
Thread a supplied socket cup screw into the driver's side rear
of the Stealthbox®, leaving 1.0" of the threads exposed.
S T E P 3
Thread another supplied socket cup screw into the
passenger's side rear of the Stealthbox®, leaving 1.0" of the
threads exposed.
Continued on Next Page
OUT
OF 5
