Tyre Pressure Sensor Serial Number

The serial number for the tyre pressure
sensor is printed on a label attached to the
sensor. This number may be required by the
dealer for service or diagnostics.
When the tyre pressure monitoring system is
being fitted to the motorcycle, ensure that the
dealer records the serial numbers of the front
and rear tyre pressure sensors in the spaces
provided below.
Front Tyre Pressure Sensor
Rear Tyre Pressure Sensor
General Information

System Display

Warning
Do not attempt to switch between front
and rear tyre display modes with the
motorcycle in motion as this may lead to
loss of motorcycle control and an accident
1
5
6
cgjp_6
1. TPMS symbol
2. Tyre pressure display
3. Front tyre, identified
4. Rear tyre, identified
5. Button A
6. Button B
To access the tyre pressure display, turn the
ignition to the ON position.
Press and release button 'A' until psi or bAr is
visible in the display screen.
Press and release button 'B' to select the front
or rear tyre pressure.
3
4
2
29
